DSPs for future wireless systems

1
DSPs for future wireless systems

• Sridhar Rajagopal

2
Motivation
Baseband
Programmable
A/D
Wireless Mobile
RF Unit
D/A
device
Communications
Processor
Higher Layers
Add-on PCMCIA Network Interface Card

• Mobile Switch between standards and between
  parameters
• Base-station varying number of users with
  different parameters

3
The problem
4
An approach for the solution

• Algorithms well understood at VLSI level
• Can design real-time systems.
• Pushing it higher in the chain
• Current DSPs not powerful enough for our
  application
• Using the IMAGINE simulator to see what kind of
  architecture features would be useful in a future
  DSP for such applications.

5
History of my work
Multiuser channel estimation Multiuser detection
Distant Past
Algorithms
VLSI
Task-partitioning Parallelism Pipelining
FPGA
Recent Past
Conventional arithmetic On-line arithmetic
DSP
Instruction set extensions Co-processor
support Functional unit design and usage
Recent and Near Future
IMAGINE
6
Contents

• Programmable architecture design using the
  IMAGINE simulator
• Multiuser estimation and detection implementation
• Performance comparisons and results
• Other extensions for possible integration
• Conclusions

7
The IMAGINE architecture and simulator

• IMAGINE is a media signal processor

8
Why the IMAGINE simulator?

• Great for media processing algorithms
• Has a VLIW-based cluster -- DSP comparisons
• A good base architecture 1024-pt FFT
• RSIM, SimpleScalar more general purpose
  architecture simulators

9
What does the simulator give us?

• Execution time for the different parts of the
  code
• Functional unit utilization
• Insights into the bottlenecks
• Flexibility to add and remove functional units
  already present or design your own
• Graphical view of the schedule on the functional
  units

10
Down-side

• 2 level C programming
• StreamC
• transfers streams of data between main memory and
  stream register file (SRF)
• KernelC
• transfers streams from the SRF to the ALU
  clusters
• Code optimized to the number of ALU clusters and
  the size of the data
• Compiler may fail register allocation if too many
  variables or functional units modified

11
Contents

• Programmable architecture design using the
  IMAGINE simulator
• Multiuser estimation and detection implementation
• Performance comparisons and results
• Other extensions for possible integration
• Conclusions

12
Typical workload representation (Base-station)

• Equalization
• FFT
• Viterbi decoding
• Channel estimation
• Multiuser detection
• Viterbi/Turbo decoding
• Multiple antennas
• Long spreading codes
• Space-Time codes

Wireless LAN
W-CDMA
If you felt that life was too easy
13
Estimation/Detection (64,32 sizes)
Multiuser Estimation Kernel 1,2,3
Massaging matrices for detection Kernel 4, 5
Multiuser Detection Kernel 6, 7
14
Kernels

• 1. Update Update Rbb, Rbr
• 2. Mmult multiply Rbb A
• 3. Iterate gradient descent
• 4. MmultL Calculate L
• 5. MmultC Calculate C
• 6. Mf Matched Filter
• 7. Pic 1 Parallel Interference Cancellation
  Stage

15
Kernel 2 (mmult) for 3 ,2Divider not being
utilizedAdders have limited FU
utilizationO(N3) , O(N3) Multipliers 100
in loopReplace / with
16
Kernel 2 (mmult)for 3 ,3better adder
utilization needs sufficient registers for
scaling register allocation may failcode may
also need slight tuning of variables for
optimization
17
Contents

• Programmable architecture design using the
  IMAGINE simulator
• Multiuser estimation and detection implementation
• Performance comparisons and results
• Other extensions for possible integration
• Conclusions

18
FU utilization on each cluster
Time for detection at 128 Kbps for each of 32
users at 500 MHz 4000 cycles
19
Comparisons with DSPs
-2
10
-3
10
-4
10
Execution time (in seconds)
X
-5
10
Single DSP implementation
2 DSP implementation
Target data rate - 128 Kbps/user
x
Our architecture based on Imagine
-6
10
0
5
10
15
20
25
30
35
Users
20
Current work

• Evaluating performance of wireless communication
  algorithms such as estimation, detection and
  decoding on this architecture
• Studying bottlenecks, functional unit design
  needed to attain real-time
• The insights gained from the design can also be
  applied to other processors such as DSPs.
