Compression for the web

1
Compression for the web

• The right size for the right job

2
(No Transcript)
3
Terms you should know

• Video Compression
• Resolution
• Interlacing vs. Progressive
• Fields vs. Frames
• Lossless vs. Lossy
• VBR vs. CBR
• Intraframe vs. Interframe

4
Video Compression

• Reducing the quantity of data used to represent
  digital video images

5
Resolution

• The number of pixels/lines vertically displayed
  the screen
• 320x180 (180 lines)
• 480x270 (270 lines)
• 640x360 (360 lines)
• 1280720 (720 lines)
• 19201080 (1080 lines)

6
Interlaced vs. Progressive

• A FULL image for each frame

• Only HALF the lines are drawn each frame

7
Fields vs. Frames

• Interlaced video is represented by either odd OR
  even fields per frame

8
Lossless vs. Lossy

• Negligible file size difference from original

1/8th the file size of original with unnoticeable
quality difference to most viewers

• NOTE Lossy compression is most often noticed in
  scenes with text, transitions and/or lots of
  movement

9
VBR vs. CBR

• VBR variable bit rate
• Allows for best compression size based on the
  needs of the file
• Will only use the required amount of bits to save
  frame information
• CBR constant bit rate
• Maintains the set bit rate throughout the entire
  video
• Important for streaming media

• Complex image sequence that takes advantage of
  higher bit rate as necessary

• Majority of the screen uses the same background
  from frame to frame
• File size can decrease greatly without
  significant quality loss

10
Intraframe vs. Interframe

• Intraframe
• Records every pixel for every frame regardless if
  the pixel information has changed or not
• Examples
• AVC-I
• DVC-Pro HD
• Apple ProRes

• Interframe
• Records an I-Frame and then only records the
  pixels that change from one frame to the next
  depending on the GOP structure
• Examples
• HDV
• MPEG-2

11
Evaluating Video for Compression
12
Evaluating Video for Compression

• How was the video shot?
• Is the video image static or in motion?
• Was it shot interlaced or progressive?
• Is the video high or low contrast?

13
Evaluating Video for Compression

• How was the video edited?
• Are there long or short edits?
• Are there mostly cuts or transitions?
• Are there lots of graphics?
• If so, are they static or in motion?
• Has the video been stylized in any way?

14
Evaluating Video for Compression

• Who is the intended audience?
• How are the viewers watching?
• Computer, TV, Mobile, etc
• Will it be an individual or group viewing?
• How large is the screen?
• How far away are the viewers expected to be?
• Which is more important
• Quality or Speed of Delivery?

15
Progressive Download vs. Streaming Video
16
Progressive Download

• Allows the viewer to begin playback before the
  download is fully complete
• Use if
• Delivering short videos (less than 10min)
• Operating a small website with low traffic
• Using a higher quality video than a streaming
  connection would allow

17
Streaming Video

• Allows for real time broadcasting of live
  events the ability to control playback
  on-demand
• Use if
• Delivering long videos (greater than 10min)
• Delivering to many viewers simultaneously
• Using bandwidth detection or a quality monitoring
  service
• Serving live events

18
Streaming Video

• Must be played back from a separate server
  programmed for streaming
• Flash Media Server (FLV, SWF)
• Apple OS X Server (Quicktime)
• Darwin Streaming Server (Quicktime)
• Windows Media Services (WMV, Silverlight)

19
Formats
20
Formats

• A particular way that information is encoded for
  storage in a file
• Examples
• AVI, ASF, WMV, FLV, MOV, MPEG-2(TS), MP4, Ogg,
  RMV, 3GP

21
Format vs. Codec
22
Format vs. Codec

• Wrapper refers to the coding format
• Codec is an acronym for compression/decompress
  ion
• Example
• Flash Video (FLV) is a format
• H.264, On2 VP6, Sorenson Spark are codecs for
  Flash FLVs

23
Current Popular Codecs
24
Current Popular Codecs

• VC-1 Windows Media
• VP6 FLV
• MPEG-2 Quicktime, DVD
• MPEG-4 part 10 (AVC)

25
H.264

• The most commonly used codec today

26
Older Common Codecs

• MPEG-4 part 2 (DivX, Xvid, FFmpeg, 3ivx)
• H.263
• Cineform
• RealVideo
• Sorenson Spark
• Sorenson 3
• Cinepak
• MPEG-1

27
Compression Software
Adobe Media Encoder CS4
Sorenson Squeeze 5
Telestream Episode 5.2
Apple Compressor 3.5
Microsoft Expression Encoder
Mac Only
Windows Only
28
Adobe Media Encoder
29
Adobe Media Encoder
30
Apple Compressor
31
Apple Compressor
32
Sorenson Squeeze
33
Sorenson Squeeze
34
Telestream Episode
35
Your Toolkit
Programs everyone should have
36
Examples
37
YouTubeHD

• H.264 codec
• mp4 format
• 1280 x 720
• 6Mbps - 9Mbps
• 24fps
• Audio AAC 64kbps 44.1 kHz

38
iPhone

• H.264 codec
• m4v format
• 640 x 360
• 1500kbps
• Native frame rate
• Audio AAC 128kbps 44.1 kHz

39
DVD-SD

• Video Settings
• MPEG-2 codec
• m2v format
• 720 x 480
• 6.2Mbps - 7.7Mbps
• 29.97fps
• Mode One Pass Best
• Motion Estimation Best

40
DVD-SD

• Audio Settings
• Dialog Normalization -31 dbFS

41
DVD-SD

• Audio Settings
• Compression Preset None

42
Blu-Ray

• H.264 codec
• m4v format
• 1440 x 1080
• 20Mbps - 25Mbps
• 23.98fps
• Audio PCM 192kbps 48 kHz

43
Questions?
