Adapting Routing to the Traffic

• COS 461 Computer Networks
• Spring 2007 (MW 130-250 in Friend 004)
• Jennifer Rexford
• Teaching Assistant Ioannis Avramopoulos
• http//www.cs.princeton.edu/courses/archive/spring
  07/cos461/

2
Goals of Todays Lecture

• Challenges
• Reacting quickly to alleviate congestion
• Avoiding over-reacting and causing oscillations
• Limiting bandwidth CPU overhead on routers
• Load-sensitive routing
• Routers adapt to link load in a distributed
  fashion
• At the packet level, or on group of packets
• Traffic engineering
• Centralized computation of routing parameters
• Network-wide measurements of offered traffic

3
Do IP Networks Manage Themselves?

• TCP congestion control
• Senders react to congestion
• Decrease sending rate
• But the TCP sessions receive lower throughput

• IP routing protocols
• Routers react to failures
• Compute new paths
• But the new paths may be congested

2
2
1
1
4
4
1
1
3
3
2
2
1
1
5
5
4
4
3
3
4
Do IP Networks Manage Themselves?

• In some sense, yes
• TCP senders send less traffic during congestion
• Routing protocols adapt to topology changes
• But, does the network run efficiently?
• Congested link when idle paths exist?
• High-delay path when a low-delay path exists?

2
2
1
1
4
4
1
1
3
3
2
2
1
1
5
5
4
4
3
3
5
Adapting the Routing to the Traffic

• Goal modify the routes to steer traffic through
  the network in most effective way
• Approach 1 load-sensitive protocols
• Distribute traffic performance measurements
• Routers compute paths based on load
• Approach 2 adaptive management system
• Collect measurements of traffic and topology
• Management system optimizes the parameters
• Debates still today about the right answer

6
Load-Sensitive Routing Protocols

• Advantages
• Efficient use of network resources
• Satisfying the performance needs of end users
• Self-managing network takes care of itself
• Disadvantages
• Higher overhead on the routers
• Long alternate paths consume extra resources
• Instability from out-of-date feedback information

7
Packet-Based Load-Sensitive Routing

• Packet-based routing
• Forward packets based on forwarding table
• Load-sensitive
• Compute table entries based on load or delay
• Questions
• What link metrics to use?
• How frequently to update the metrics?
• How to propagate the metrics?
• How to compute the paths based on metrics?

8
Original ARPANET Algorithm (1969)

• Routing algorithm
• Shortest-path routing based on link metrics
• Instantaneous queue length plus a constant
• Distributed shortest-path algorithm (Bellman-Ford)

2
1
3
1
3
2
1
5
20
congested link
9
Performance of ARPANET Algorithm

• Light load
• Delay dominated by transmission propagation
• So, link metrics dont fluctuate much
• Medium load
• Queuing delay is no longer negligible
• Moderate traffic shifts to avoid congestion
• Heavy load
• Very high metrics on congested links
• Busy links look bad to all of the routers
• All routers avoid the busy links
• Routers may send packets on longer paths

10
Problem Out-of-Date Information

• Routers make decisions based on old information
• Propagation delay in flooding link metrics
• Thresholds applied to limit number of updates
• Old information leads to bad decisions
• All routers avoid the congested links
• leading to congestion on other links
• and the whole things repeats

11
Problem Frequent Updates

• Update messages
• Link keeps track of its metric (e.g., queuing
  delay)
• Link transmits updates when the metric changes
• Frequency of updates
• Frequent changes to the metric lead to frequent
  updates
• Significantly increases the overhead of the
  protocol
• Oscillation makes the problem worse
• Oscillation leads to wild swings in the link
  metrics
• Forcing very frequent update messages
• that add to the load on the links in the network

12
Second ARPANET Algorithm (1979)

• Link-state protocol
• Old Distributed path computation leads to loops
• New Better to flood metrics and have each router
  compute the shortest paths
• Averaging of the link metric over time
• Old Instantaneous delay fluctuates a lot
• New Averaging reduces the fluctuations
• Reduce frequency of updates
• Old Sending updates on each change is too much
• New Send updates if change passes a threshold

13
Problem of Long Alternate Paths

• Picking alternate paths
• Long path chosen by one router consumes resource
  that other packets could have used
• Leads other routers to pick other alternate paths
• Solution limit path length
• Bound the value of the link metric
• This link is busy enough to go two extra hops
• Extreme case
• Limit path selection to the shortest paths
• Pick least-loaded shortest path in the network

14
Load-Sensitive Routing

• Timescales
• What timescale of routing decisions?
• What timescale of feedback about link loads?
• Load-sensitive routing at packet level
• Routers receive feedback on load and delay
• Routers re-compute their forwarding tables
• Fundamental problems with oscillation
• Load-sensitive routing for groups of packets
• Routers receive feedback on load and delay
• Router compute a path for the next flow or
  circuit
• Less oscillation, as long as circuits last for a
  while

15
Reducing Effects of Out-of-Date Info

• Send link metrics more often
• But, leads to higher overhead
• But, propagation delay is a fundamental limit
• Make the traffic last longer
• Route on groups of packets, rather than packets
• Fewer routing decisions, and more accurate
  feedback
• Groups of packets
• Telephone network phone call (3-minutes long)
• Internet TCP connection (10-packets long)
• Internet all traffic between a pair of hosts, or
  routers,

More when we talk about circuit switching later
in the course.
16
Traffic Engineering as a Network-Management
Problem Case Study
17
Using Traditional Routing Protocols

• Routers flood information to learn topology
• Determine next hop to reach other routers
• Compute shortest paths based on link weights
• Link weights configured by network operator

18
Approaches for Setting the Link Weights

• Conventional static heuristics
• Proportional to physical distance
• Cross-country links have higher weights
• Minimizes end-to-end propagation delay
• Inversely proportional to link capacity
• Smaller weights for higher-bandwidth links
• Attracts more traffic to links with more capacity
• Tune the weights based on the offered traffic
• Network-wide optimization of the link weights
• Directly minimize metrics like max link
  utilization

19
Example of Tuning the Link Weights

• Problem congestion along the pink path
• Second or third link on the path is overloaded
• Solution move some traffic to the bottom path
• E.g., by decreasing the weight of the second link

2
1
3
1
3
2
3
1
5
4
3
20
Measure, Model, and Control
Network-wide what if model
Offered traffic
Changes to the network
Topology/ Configuration
measure
control
Operational network
21
Traffic Engineering Problem

• Topology
• Connectivity and capacity of routers and links
• Traffic matrix
• Offered load between points in the network
• Link weights
• Configurable parameters for routing protocol
• Performance objective
• Balanced load, low latency, service level
  agreements
• Question Given the topology and traffic matrix,
  which link weights should be used?

22
Key Ingredients of the Approach

• Instrumentation
• Topology monitoring of the routing protocols
• Traffic matrix fine-grained traffic measurement
• Network-wide models
• Representations of topology and traffic
• What-if models of shortest-path routing
• Network optimization
• Efficient algorithms to find good configurations
• Operational experience to identify key
  constraints

23
Formalizing the Optimization Problem

• Input graph G(R,L)
• R is the set of routers
• L is the set of unidirectional links
• cl is the capacity of link l
• Input traffic matrix
• Mi,j is load from router i to j
• Output setting of the link weights
• wl is weight on unidirectional link l
• Pi,j,l is fraction of traffic from i to j
  traversing link l

24
Multiple Shortest Paths Even Splitting
Values of Pi,j,l
25
Defining the Objective Function

• Computing the link utilization
• Link load ul Si,j Mi,j Pi,j,l
• Utilization ul/cl
• Objective functions
• min (maxl(ul/cl))
• min(Sl f(ul/cl))

26
Complexity of the Optimization Problem

• Computationally intractable problem
• No efficient algorithm to find the link weights
• Even for simple objective functions
• What are the implications?
• Must resort to searching through weight settings

27
Optimization Based on Local Search

• Start with an initial setting of the link weights
• E.g., same integer weight on every link
• E.g., weights inversely proportional to capacity
• E.g., existing weights in the operational network
• Compute the objective function
• Compute the all-pairs shortest paths to get
  Pi,j,l
• Apply the traffic matrix Mi,j to get link loads
  ul
• Evaluate the objective function from the ul/cl
• Generate a new setting of the link weights

repeat
28
Making the Search Efficient

• Avoid repeating the same weight setting
• Keep track of past values of the weight setting
• or keep a small signature of past values
• Do not evaluate setting if signatures match
• Avoid computing shortest paths from scratch
• Explore settings that changes just one weight
• Apply fast incremental shortest-path algorithms
• Limit number of unique link-weight values
• Dont explore 216 possible values for each weight
• Stop early, before exploring all settings

29
Incorporating Operational Realities

• Minimize number of changes to the network
• Changing just 1 or 2 link weights is often enough
• Tolerate failure of network equipment
• Weights usually remain good after failure
• or can be fixed by changing 1-2 weights
• Limit effects of measurement accuracy
• Good weights remain good, despite noise
• Limit frequency of changes to the weights
• Joint optimization for day night traffic
  matrices

30
Application to ATTs Backbone

• Performance of the optimized weights
• Search finds a good solution within a few minutes
• Much better than link capacity or physical
  distance
• Competitive with multi-commodity flow solution
• How ATT changes the link weights
• Maintenance every night from midnight to 6am
• Predict effects of removing link(s) from network
• Reoptimize the link weights to avoid congestion
• Configure new weights before disabling equipment

31
Example from ATTs Operations Center

• Amtrak repairing/moving part of train track
• Need to move some of the fiber optic cables
• Or, heightened risk of the cables being cut
• Amtrak notifies ATT the timework will be done
• ATT engineers model the effects
• Determine which IP links go over affected fiber
• Pretend the network no longer has these links
• Evaluate the new shortest paths and traffic flow
• Identify whether link loads will be too high

32
Example Continued

• If load will be too high
• Reoptimize the weights on the remaining links
• Schedule time for new weights to be configured
• Roll back to old weights when Amtrak is done
• Same process applied to other cases
• Assessing the networks risk to possible failures
• Planning for maintenance of existing equipment
• Adapting link weights to installation of new
  links
• Adapting link weights in response to traffic
  shifts

33
What About Interdomain Routing?

• Border Gateway Protocol
• Announcements carry very limited information
• E.g., AS path, but nothing about delay, loss,
  etc.
• Challenging to make load-sensitive protocol
• Hard to agree upon a common metric
• Hard to scale to such a large network
• Hard to prevent ASes from gaming the system
• Instead, individual ASes act alone
• Change routing policies based on link load
• E.g., moving some traffic to another provider

34
Interdomain Traffic Engineering

• Predict effects of changes to import policies
• Inputs routing, traffic, and configuration data
• Outputs flow of traffic through the network

BGP policy configuration
Topology
Externally learned routes
BGP routing model
Offered traffic
Flow of traffic through the network
35
Outbound Traffic Pick a BGP Route

• Easier to control than inbound traffic
• IP routing is destination based
• Sender determines where the packets go
• Control only by selecting the next hop
• Border router can pick the next-hop AS
• Cannot control selection of the entire path

Provider 1
Provider 2
(1, 3, 4)
(2, 7, 8, 4)
36
Outbound Traffic Shortest AS Path

• No import policy on border router
• Pick route with shortest AS path
• Arbitrary tie break (e.g., smallest router-id)
• Performance?
• Shortest AS path is not necessarily best
• Could have high delays or congestion
• Load balancing?
• Could lead to uneven split in traffic
• E.g., one provider with shorter paths
• E.g., too many ties with skewed tie-break

37
Outbound Traffic Load Balancing

• Selectively use each provider
• Assign local-pref across destination prefixes
• Change the local-pref assignments over time
• Useful inputs to load balancing
• End-to-end path performance data
• E.g., active measurements along each path
• Outbound traffic statistics per destination
  prefix
• E.g., packet monitors or router-level support
• Link capacity to each provider
• Billing model of each provider

38
Balancing Load, Performance, and Cost

• Balance traffic based on link capacity
• Measure outbound traffic per prefix
• Select provider per prefix for even load
  splitting
• But, might lead to poor performance and high bill
• Balance traffic based on performance
• Select provider with best performance per prefix
• But, might lead to congestion and a high bill
• Balance traffic based on financial cost
• Select provider per prefix over time to minimize
  the total financial cost
• But, might lead to bad performance

39
A Fundamental Problem

• Everyone is acting alone
• Internet is highly decentralized
• Each AS is adapting its routes alone
• Toward greater coordination
• End hosts or edge routers pick the entire path?
• Neighbor ASes cooperate to pick better paths?
• A largely unsolved problem
• The price of anarchy
• Is there a better way?

40
Conclusions

• Adapting routing to the traffic
• To alleviate congestion
• To minimize propagation delay
• To be robust to future failures
• Two main approaches
• Load-sensitive routing protocol
• Optimization of configurable parameters
• Next class Overlay Networks
• Read Section 9.4 of the textbook
