1st ARMD REGT

1
1st ARMD REGT

• M1A1 AIM SA and M88A2
• Logistics Planning Data Handbook

2
PLANNING FACTORS
M1A1 / M88 to Support Tank REGT 41 M1A1
Tanks 4 M88A2 Tank Sqn (3 / REGT) 14
M1A1 Tanks 1 M88A2 Tank Tp (3 / Sqn)
4 M1A1 Tanks 1 M88A2 (may be
attached) Tank Section (2 / Tp) 2 M1A1
Personnel to Support Tank Regt 481 pers 40 x
Offr / 79 x SNCO / 362 x OR Tank Sqn 90
pers 6 x Offr / 8 x SNCO / 76 x OR Tank Troop
16 pers 1 x Offr / 1 x SNCO / 14 x OR Tank
Section 8 pers 1 x Offr or SNCO / 7 x OR
3
PLANNING FACTORS1AR DEPLOYABLE READY TANK TROOP
GROUP (1AR RTTG)THE 1AR RTTG CONTAINS 1 X TANK
TROOP AND ALL SPECIALIST M1A1/M88 LOG
REQUIREMENTS, IT IS HELD ON 7 DAYS NOTICE TO MOVE
Deployed JTF/BG
1 AR LO/Det Embedded SO

5 x M1A1 (4 TK TP 1 Spare) 1 x M88A2 ARVM 1 x
M113AS4 for protection/tooling 1 x Armoured
Unimog for RPS 1 x Truck Tanker Fuel 0-5 x 20ft
ISO containers of RPS STORES (dependant
on OVP) 31-34 x Pers

4
CONSUMABLES - POL
M1A1 POL CONSUMPTION RATES / HOUR

• NOTES
• The above mentioned POL are those with the
  highest consumption rates
• The M1A1 has a 1910L fuel tank, this will last
  for 8 hours at idle and up to 12 hours when
  moving, (the turbine engine burns less fuel and
  more oxygen at high revs whilst moving)
• The M1A1 has an External Auxiliary Power Unit
  (EAPU). The EAPU is essentially a small generator
  which enables the M1A1 to operate all weapon and
  targeting systems, including the thermal image
  system in static roles at greatly reduced fuel
  consumption over prolonged periods.
• Jetoil 2 consumption can also be provisioned
  using the following formula 2 quarts / tank /
  day.
• FRH consumption can also be provisioned using the
  following formula 5 litres / tank / week.
• Grease consumption can also be provisioned using
  the following formula 3 cartridges / tank /
  week.
• 15W40 consumption can also be provisioned using
  the following formula 10 litres / tank / week.

THE M88A2 USES 3 L DEISO / KM AND HAS A 1563L
FUEL CABACITY
5
CONSUMABLES - POL
FBCB2 FUEL REPORT TABLE
REPORTED FUEL STATUS
3088 3861 4633 5632 6177 6949 7729 8494 92
66 10038 10810
4 5 6 7 8 9 10 11 12 13 14
1530 1911 2316 2718 3102 3497 3891 4284 46
78 5072 5450
2347 2932 3520 4107 4693 5280 5866 6453 70
40 7627 8213
4603 5753 6904 8047 9205 10356 11506 12657
13807 14958 16109
Attached M1 Series Vehicles to Unit
2244
Fuel Required (Liters)
This chart identifies the amount of fuel required
to refill based upon their Class III report.
6
CONSUMABLES - POL

• 1 ARMD REGT BULK FUEL ASSETS
• 8 X MACK TRUCK TANKER FUEL-AVIATION (TTF-A)
  PLANNING CAPACITY 12500L (PICTURED BELOW)
• 2 X MACK TRUCK TANKER FUEL (TTF) PLANNING
  CAPACITY 11380L
• REGT TOTAL FUEL CAPACITY OF 122760L
• THE TTF-A IS THE PREFERRED OPTION FOR REFUELLING
  THE M1A1 AND M88A2 DUE TO ITS FASTER PUMP AND
  BETTER FUEL FILTRATION SYSTEM.

7
CONSUMABLES - POL
RECOMMENDED PRE H-HOUR POL HOLDINGS
8
CONSUMABLES - BATTERIES
BATTERY CONSUMPTION RATES
9
CONSUMABLES - BATTERIES
RECOMMENDED PRE H-HOUR BATTERY HOLDINGS
10
CONSUMABLES - GASSES
GAS CONSUMPTION RATES
11
POL, GAS BATTERY NSNs
12
AMMUNITION
RECOMMENDED PRE H-HOUR AMMO HOLDINGS (RNDS)

• Notes
• Tank Crewmen are to be supplied small arms
  ammunition (9mm 5.56 loose) in accordance with
  extant holdings.
• The above A1 and A2 holdings require 17 and 52
  pallet spaces, respectively, to carry.
• Whilst a Mack is usually capable of carrying 10
  pallets, if it is being used to replen MA1As
  directly only 6 pallets can be packed on it in
  order to allow space for pers to unload
  ammunition and hand off to tank crewmen. (see
  fig1)
• 120mm ammunition comes in a 30rnd wine rack
  whereby each round is pressure sealed into a tube
  that should only be opened immediately prior to
  loading it onto the tank. (see fig2)
• A planning weight of 700kg per 30rnd wine rack
  should be used when loading 120mm ammo on other
  platforms

13
AMMUNITION
MACK AMMO TRUCK SIDE VIEW
MACK AMMO TRUCK TOP VIEW

• FIGURE 1, 120mm Ammunition Wine rack storage on
  MACK truck
• wine racks are to be positioned facing
  forward/backward so that 120mm ammo cam be
  unloaded within the confines of the trucks tray.
• all ammunition handling/unloading is to occur on
  the tray of the truck in order to avoid crush
  injuries if/when Tanks touch side of truck.
• only when tanks have halted beside the truck is
  it safe to step across to the Tank and cross load
  ammo.

FIGURE 2, 120mm Ammunition in its Wine
rack (planning weight 700kg / wine rack)
14
AMMUNITION
AMMUNITION CONSUMPRION/SUSTAINMENT RATES RNDS
PER TANK PER DAY
Infantry/ MOUT Armor
Threat
Environment Environment
Assault
Sustain Assault
Sustain 7.62mm 4BIT link
18600 9300 12400
6200 12.7mm 4BIT link
2000 1000 2000
1000 120 mm APFSDS-T
28 6 29
4 120mm MPAT
27 7
28 5 120mm CANISTER
8 1
8 1 Grenade, Launcher
Smoke IR 51 34
29 27
15

AMMUNITION TSNs

• Notes
• 12.7 mm (AIMTESS) are rounds that are
  ballistically matched to 120mm natures out to
  2000m. They are fired for training purposed from
  an assembly that fits inside the M1A1s Breech.
• 7.62mm ammunition should, where possible, be
  ordered in 235rnd (M19)liners. This is because
  the stowage positions inside the Tank as well as
  the loaders and coax MGs only take this
  size/shape liner.

16
ITEM NSN  HUB
01-063-5666 BEARING(SM)
00-101-6493 BEARING(LG) 00-101-4194 SEALS 0
1-065-6208 HUBCAPS
01-063-5862 PLUG
01-128-9554 O-RING
01-067-3446 ROAD WHEEL NUT 01-064-3910
ROAD WHEEL WASHER
01-382-9996 ROTARY SHOCK SEAL KIT
01-270-7498 TORSION BAR LEFT
01-063-5838 TORSION BAR RIGHT
01-063-5837 COMPENSATING IDLER RIGHT
01-179-1417 COMPENSATING IDLER LEFT
01-179-1416 ROAD ARM LEFT
01-180-8676 ROAD ARM RIGHT
01-180-8677 ARM ASSEMBLY NO1 RIGHT
01-063-5856 ARM ASSEMBLY NO1 LEFT
01-065-6297 ARM ASSEMBLY NO 2, 7 LEFT
01-185-5974 ARM ASSEMBLY NO 2, 7 RIGHT
01-185-5975 TRACK T158LL 01-435-5175 AUX HYD
PUMP 01- 073-4289 CEU 01-290-7508 LOS 01-171-4
774 MDU 01-238-8186 MOTOR BRAKE
01-180-3512 MOTOR BRAKE MOTOR
01-075-9295 TRU 01-293-9706 LRF
01-149-8302 TDV 01-308-1858 PCU
01-204-5765 GTD 01-190-6175
COMMON M1A1 RPS REQUIREMENTS
THE M88A2 IS BUILT ON A M60 TANK HULL NOT A M1
TANK HULL THERE IS NO PARTS COMMONALITY BETWEEN
THE M88A2 AND THE M1
17
RESUPPLY PLANNING
1 ARMD REPLEN PROCEDURES LINEAR REPLEN

• A LINEAR REPLEN CAN BE TAILORED FOR THE SIZE OF
  THE ELEMENT BEING RESUPPLIED, THE BELOW LINEAR
  REPLEN IS APPROPRIATE TO REPLEN A SQN IN ONE HOUR
• A LINEAR REPLEN CAN BE CONDUCTED ON A ROAD OR IN
  A GREEN-FIELD ENVIRONMENT (WITHIN THE CROSS
  COUNTRY LIMITATIONS OF FULLY LADEN MACKS)
• THE TP SGT, SSM OR RSM OF THE ELEMENT CONDUCTING
  THE REPLEN SHOULD RV WITH LOG ELEMENTS PRIOR TO
  THE REPLEN OCCURING IN ORDER TO SITE THE LINEAR
  REPLEN TAKING ALL SUPPLY AND TACTICAL
  CONSIDERATIONS SUCH AS LIKELY ENEMY APPROACH AND
  SPACING INTO ACCOUNT
• TTF-A SHOULD BE USED TO REFUEL ON LINEAR REPLENS
  WHERE POSSIBLE DUE TO THEIR FASTER PUMPING
  CAPACITY
• THE LOADING OF AMMUNITION IS GENERALLY THE
  SLOWEST PART OF THE REPLEN

COMD
AMMO AMMO
TTF-A
TTF-A
WATER RATS
SQ/GARBAGE

• A CURBSIDE REPLEN IS SIMILAR TO A LINEAR REPLEN,
  HOWEVER IT ONLY OCCURS OFF THE SIDE OF AN
  ESTABLISTED TRACK AND TANKS ONLY PASS TO ONE SIDE
  OF THE RESUPPLY ELEMENT. (CURBSIDE REPLENS
  USUALLY OCCUR INA NON-TACTICAL ENVIRONMENT)

18
RESUPPLY PLANNING
1 ARMD REPLEN PROCEDURES BATTLE REPLEN

• A BATTLE REPLEN IS A REPLEN POINT ESTABLISTED
  BEHIND TANKS IN-CONTACT, ONE TANK OR ONE SECTION
  PULLS OUT OF CONTACT AT A TIME AND CONDUCTS A
  PIT STOP STYLE REPLEN OF FUEL AND AMMO
• A BATTLE REPLEN CAN BE CONDUCTED ANYWHERE
  NECESSARY (WITHIN THE CROSS COUNTRY LIMITATIONS
  OF FULLY LADEN MACKS)
• THE TP SGT/SSM OF THE ELEMENT CONDUCTING THE
  BATTLE REPLEN SHOULD SITE, COORDINATE AND MANAGE
  THE SECURITY OF THE BATTLE REPLEN
• IT IS BETTER TO CONDUCT SEVERAL TP/SQN SIZED
  BATTLE REPLENS BEHIND THE FLOT, AS A SINGLE LARGE
  REPLEN WILL CAUSE CONJESTION, CONFUSION AND
  UNNECESSARY LATERAL MOVEMENT BEHIND THE FLOT.
• TTF-A SHOULD BE USED TO REFUEL ON BATTLE REPLENS
  WHERE POSSIBLE DUE TO THEIR FASTER PUMPING
  CAPACITY. (IF MULTIPLE TTF ARE AVAILABLE THEY
  SHOULD BE USED CONCURRENTLY)

BATTLE REPLEN
TANK TP IN CONTACT
19
RESUPPLY PLANNING
1 ARMD REPLEN PROCEDURES IN HIDE REPLEN

• AN IN HIDE REPLEN AIMS TO MINIMISE TANK MOVEMENT
  BY MOVING ALL RESUPPLY ASSETS TO STATIC TANKS
• AN IN HIDE REPLEN CAN BE CONDUCTED ANYWHERE
  NECESSARY (WITHIN THE CROSS COUNTRY LIMITATIONS
  OF FULLY LADEN MACKS)
• THE TP SGT/SSM OF THE ELEMENT CONDUCTING THE IN
  HIDE REPLEN SHOULD DIRECT THE REPLEN
• IN HIDE REPLENS ARE AN EXTREMELY SLOW WAY TO
  CONDUCT REPLENS

TANK TP IN HIDE
20
FBCB2 / BFT

• Two major capabilities that the M1A1 and M88A2
  Platforms posses are the Force XX1 Battle Command
  Brigade and Below (FBCB2) and Blue Force Tracker
  (BFT)
• FBCB2 / BFT is a live satellite based
  communication and tracking system which affords
  unprecedented situational awareness to the M1A1
  and M88A2 platforms

21
(No Transcript)
22
FBCB2 / BFT

• 1 Armd Regt has the capability to link portable
  (non-vehicle mounted) FBCB2 / BFT systems into
  another unit/BG HQ if required.
• For FBCB2 / BFT to work it requires L-Band
  satellite coverage, at present L-Band coverage
  exists over Australia, North America and all
  major US theatres of operation.

23

24
gt . . . . . . . . . . . . . . . . . . . . .
25
Correct as at 28 Jul 2008

• Complied By
• CAPT W. Frazer
• CAPT B. Franklin
• CAPT J. Cottis
• WO1 J. Miller
