CAP 5415 Computer Vision Fall 2004

1
CAP 5415 Computer VisionFall 2004

• Dr. Alper Yilmaz
• Univ. of Central Florida
• www.cs.ucf.edu/courses/cap5415/fall2004
• Office CSB 250

2
RecapEstimation of Camera Parameters

• Relation between camera and image coordinates

(A)
(B)

• Estimate rij,ti,ox,oy,fx,fy.

3
RecapEstimation of Camera Parameters

• Given corresponding world and image points
• Divide (A) to (B), rearrange result

(C)

• Rearrange into matrix and solve using SVD
• Estimate scale factor ? r2i and ty are there!!
• Compute ? similar to scale factor
• Compute r3i from r1i and r2i .
• Estimate fx , fy and ty .
• Finally compute ox and oy from other knowns

4
RecapRotation around arbitrary axis
5
RecapRotation around arbitrary axis
6
Images
7
General

• Binary
• Gray Scale
• Color

8
Binary Images
Y
1
1
1
1
Row 1
q
X
0 Black 1 White
0
0
0
0
0
Row q
p
9
Gray Level Image
10
5
9
100
10
Gray Scale Image
11
Color ImageRed, Green, Blue Channels
12
Image Histogram
13
Image Noise

• Light Variations
• Camera Electronics
• Surface Reflectance
• Lens

14
Image Noise

• I(x,y) the true pixel values
• n(x,y) the noise at pixel (x,y)

?
15
Gaussian Noise
16
Salt Pepper Noise

• p is uniformly distributed random variable
• l is threshold
• smin and smin are constant

17
Image Derivatives Averages
18
Definitions

• Derivative Rate of change
• Speed is a rate of change of a distance
• Acceleration is a rate of change of speed
• Average (Mean)
• Dividing the sum of N values by N

19
Derivative
20
Examples
21
Discrete Derivative
22
Discrete DerivativeFinite Difference
Backward difference
Forward difference
Central difference
23
Example
Derivative Masks
Backward difference
-1 1
1 -1
Forward difference
-1 0 1
Central difference
24
Derivatives in 2 Dimensions
Given function
Gradient vector
Gradient magnitude
Gradient direction
25
Derivatives of Images
Derivative masks
26
Derivatives of Images
27
Convolution
f
h
x
x
28
Averages

• Mean

• Weighted mean

29
Gaussian Filter
30
Properties of Gaussian

• Most common natural model
• Smooth function, it has infinite number of
  derivatives
• Fourier Transform of Gaussian is Gaussian.
• Convolution of a Gaussian with itself is a
  Gaussian.
• There are cells in eye that perform Gaussian
  filtering.
