Title: Unit 2 Forces and Motion


1
Unit 2 Forces and Motion
2
  • Motion
  • People walk, ride bikes, drive cars, etc. All the
    time we are dealing with motion
  • What must you know in order to describe an
    objects motion?

3
  • Motion
  • To describe motion we speak of
  • Position - Where an object is (as measured from
    some reference point)
  • Speed an objects rate of change of position (v
    d/t)
  • Acceleration an objects rate of change of
    speed (a v/t)

4
  • Speed and Velocity
  • Speed- the rate of change of the position of an
    object.
  • Speed(v) Distance (d)
  • Time (t)
  • Velocity- describes both speed and direction.

5
  • Speed and Velocity
  • Ex1 Find the speed of a car that goes 10 miles
    in 6.6 minutes.
  • Ex2 Find the speed and velocity of an airplane
    that flies 805 miles north in 2.3 hours.

6
  • Acceleration-
  • Rate of Change in velocity
  • Average Acceleration a
  • Final velocity Vf
  • Initial velocity Vi
  • Time t
  • a Vf - Vi or a ?v
  • t s t t

7
Sample Problem
  • A flower pot falls off second story windowsill.
    The flowerpots starts from rest and hits sidewalk
    1.5 seconds later with a velocity of 14.7 m/s.
    Find average acceleration
  • What are your givens?

Time 1.5 s Initial velocity 0m/s Final velocity
14.7m/s
8
Your Turn
  • Ex If you run at a rate of 6.00 km/hour, how
    far will you run in 35 seconds?
  • Ex What is the acceleration of a car that goes
    from 1.00m/s to 50.0 m/s in 1.00 minute?
  • Ex What is the acceleration of a car that goes
    from 0 mph to 60.0 mph in 6.2 seconds?

9
Acceleration requires a change in velocity
  • Can you accelerate w/o changing speed?
  • Remember maintaining same speed but changing
    direction changes velocity, thus you have
    acceleration!

10
Graphing Motion
  • You can tell a lot about an objects motion from
    looking at a graph of the motion

11
Distance vs. Time Graph
  • Speed can be determined from a distance vs. time
    graph.
  • Slope of the line is the speed.
  • What is slope?

12
Velocity vs. Time graph
  • Acceleration is equal to zero if velocity is
    constant.
  • Be sure to recognize speeding up and slowing down
    on a graph.

13
  • Slope of velocity vs. time graph is the
    acceleration.
  • Acceleration can
  • be negative.
  • See page 262

14
Momentum
  • What is momentum (P)?
  • The product of the mass and velocity of an
    object.
  • P m x v kg m/s
  • Momentum has direction, it is the same direction
    as velocity

15
  • Mass can be thought of as a measure of the amount
    of Inertia of an object.
  • Momentum - the amount of mass-motion of an
    object.
  • Momentum is used to understand what happens when
    2 objects collide.

16
  • Find the momentum of the following (watch units)
  • A 75 kg football player running at 9.4 m/s
  • A 12 lb bowling ball moving at 20 ft/s
  • A 2 ton truck moving at 40 mph
  • Can a butterfly ever have more momentum than a
    freight train?

17
Your Turn
  • A person throws a 25g rock at a velocity of
    4.9m/s in an upward direction. What is the
    momentum of the rock?
  • Calculate the time in seconds that a runner would
    take to complete a 6.00km run if he ran with an
    average velocity of 3.00 m/s.

18
Law of conservation of momentum
  • Total momentum in a
  • system is conserved.
  • If no other forces act upon two marbles when one
    is rolled into another the total momentum would
    remain unchanged.

19
The Impulse-Momentum Theorem
  • A force applied over a given time is called an
    Impulse.
  • When an impulse is applied to a body, it will
    gain or lose the same amount of momentum

20
Mechanical Forces
  • 1.) What is a Force?
  • A push or pull that changes direction, shape, or
    motion.

21
  • a.) Forces are all around us. Floors and walls
    exert forces on us.
  • Friction is the force that opposes the motion
    between two objects that are touching each other.
    ( Walking, driving, writing all require friction.)

22
Friction
  • If you roll a ball across the floor it eventually
    stops.
  • Friction is the force between two objects in
    contact.
  • What do you think friction depends on???

23
Is there another force acting on a falling object
in Earths atmosphere?
  • Air resistance-
  • Force exerted by air on a moving object.
  • Acts in the opposite direction of the motion of
    the object.

24
  • Air resistance depends on speed, size, and shape
    of the object.
  • Air resistance as speed

25
Examples of Forces
  • Result in stretching, squeezing, or bending
    matter.
  • Friction-Force that opposes the motion between
    two surfaces that are touching each other.
  • Depends on types of surfaces and forces pressing
    them together.
  • Not dependent on area in contact

26
Forces (F)
  • What changes the velocity of a body?
  • A golf club strikes a ball on a
    tee.
  • The ball then strikes a tree and changes
    direction.

27
  • Does a force always change velocity or
    direction?
  • When two forces
  • are balanced there is no net force.(tug of war)
  • Push on a wall no effect.
  • A Net force is required to change the direction
    and or velocity of a body.

28
Gravity
  • Every object in the universe exerts a force on
    other objects.
  • The more mass an object
  • has the greater the force of gravity it exerts.

29
Gravity and Weight
  • Not all forces are exerted by bodies touching one
    another.
  • Objects fall because gravity pulls them toward
    Earth.
  • Force exerted depends on
  • the objects mass.

30
  • Force of gravity that Earth exerts on an object
    is its weight.
  • The unit of weight (or any force) is the
    Newton(N).

31
  • Example
  • Earth has greater mass than moon
  • Weight on moon is 1/6 weight on Earth.
  • Mass is the same
  • Inertia is the same

32
  • Gravity also depends on the distance between
    objects.
  • As distance pull of gravity
  • example- rocket and Earth
  • double the distance and force is 1/4 X
    distance
  • 2X 1/4 3X 1/9

33
Newtons Laws
  • 1st Law-The Law of inertia
  • a.)An object will continue in a state of rest
    or uniform motion unless acted on by an
    unbalanced force.

34
  • b.) An object that is moving
  • at a constant velocity
  • continues at that velocity
  • unless a net force acts on it.
  • Golf ball- at rest until club hits it.
  • Bowling ball- continues until it strikes pins and
    back stop.

35
  • Inertia- the property of a body that resists any
    change in velocity.
  • a baseball is pitched at a
  • rate of speed that continues
  • until the catchers glove or the
  • bat contacts the ball)
  • The amount of mass an object is a measure of its
    inertia

36
  • Mass, weight, and Inertia
  • Mass - the amount of matter in an object. This
    is a constant.
  • Weight can change with the environment. We use
    a balance to mass objects, not a scale.

37
  • Remember
  • Mass is a measure of inertia
  • Greater mass means greater difficulty changing
    motion.
  • mass amount of matter in an object (kg or g)
  • The Physics Classroom

38
  • Newtons 2nd Law-
  • The Law of Acceleration
  • When a force is applied to an object it will
    accelerate with an acceleration proportional to
    the amount of the force and inversely
    proportional to the mass. F ma or aF/m

39
Units for Force (N)
  • Units for acceleration m/s2
  • Units for mass kg
  • Units for force kgm/s2
  • F ma
  • 1N1 kgm/s2

40
  • The acceleration of an object is increased as
    the amount of net force applied from outside the
    object increases.

41
  • For the same force, a small mass will have a
    greater acceleration than a larger mass.
  • F m(a)

a F/m
42
Your turn
  • An object with a mass of 27.0kg is accelerated at
    a rate of 121m/s2. What was the force applied to
    the object?
  • A force of 301.6N is applied to an object and
    results in an accelaration of 59m/s2. What is the
    mass of the object?

43
Falling Objects
  • Rate of acceleration is a constant value in a
    vacuum.
  • 9.8 m/s2
  • For a falling object
  • If F m(a) then W m(a)
  • Weight force of gravity

44
  • Terminal Velocity
  • The largest velocity
  • that can be reached
  • by a falling object.
  • An object has no net force acting on it. It
    keeps falling at a constant velocity.

45
  • Upward force of air downward force of gravity.
    Object has a constant velocity.
  • If there is no air
  • resistance
  • (i.e. moon or vacuum)
  • an object accelerates
  • until it hits the ground.

46
Weightlessness and Freefall
  • What is weightlessness?
  • An object is weightless when it is in freefall.
  • No force other than
  • gravity is acting on
  • an object in freefall
  • The Physics Classroom.

47
  • 3rd Law
  • The Law of Action Reaction
  • 1.) For every applied force, there is an equal
    force in the opposite direction.
  • 2.) Forces occur in pairs. One object exerts a
    force on another the 2nd exerts an force on
    the 1st

48
  • For every force there is an equal and opposite
    force.
  • Identifying Action and Reaction Force Pairs

49
Newtons 3rd Law
  • Why does it hurt when we kick a brick wall?
  • How does the 3rd law describe how we walk?.

50
The End
