Java

1
George Blank University Lecturer
2
Java RMI

• Introduction to RMI

3
Java and the Web

• Javas popularity is due to its suitability for
  use on the World Wide Web (WWW).
• Several Web browsers have support for Java
• Netscape Navigator
• Internet Explorer
• HotJava
• Java incorporates audio, video, and animation
  directly on the web page.

4
Method Modifiers

• Instance Methods
• Class Methods
• Abstract Methods
• Native Methods
• Final Methods

5
Method Modifiers with Effect on Scoping

• public Method can be accessed by any class
• private methods accessed only by class methods
• friendly methods accessed by other methods in
  the same package
• protected methods accessed by subclass methods.

6
Interfaces

• A Java interface is similar to a class, except
  there is no data associated with the interface.
• Example
• public interface MyInterface
• methods-with no implementation details
• final variables

7
Properties of Interfaces

• The variables in an interface must be final.
• The methods are only declarations.
• A class that extends another class is guaranteed
  to support the contracts entered into by its
  superclass.
• Interfaces are used to approximate multiple
  inheritances

8
Java Native Interface (JNI)

• The Java Native Interface (JNI) is part of the
  core JDK and provides a framework for interfacing
  to native code. The native code is not easily
  portable across different hardware platforms. So
  using native code takes way one of the major
  advantages of java. JNI was developed to bridge
  the gap.
• (JNI
  section by Rekha Telkar)

9
When to use JNI

• When the standard Java class library does not
  support the platform-dependent features needed by
  the application.
• You need to use a library written in another
  language, and wish to make it accessible to Java
  code through the JNI.
• You want to implement a small portion of
  time-critical code in a lower-level language such
  as assembly.

10
JNI Capabilities

• You can use native methods to
• Create, inspect, and update Java objects
  (including arrays and strings).
• Call Java methods.
• Catch and throw exceptions.
• Load classes and obtain class information.
• Perform runtime type checking.

11
Enabling Java code with JNI

• You can use the JNI with the Invocation API to
  enable an arbitrary native application to embed
  the Java VM. Programmers can make their existing
  applications Java-enabled without having to link
  with the VM source code.

12
Remote Method Invocation

• RMI provides the means to invoke methods
  remotely.
• RMI allows for applications to communicate and
  execute across multiple systems on a network.
• RMI is supported by the java.rmi,
  java.rmi.server, and java.rmi.registry
• Enhanced security of Java 2 requires a security
  policy implementation.

13
Parts in a RMI System

• Interface definitions for remote services
• Implementations of the remote services
• Stub and Skeleton files
• A server to host the remote services
• An RMI Naming service that allows clients to find
  the remote services
• A class file provider (an HTTP or FTP server)

14
RMI process
Not needed In Java 2
15
RMI Server, Client, and Registry

• The server process registers the remote object X
  with the registry using the Naming.bind() method.
• The client calls Naming.lookup(), which contacts
  the registry and obtains a stub object for X.
• The client then uses the stub as if it is a local
  object.

16
Stub Class

• A stub for a remote object is the client-side
  proxy for the remote object. Such a stub
  implements all the interfaces that are supported
  by the remote object implementation. The
  client-side stub responsibilities are shown on
  the next slide.

17
Stub Class Responsibilities

• Initiating a call to the remote object (by
  calling the remote reference layer).
• Marshaling arguments to a marshal stream
  (obtained from the remote reference layer).
• Informing the remote reference layer that the
  call should be invoked.
• Unmarshaling the return value or exception from a
  marshal stream.
• Informing the remote reference layer that the
  call is complete.

18
Skeleton Class

• A skeleton for a remote object is a server-side
  entity that contains a method which dispatches
  calls to the actual remote object implementation.
  The skeleton is responsible for
• Unmarshaling arguments from the marshal stream.
• Making the up-call to the actual remote object
  implementation.
• Marshaling the return value of the call or an
  exception (if one occurred) onto the marshal
  stream.

19
Remote Reference Layer

• The remote reference layer deals with the lower
  level transport interface and is responsible for
  carrying out a specific remote reference protocol
  which is independent of the client stubs and
  server skeletons. The remote reference layer has
  two cooperating components the client-side and
  the server-side components.

20
Remote Reference Layer (2)

• The client-side component contains information
  specific to the remote server (or servers, if the
  remote reference is to a replicated object) and
  communicates via the transport to the server-side
  component. During each method invocation, the
  client and server-side components perform the
  specific remote reference semantics.

21
Remote Reference Layer (3)

• For example, if a remote object is part of a
  replicated object, the client-side component can
  forward the invocation to each replica rather
  than just a single remote object.
• In a corresponding manner, the server-side
  component implements the specific remote
  reference semantics prior to delivering a remote
  method invocation to the skeleton.

22
Remote Reference Layer (4)

• For example, the server side could handle
  ensuring atomic multiple delivery by
  communicating with other servers in the replica
  group.The remote reference layer transmits data
  to the transport layer via the abstraction of a
  stream-oriented connection. The transport takes
  care of the implementation details of
  connections. Although connections present a
  streams-based interface, a connectionless
  transport may be implemented beneath the
  abstraction

23
RMI Registry

• The Registry tracks the addresses of the remote
  objects exported by applications
• It is the central management point for RMI
• Does not actually invoke remote methods
• Bind() links the object in the registry
• Rebind() replaces object with a new one

24
Parameter Passing

• When a remote procedure is executed, the java.rmi
  runtime encodes the arguments and sends them over
  the network to a server that decodes them.
• The server then invokes the method, encodes the
  results, and sends it back.
• Finally, the client-side java.rmi runtime decodes
  the result.

25
Parameter Marshalling

• RMI stubs are responsible for packaging
  parameters used in a remote method in a block of
  bytes using the big-endian byte order. This is
  called parameter marshalling. A receiver object
  on the server must unmarshall the parameters or
  report errors.

26
Building RMI Applications

• Define remote interfaces
• Create classes that implement the interfaces
• Create stub and skeleton classes for the
  implementation classes.
• Create Security Policy

27
A Distributed Hello World Program Using RMI

• It uses an applet to make a remote method call to
  the server from which it was downloaded to
  retrieve the message "Hello World!".
• When the applet runs, Hello World! is displayed
  on the client browser.

28
Steps Involved

• Write The HTML and Java Source Files.
• Compile and Deploy Class Files and HTML Files.
• Start the Remote Object Registry, Server, and
  Applet

29
Source Files

• The Java remote interface. (Hello.java)
• The Java remote object (server) which implements
  the remote interface. (HelloImpl.java)
• The Java applet that remotely invokes the remote
  method, sayHello(). (HelloApplet.java)
• The HTML code for the web page that references
  the applet. (hello.html)

30
The Remote Interface

• Must be public.
• Extends the interface java.rmi.Remote.
• Each method must declare java.rmi.RemoteException
  in its throws clause
• A remote object passed as an argument or return
  value must be declared as the remote interface.

31
Remote Interface

• package examples.hello
• import java.rmi.Remote
• import java.rmi.RemoteException
• public interface Hello extends java.rmi.Remote
• String sayHello() throws java.rmi.RemoteException


32
The Implementation Class

• Specify the remote interface(s) being
  implemented.
• Define the constructor for the remote object.
• Provide implementations for the methods that can
  be invoked remotely.
• Create and install a security manager.

33
The Implementation Class (Contd)

• Create one or more instances of a remote object.
• Register at least one of the remote objects with
  the RMI remote object registry, for bootstrapping
  purposes.

34
Server Code (1)

• package examples.hello
• import java.rmi.Naming
• import java.rmi.RemoteException
• import java.rmi.RMISecurityManager
• import java.rmi.server.UnicastRemoteObject
• public class HelloImpl extends UnicastRemoteObject
  implements Hello
• public HelloImpl() throws RemoteException
• super()

35
Server Code (2)
// Implementation of remote method public
String sayHello() return "Hello World!"
36
Server Code (3) main begins
public static void main(String args) //
Create and install a security manager if
(System.getSecurityManager() null)
System.setSecurityManager(new RMISecurityManager(
))
37
Server Code (4) main ends
try HelloImpl obj new HelloImpl() // Bind
this object instance to the name "HelloServer"
Naming.rebind("//afsxx.njit.edu/HelloServer",
obj) System.out.println("HelloServer bound in
registry") catch (Exception e)
System.out.println("HelloImpl err "
e.getMessage()) e.printStackTrace()
38
Notes on Server Code

• By extending remote class UnicastRemoteObject,
  the HelloImpl class can be used to create a
  remote object that
• Uses RMI's default sockets-based transport for
  communication
• Runs all the time (In Java 2 SDK, the object can
  be activated (created) when a client requests it,
  using Remote Object Activation, rather than
  running all the time extend java.rmi.activation.
  Activatable)
• To bind to a different port, for example 2001,
  use
• Naming.rebind("//afsxx.njit.edu2001/HelloServer"
  , obj)

39
Notes on Server Code (contd)

• Arguments to, or return values from, remote
  methods can be any data type for the Java
  platform, including objects, as long as those
  objects implement the interface
  java.io.Serializable.
• By default, local objects are passed by copy,
  which means that all data members (or fields) of
  an object are copied, except those marked as
  static or transient
• Remote objects are passed by reference. A
  reference to a remote object is actually a
  reference to a stub, which is a client-side proxy
  for the remote object.

40
Notes on Server Code (contd)

• Security manager guarantees that the classes that
  get loaded perform only allowed operations.
• If no security manager is specified, no class
  loading, by RMI clients or servers, is allowed,
  aside from what can be found in the local
  CLASSPATH.
• Client Applets use the security manager already
  installed in the client browser.
• If the client were an application rather than an
  applet, Security manager would need to be
  installed.
• A security manager is required in any JVM that
  needs to download code, and RMI clients need to
  download RMI stubs (as well as any other custom
  classes or interfaces needed to communicate with
  the RMI server).

41
A Remote Service Applet
package examples.hello import
java.applet.Applet import java.awt.Graphics
import java.rmi.Naming import
java.rmi.RemoteException public class
HelloApplet extends Applet String message
"" // "obj" is the identifier that we'll use
// to refer to the remote object that //
implements the "Hello" interface Hello obj
null
42
Remote Applet Code (2)
public void init() try Hello obj
(Hello)Naming.lookup("//"
getCodeBase().getHost() "/HelloServer")
message obj.sayHello() catch
(Exception e) System.out.println("Applet
exception " e.getMessage())
e.printStackTrace()
43
Remote Applet Code (3)
public void paint(Graphics g)
g.drawString(message, 25, 50)
44
Notes on Client Applet

• The applet gets a reference to the remote object
  implementation (advertised as "HelloServer") from
  the server host's rmiregistry.
• The applet invokes the remote sayHello method on
  the server's remote object.
• The applet invokes the paint method, causing the
  string "Hello World!" to be displayed in the
  drawing area of the applet.

45
The Web Page (hello.html)
ltHTMLgt lttitlegtHello Worldlt/titlegt ltcentergt
lth1gtHello Worldlt/h1gt lt/centergt ltpgt ltapplet
codebase"myclasses/ " code"examples.hell
o.HelloApplet" width500
height120gt lt/appletgt lt/HTMLgt
46
Compiling the Java Source Code

• Create a directory myclasses in your public_html
  on AFS and compile the java code
• javac -d HOME/public_html/myclasses
• Hello.java HelloImpl.java HelloApplet.java

47
Generate Stubs and Skeletons
rmic -d HOME/public_html/myclasses
examples.hello.HelloImpl The following files are
created in the directory HOME/public_html/mycla
sses/examples/hello HelloImpl_Stub.class
HelloImpl_Skel.class (before Java 2 only)
48
Java 2 SDK Stubs

• In the Java 2 SDK implementation of RMI, skeleton
  classes are obsolete. RMI uses reflection to make
  the connection to the remote service object.
• If you will never need support for 1.1 clients,
  rmic can be run with the -v1.2 option
• rmic v1.2 -d HOME/public_html/myclasses
  examples.hello.HelloImpl
• This creates only
• HelloImpl_Stub.class

49
Deploying Applet (1)

• Move the HTML File (hello.html) to the Deployment
  Directory
• HOME/public_html/

50
Sample Policy File for User (.java.policy) in
HOME

• grant
• permission java.net.SocketPermission
  "1024-65535","connect,accept"
• permission java.net.SocketPermission "80",
  "connect"
• Replace with name or IP of client to restrict
  access

51
Security Policy

• In a Unix environment, you will probably need to
  create a Security Policy for the Client
  Application but not for an applet. The default
  policy might work in Windows.
• To create a security policy, see a Java text
  book. Just Java 2, pages 351-368, gives an
  explanation. Some students have expressed a
  preference for the explanation in Core Java 2.

52
Start the Remote Object Registry

• The RMI registry is a simple server-side
  bootstrap name server that allows remote clients
  to get a reference to a remote object.
• Start registry on server - UNIX
• rmiregistry
• Windows
• start rmiregistry
• To start on a port other than the default 1099,
  for example port 2001
• rmiregistry 2001

53
Starting the Server

• java  -Djava.rmi.server.codebasehttp//afsxx.nji
  t.edu/username/myclasses/  -Djava.security.policy
  HOME/.java.policy  examples.hello.HelloImpl
• The output should look like this
• HelloServer bound in registry

54
Starting the Server

• When starting the server, the java.rmi.server.code
  base property must be specified, so that the stub
  class can be dynamically downloaded to the
  registry and then to the client.
• Run the server, setting the codebase property to
  be the location of the implementation stubs.
  Because the codebase property in this example
  references a directory, make sure that any other
  classes that may need to be downloaded have also
  been installed in the directory referenced by
  java.rmi.server.codebase

55
Starting the Server

• Note A stub class is dynamically downloaded to a
  client's virtual machine only when the class is
  not already available locally and the
  java.rmi.server.codebase property has been set
  properly to specify where the class files are
  located on the server.
• You can also specify the java.security.policy
  property for the server to set permissions.

56
Common Exception

• If you forget the trailing slash on the codebase
  property, or if the class files can't be located
  at the source (they aren't really being made
  available for download) or if you misspell the
  property name, you'll get thrown a
  java.lang.ClassNotFoundException.
• You will also need to use a VPN if you access the
  RMI server from off-campus because AFS security
  does not allow remote connections from unsigned
  applets. Otherwise you will get a
  Java.rmi.ConnectException

57
Running the Applet

• appletviewer http//afsxx.njit.edu/usrnam
  e/hello.html
• Or use the Browser URL
• http//afsxx.njit.edu/usrname/hello.html
• String Hello World should display.
• Note The Applet sandbox allows them to connect
  only to their host URL. Therefore, the AFS
  hostname should be of the AFS machine on which
  the RMI server is running.

58
Output
Browser Note Use web.njit.edu, not afsxx as
shown. That will not work as Web server access to
AFS is now disabled.
Appletviewer
59
Advantages of RMI

• Object-Oriented
• Safe and Secure
• Easy to Write/Easy to Use
• Connects to Existing/Legacy Systems (JNI)
• Write Once, Run Anywhere
• Distributed Garbage Collection
• Parallel Computing

60
Garbage Collection

• The Java Virtual Machine has an automatic garbage
  collector that will reclaim the memory from any
  object that has been discarded by the running
  program. Garbage collection is difficult if the
  server and client run on different machines. The
  RMI subsystem implements a reference
  counting-based distributed garbage collection
  (DGC) algorithm to provide automatic memory
  management facilities for remote server objects.

61
How DGC works

• The remote server keeps track of all external
  client references. When a reference is made, the
  server increases the object reference count by
  one and marks the object as "dirty". When a
  client drops the reference, the DGC decreases its
  reference count by one and marks the object as
  "clean." When the reference count reaches zero,
  the remote object is free of any live client
  references. It is then placed on the weak
  reference list and subject to periodic garbage
  collection.

62
RMI Limitations

• RMI is not full featured middleware
• No mechanism for object description
• No server events
• Java only, not language independent
• Firewalls are not supported
• Naming service is not persistent
• No load balancing

63
Example

• Users fill in the fields of an expense report.
  Clients communicate with the server using RMI.
  The server stores the expense reports in a
  database using JDBC.

64
Remote Interface

• import java.rmi.
• public interface ExpenseServer extends Remote
• Policy getPolicy() throws RemoteException
• void submitReport(ExpenseReport report)
• throws RemoteException,
• InvalidReportException

65
The Policy Interface

• public interface Policy
• void checkValid(ExpenseEntry entry)
• throws PolicyViolationException

66
Client Code
Policy curPolicy server.getPolicy()
while (user keeps adding entries)
try
curPolicy.checkValid(entry) //
throws exception if not OK
add the entry to the expense report
catch (PolicyViolationException e)
show the error to the user

server.submitReport(report)
67
Server Code (1)
import java.rmi. import java.rmi.server. class
ExpenseServerImpl extends UnicastRemoteObject
implements ExpenseServer
68
Server Code (2)
ExpenseServerImpl() throws RemoteException
// ...set up server state...
public Policy getPolicy()
return new TodaysPolicy()
public void submitReport(ExpenseReport report)
// ...write the report
into the db...
69
Implementing a Policy
public class TodaysPolicy implements Policy
public void checkValid(ExpenseEntry entry)
throws PolicyViolationException
if (entry.dollars() lt 20)
return // no receipt
required throw new
PolicyViolationException( "Need a
receipt")
70
New Policy Implementation
public class TomorrowsPolicy implements Policy
public void checkValid(ExpenseEntry entry)
throws PolicyViolationException
if (entry.isMeal()
entry.dollars() lt 20)
return // no receipt
required throw new
PolicyViolationException( "Need a
receipt")
71
Summary

• Java RMI is a distributed object model for the
  Java platform.
• RMI extends the Java object model beyond a single
  virtual machine address space.
• RMI uses object serialization to convert object
  graphs to byte streams for transport.

72
Defining Interfaces

• All methods that can be run remotely must be
  declared as part of an interface that extends
  Remote .
• public interface RemOp extends Remote
• public void call() throws RemoteException

73
Creating Classes that Implement the Interfaces

• Classes that implement the remote interfaces must
  be subclasses of the RemoteObject class.
• RemoteObject provides support for the hashCode(),
  equals(), and toString().

74
Interface Class Example (1)
package rmi1 import java.rmi. import
java.rmi.server.
75
Interface Class Example (2)
public class RemImpl extends UnicastRemoteServer i
mplements RemoOp public static void
main(String args) System.setSecurityManage
r( new StubSecurityManager()) try
Naming.rebind(operator, new RemImpl())
catch (Exception x) x.printStackTrace()
return
76
Interface Class Example (3)
public RemImpl() throws RemoteException
public void call() throws RemoteException
System.out.println(getName())
System.out.println(Location
System.getProperty(LOCATION))
77
Interface Class Example (4)
public String getName() return Remote
operation hashCode()
78
Interface Class Example (5)
package rmi1 import java.rmi. import
java.rmi.server.
79
Interface Class Example (6)
public class OpTest public static void
main(String args) System.setSecurityMana
ger( new StubSecurityManager()) try
RemOp ro (RemOp) Naming.lookup(operator
) ro.call() catch (Exception x)
x.printStackTrace() System.exit(-1)
80
Running the rmi1 Example

• java java.rmi.registry.RegistryImpl
• java -DLOCATIONserver rmi1.RemImpl
• java -DLOCATIONclient rmi1.OpTest
• Output
• Remote operation 841549921
• Location server

81
RMI Security

• One of the most common problems encountered with
  RMI is a failure due to security constraints.
• The security policy can be set by constructing a
  SecurityManager object and calling the
  setSecurityManager method of the System class.
• The SecurityManager class has a large number of
  methods whose name begins with check. For
  example, checkConnect (String host, int port).

82
Security Continued

• If the current security policy does not allow
  connection to this host and port, then the call
  throws an exception. This usually causes the
  program to terminate with a message such as
• java.security.AccessControlException access
  denied
• (java.net.SocketPermission 127.0.0.11099
  connect,resolve)

83
Java-RMI vs. CORBA and DCOM

• Java-RMI is a Java-specific middleware spec that
  allows client Java programs to invoke server Java
  objects as if they were local.
• Java-RMI is tightly coupled with the Java
  language.

84
Comparison Continued

• Since Java-RMI is tightly coupled with The Java
  Language, Java-RMI can work with true
  sub-classes.
• Because of this, parameters passed during method
  calls between machines can be true Java Objects.
  This is impossible in DCOM or CORBA at present.

85
Comparison Continued

• If a process in an RMI system receives an object
  of a class that it has never seen before, it can
  request that its class information be sent over
  the network.
• Over and above all this, Java-RMI supports
  Distributed Garbage Collection that ties into the
  local Garbage Collectors in each JVM.

86
Trouble Shooting

• If a JVM that is exporting remote objects does
  not have the java.rmi.server.codebase property
  set correctly, you will get a class not found
  error.
• Default port for RMI RegistryImpl is 1099. If it
  is already in use, you will get a
• java.net.SocketException Address already
  in use.
• Do not try to use the loopback address, 127.0.0.1
  improperly. It does not work on a network.
• RMI is subject to Connection Exceptions that are
  idiosyncratic and difficult to overcome. This is
  one of the most common topics in RMI discussions.

87
Problems Encountered

• A java.rmi.NotBoundException was overcome by
  bypassing the start command and starting the
  server directly. This is not recommended, as the
  program will not exit normally. NOTE A probable
  cause is another version of Java on the system
  that is referenced by the start command.
• Several java.rmi.UnmarshallException were caused
  by classes not in the class path. Some students
  just had to add the current directory
• set classpath.classpath

88
Problems Encountered

• An Incompatible Type Exception error occurred
  when a group failed to cast a returned reference
  to the ltClassNamegt_stub type.
• A java.security.AccessControlException required
  creating a policy file and referencing it as
• java -Djava.security.policyc\rmi.policy
  ltYourClient./ltYourServergt
• Dont overlook standard programming errors like
  syntax errors, missing try blocks, and naming and
  typing mistakes.

89
Hints

• When you have a problem, you may have to kill all
  your processes and restart everything.
• You must start the registry (Windows command)
• start rmiregistrystart
• All remote interfaces must extend
  java.rmi.RemoteInterface, and all remote objects
  must extend java.rmi.UnicastRemoteObject.
• Security management and implementing class
  policies are complex and difficult in RMI. The
  client policy file permits connection to a
  specific referenced port number.

90
Lessons Learned

• You can get a trace of the server activity using
• java -Djava.rmi.server.logCallstrue
  ltYourServergt
• Properties beginning java.rmi. are part of
  published RMI spec and docs, while sun.rmi.
  indicates things that may vary.
• You can find the host name of a caller of a
  remote method with
• java.rmi.server.RemoteServer.getClientHost
• On a server with multiple host names, you need to
  force a fully qualified host name with
• java.rmi.server.useLocalHostnametrue

91
Environment Conflicts

• If you may have multiple versions of Java on your
  system, try java -version to see which version
  your environment defaults to. Remember that
  different versions seldom work together, and that
  your Windows autoexec.bat file may set some
  environment values that you might not think about.

92
Good RMI explanation

• The example from the Sun Web site is difficult to
  get working, because it includes a lot of
  material that goes beyond the basics. You may
  wish to find a simpler example. One excellent
  one was at
• http//www.ccs.neu.edu/home/kenb/com3337/rmi_tut.h
  tml

93
RMI Versions

• Java 2 SDK, version 1.4 adds server-side stack
  trace retention, Service Provider Interface for
  RMIClassLoader and Dynamic Server Host Name.
• Java 2 SDK, version 1.3 adds enhancements to
  serialization
• Java 2 SDK, version 1.2 adds activation, the use
  of custom socket protocols and security policies.
• Java 1.1 added core RMI support, but usually
  requires running applets in the applet viewer.
• Java 1.0.2 was an interim release, and should not
  be used for RMI.

94
References

• http//java.sun.com/j2se/1.4.2/docs/guide/rmi/gets
  tart.doc.html
• http//developer.java.sun.com/developer/onlineTrai
  ning/rmi/RMI.html
• http//java.sun.com/j2se/1.4/docs/relnotes/feature
  s.html
• http//java.sun.com/marketing/collateral/javarmi.h
  tml
