OGSA-DAI data access and integration

1
OGSA-DAIdata access and integration

• NERC GridGIS workshop
• eSI, 1 February 2006

2
Overview

• The Data Deluge
• challenges of increasing data availability
• benefits of bringing data together
• OGSA-DAI
• overview
• use as a data integration base layer

3
The Data Deluge

• Entering an age of data
• Data Explosion
• CERN LHC will generate 1GB/s 10PB/y
• VLBA (NRAO) generates 1GB/s today
• Pixar generate 100 TB/Movie
• Storage getting cheaper
• Data stored in many different ways
• Data resources
• Relational databases
• XML databases / files
• Result files
• Need ways to facilitate
• Data discovery
• Data access
• Data integration
• Empower e-Business and e-Science
• The Grid is a vehicle for achieving this

4
Composing Observations in Astronomy

• No. sizes of data sets as of mid-2002,
  grouped by wavelength
• 12 waveband coverage of large areas of the
  sky
• Total about 200 TB data
• Doubling every 12 months
• Largest catalogues near 1B objects

Data and images courtesy
Alex Szalay, John Hopkins

5
Data Services motives

• Key to Integration of Scientific Methods
• Publication and sharing of results
• Primary data from observation, simulation
  experiment
• Encourages novel uses
• Allows validation of methods and derivatives
• Enables discovery by combining data collected
  independently
• Key to Large-scale Collaboration
• Economies data production, publication
  management
• Sharing cost of storage, management and curation
• Many researchers contributing increments of data
• Pooling annotation leads to rapid incremental
  publication
• Accommodates global distribution
• Data code travel faster and more cheaply
• Accommodates temporal distribution
• Researchers assemble data
• Later (other) researchers access data

6
Data Services challenges to management

• Scale
• Many sites, large collections, many uses
• Longevity
• Research requirements outlive technical decisions
• Diversity
• No one size fits all solutions will work
• Primary Data, Data Products, Meta Data,
  Administrative data,
• Many Data Resources
• Independently owned managed
• No common goals
• No common design
• Work hard for agreements on foundation types and
  ontologies
• Autonomous decisions change data, structure,
  policy,
• Geographically distributed
• and I havent even mentioned security yet!

7
Small problems

• Not just Grand Challenges!
• Also the small problems
• For instance
• What happens to data when a researcher leaves a
  team?
• How can a research leader point to popular data
  when a new researcher joins?
• How can you manage your data when you start to
  run out of local storage space?
• How do I get my data from one format/database to
  another?
• How do I combine my data with your data?
• You need to manage your data

8
What is a data service?

• An interface to a stored collection of data
• e.g. Google and Amazon
• web services
• But the data could be
• replicated
• shared
• federated
• virtual
• incomplete
• Dont care about the underlying representation
• do care about the information it represents
• Adding a service layer to existing data sources
  can improve composability

9
Examples of Data Services

• Many Data Services and applications
• Commercial databases
• Web interfaces
• Applications developed individually by groups and
  projects
• Also many places to get hold of public data
• Publications and citation servers
• Results servers
• But no such thing as a free lunch
• Things are not yet Plug and Play
• You need to expend some effort to use these
  services effectively

10
Use Cases for Data Services

• Data Filtering
• Single source producing large amounts of data
  distributed to many sites downstream
• Data Discovery
• many sources, many query entry points in a linked
  system
• Data Translation
• source to sink, conversion of data model /
  structure
• Data Federation
• many sources, linked to provide view as a single
  source
• Data Replication
• full or partial copies to improve throughput
• Data Integration (model aggregation)
• e.g. integration of time variant data, streams,
  files
• Data Integration (knowledge expansion)
• forming links between databases to increase
  knowledge

11
Trade Offs

• Speed vs completeness
• do you require the exact answer or an answer?
• Application specific vs language specific queries
• how will users interrogate a data service?
• Static system vs Dynamic Discovery
• do you actually have dynamic resources?
• Static vs Dynamic data
• READ only, READ/INSERT only, UPDATE permitted
• Static vs Dynamic queries
• optimisation over flexibility
• Intranet vs Internet
• speed over security
• Single data model versus mixed data models
• ease/speed over integration
• Queries vs Questions
• assume that we know the structure when we form
  the query

12
Requirements on Data Services?

• Common Data Model e.g. RowSet
• Common Query Language(s) e.g. XQuery, SQL
• Standard access to
• data resource schema information for schema
  mapping
• physical data resource information for
  optimisation purposes
• data resource descriptive information for
  discovery / integration
• Single, seamless security model
• Dynamic publication and discovery
• Multiple, efficient delivery methods
• Move computation towards data
• Data aggregation functionality
• Provenance information
• Replication information

13
OGSA-DAI In One Slide

• An extensible framework for data access and
  integration.
• Expose heterogeneous data resources to a grid
  through web services.
• Interact with data resources
• Queries and updates.
• Data transformation / compression
• Data delivery.
• Customise for your project using
• Additional Activities
• Client Toolkit APIs
• Data Resource handlers
• A base for higher-level services
• federation, mining, visualisation,

14
OGSA-DAI team
NeSC, Edinburgh
EPCC Team, Edinburgh
NEReSC, Newcastle
IBM Dissemination Team
IBM Development Team, Hursley
15
OGSA-DAI Design Principles I

• Efficient client-server communication
• Minimise where possible
• One request specifies multiple operations
• No unnecessary data movement
• Move computation to the data
• Utilise third-party delivery
• Apply transforms (e.g., compression)
• Build on existing standards
• Fill-in gaps where necessary
• DAIS specifications from DAIS WG at GGF

16
OGSA-DAI Design Principles II

• Do not hide underlying data model
• Users must know where to target queries
• Data virtualisation is hard
• Extensible architecture
• Modular and customisable
• e.g., to accommodate stronger security
• Extensible activity framework
• Cannot anticipate all desired functionality
• Activity unit of functionality
• Allow users to plug-in their own

17
The OGSA-DAI Framework
Application
Client Toolkit
OGSA-DAI service
Engine
SQLQuery
Activities
GZip
GridFTP
XPath
readFile
XSLT
JDBC
Data Resources
XMLDB
File
MySQL
DB2
XIndice
SWISS PROT
SQL Server
Data- bases
18
Intermediary

• Simple intermediary
• potential to accelerate development, logging, or
  filtering
• Persistent intermediary
• e.g. to allow efficient local indexing

19
Redirector, Coordinator, Network

• Allowing composition and decentralisation

20
Extensibility Example
OGSA-DAI service
Engine
SQLQuery
SQLQuery
JDBC
Multiple SQL GDS
MySQL
21
Map Retrieval Current
22
Map Retrieval Grid Prototype
23
Map Retrieval Security

• Exploit NGS infrastructure to provide secure
  access layer

EDINA
NGS Authentication
Allowed users dn
SO-OGC
OGC
ODS 1
GIS
Oracle
24
Map Retrieval Integration

• Exploit OGSA-DAI extensibility to add e.g. overlay

25
OGSA-DAI / EDINA prototyping work

• Stage 1 Using existing OGSA-DAI technology
• Stage 2 Extending OGSA-DAI

OGSA-DAI service
Input Parameters
URL
GIS Client
DeliverFrom URL
GIS Activities
Image/XML File
WMS Server
HTTP Request
HTTP Data Resource
HTTP Response
26
Core features of OGSA-DAI I

• A framework for building applications
• Supports data access, insert and update
• Relational MySQL, Oracle, DB2, SQL Server,
  Postgres
• XML Xindice, eXist
• Files CSV, BinX, EMBL, OMIM, SWISSPROT,
• Supports data delivery
• SOAP over HTTP
• FTP GridFTP
• E-mail
• Inter-service
• Supports data transformation
• XSLT
• ZIP GZIP
• Supports security
• X.509 certificate based security

27
Core features of OGSA-DAI II

• A framework for building data clients
• Client toolkit library for application developers
• A framework for developing functionality
• Extend existing activities, or implement your own
• Mix and match activities to provide functionality
  you need
• Highly-extensible
• Customise our out-of-the-box product
• Provide your own services, client-side support
  and data-related functionality
• Comprehensive documentation and tutorials
• Latest release supports GT4.0 and Axis 1.2 /
  OMII_2 using Java 1.4

28
Distributed Query Processing

• Higher level services building on OGSA-DAI
• specialised metadata extraction
• Execute queries in parallel over multiple data
  resources
• Queries mapped to algebraic expressions for
  evaluation
• Parallelism represented by partitioning queries
• Use exchange operators
• Equality based joins in current release
• supported types long, integer, string, double
  and float

29
DQP architecture
30
GridMiner Data Mediation Service

• Principles
• Tight Federation
• global (relational) schema
• Virtual integration
• leave the data where it is
• always up-to-date data
• Build on data access from OGSA-DAI
• Not bound to special architecture
• Supported data sources
• RDBMS (via JDBC), XMLDB (Xindice), CSV files
• Operators Union all and inner join
• Operators are XQuery based (using SAXON)

31
Data Integration Scenario

• Heterogeneities
• Name in A is First Last (as the target format)
• Name in C has to be combined
• Distribution
• 3 data sources
• Java based schema mapping to global schema
• types limited by WebRowSet

32
Data Integration Scenario (cont.)

• Query
• SELECT p_name FROM patient WHERE id10

Standard
to
optimized
33
caBIG

• Object-Oriented view of data
• Data types are well-defined and registered in a
  repository
• Standardized metadata facilitates discovery
• custom query language implemented as an activity

34
LEAD
35
FirstDIG

• Data mining with the First Transport Group, UK
• Example When buses are more than 10 minutes
  late there is an 82 chance that revenue drops by
  at least 10
• "The results of this exercise will revolutionise
  the way we do things in the bus industry.,
  Darren Unwin, Divisional Manager, First South
  Yorkshire.
• Client based joins, using temporary tables

OGSA-DAI
OGSA-DAI
OGSA-DAI
OGSA-DAI
OGSA-DAI Client Application
Data Mining Application
36
OGSA-DAI Challenges

• Metadata extraction
• define a common model for e.g. database schema?
• Intermediate representation
• between multiple models (relational, XML,)
• XML WebRowSet is flexible (c.f. GridMiner) but
  expansive
• DFDL and GridFTP/parallel HTTP?
• Query definition
• translation of queries
• aggregation of results
• Data transport and workflow
• workflow is typically compute driven
• Move computation to data
• mobile code activities?
• data services hosted on DBMS?

37
Contributing to OGSA-DAI

• Additional functionality
• Provide activities which implement specific
  functionality
• Provide extra client functionality
• Provide different security mechanisms
• Provide higher level components and applications
• Different levels of contributions
• Based on OGSA-DAI?
• Works with OGSA-DAI?
• Part of OGSA-DAI?

38
In the near future

• A new version of the OGSA-DAI Engine
• should look mostly the same externally
• better support for concurrency, sessions and
  monitoring
• Implementing new versions of specifications
• DAIS Specifications
• Key things that we will be addressing
• Performance
• A Security Model which can be applied across
  platforms
• Full Transactions framework, distributed
  transactions
• More data integration facilities
• Better abstraction over DBMS variation
• Application centric queries
• collaborating with other projects
• Research projects looking at
• schema mapping
• extended data resources

39
Associated Meetings and Workshops

• DIALOGUE Workshops (http//www.datagrids.org)
• Data Integration Applications Linking
  Organisations to Gain Understanding and
  Experience
• Bringing together Data Integration middleware and
  application providers with users
• Next one at NeSC 9-10th February 2006
• http//www.nesc.ac.uk/esi/events/636/
• Next Generation Distributed Data Management
  (HPDC15, Paris)
• http//www.isi.edu/annc/distributedDataWorkshop.h
  tml
• Data Management on Grids (VLDB06, Seoul)

40
Conclusions

• The benefits of trying to integrate data are
  hindered by challenges such as heterogeneity,
  scale and distribution
• A common data service layer should make data
  integration easier
• OGSA-DAI provides an extensible, data service
  based framework which makes it easier to
  implement data integration
• GIS data is amenable to integration using data
  services

41
Further information

• The OGSA-DAI Project Site
• http//www.ogsadai.org.uk
• The DAIS-WG site
• http//forge.gridforum.org/projects/dais-wg/
• OGSA-DAI Users Mailing list
• users_at_ogsadai.org.uk
• General discussion on grid DAI matters
• Formal support for OGSA-DAI releases
• http//bugs.ogsadai.org.uk/
• OGSA-DAI training courses
