Title: Introduction to SQA


1
CHAPTER 1
  • Introduction to SQA

2
Learning Objectives
  • To discuss
  • Overview of Software Quality
  • Definitions and Objectives of SQA
  • Software quality factors

3
Overview of Software Quality
  • Software is (IEEE)
  • Computer program, procedures and possibly
    associated documentation and data pertaining to
    the operation of a computer system.
  • Identical to ISO, list the following components
  • Computer program (code)
  • Procedures
  • Data necessary for operating the software system.

4
Software errors, faults and failures
  • Software error?
  • Software faults?
  • Software failures?

5
Software errors, faults and failures
  • Software error coding error, logical error ?
    mistake made by people.
  • Software faults result of error.
  • Software failures occurs when fault execute.

6
Classification of the causes of software errors
  • Faulty definition of requirement
  • Client-developer communication failures
  • Deliberate deviations from software requirements
  • Logical design errors
  • Coding errors
  • Non-compliance with documentation and coding
    instructions
  • Shortcomings of the testing process
  • Procedure errors
  • Documentation errors

7
Quality
  • Popular view
  • an intangible traitit can be discussed, felt,
    and judged, but cannot be weighed or measured.
  • "I know it when I see it."
  • quality connotes luxury, class, and taste.
  • Expensive, elaborate, and more complex products
    are regarded as offering a higher level of
    quality than their humbler counterparts.
  • a Cadillac is a quality car, but a Chevrolet is
    not, regardless of reliability and repair
    records or, a surround-sound hi-fi system is a
    quality system, but a single-speaker radio is
    not. According to this view, quality is
    restricted to a limited class of expensive
    products with sophisticated functionality and
    items that have a touch of class.
  • ? inexpensive products can hardly be classified
    as quality products. (?)

8
Quality
  • Professional view
  • Crosby (1979) defines quality as "conformance to
    requirements.
  • implies that requirements must be clearly stated
    such that they cannot be misunderstood.
  • Then, in the development and production process,
    measurements are taken regularly to determine
    conformance to those requirements.
  • The non-conformances are regarded as defectsthe
    absence of quality.

9
Quality
  • Juran and Gryna (1970) define it as "fitness for
    use.
  • takes customers' requirements and expectations
    into account, which involve whether the products
    or services fit their uses.
  • Since different customers may use the products in
    different ways, it means that products must
    possess multiple elements of fitness for use.
  • According to Juran, each of these elements is a
    quality characteristic and all of them can be
    classified into categories known as parameters
    for fitness for use.
  • The two most important parameters are quality of
    design and quality of conformance.

10
Quality
  • quality of conformance is concerned with
    implementation,
  • quality of design measures how valid the design
    and requirements are in creating a worthwhile
    product (Pressman, 2005).

11
Software Quality IEEE Definition
  • Software quality is
  • The degree to which a system, component, or
    process meets specified requirements.
  • The degree to which a system, component, or
    process meets customer or user needs or
    expectations.

12
Software Quality Pressmans Definition
  • Software quality is defined as
  • Conformance to explicitly stated functional and
    performance requirements, explicitly documented
    development standards, and implicit
    characteristics that are expected of all
    professionally developed software.

13
Software Quality Pressmans Definition
  • 3 requirements for quality
  • Specific functional requirements ? output of the
    software system
  • The software quality standards mentioned in the
    contract
  • Good Software Engineering Practices (GSEP), to be
    met by the developer even though not explicitly
    mentioned in the contract.

14
Definition and Objectives of SQA
  • SQA (IEEE definition) is
  • A planned and systematic pattern of all actions
    necessary to provide adequate confidence that an
    item or product conforms to established technical
    requirements.
  • A set of activities designed to evaluate the
    process by which the products are developed or
    manufactured. Contrast with quality control.

15
Derived from SQA definition by IEEE
  • Plan and implement systematically.
  • Refer to the software development process.
  • Refer to the specifications of the technical
    requirements.

16
SQA Extended definition
  • SQA is
  • A systematic, planned set of actions necessary to
    provide adequate confidence that the software
    development process or the maintenance process of
    a software system product conforms to established
    functional technical requirements as well as with
    the managerial requirements of keeping the
    schedule and operating within the budgetary
    confines. ? see attachment.

17
The Objectives of SQA
  • Software development (process-oriented)
  • Acceptable level of confidence that the software
    will conform to functional technical
    requirements.
  • Acceptable level of confidence that the software
    will conform to managerial scheduling and
    budgetary requirements.
  • Initiating and managing of activities for the
    improvement and greater efficiency of software
    development and SQA activities.

18
Objectives of SQA (cont..)
  • Software maintenance (product-oriented)
  • Acceptable level of confidence that the software
    maintenance activities will conform to the
    functional technical requirements.
  • Acceptable level of confidence that the software
    maintenance activities will conform to managerial
    scheduling and budgetary requirements.
  • Initiating and managing activities to improve and
    increase efficiency of software maintenance and
    SQA activities.

19
Software Quality Factors
  • Content
  • The need for comprehensive software quality
    requirements
  • Classifications of software requirements into
    software quality factors
  • The structure (categories and factors) of
    McCalls classic factor model
  • The additional factors
  • Those intended in defining the software quality
    requirements

20
The need for comprehension software quality
requirements
  • Many cases of low customer satisfaction are
    situations where software projects have
    satisfactorily fulfilled the basic requirements
    of correctness, while suffering from poor
    performance in other important areas such as
    maintenance, reliability, software reuse, or
    training.
  • One of the main causes lack of defined
    requirements pertaining to these aspects of
    software functionality.
  • ? need for comprehensive definition of
    requirements that will cover all aspects of
    software use throughout all stages of the
    software life cycle.

21
The structure (categories and factors)
  • McCallss factor model classifies all software
    requirements into 11 software quality factors.
  • These factors are grouped into 3 categories
  • Product operation factors correctness,
    reliability, efficiency, integrity, usability.
  • Product revision factors maintainability,
    flexibility, testability.
  • Product transition factors portability,
    reusability, interoperability.

22
Product operation software quality factors
  • Correctness required accuracy, completeness of
    the output information, etc.
  • Reliability determine maximum allowed software
    system failure rate.
  • Efficiency resources needed to perform all the
    functions of the software in conformance to all
    requirements.
  • Integrity software system security.
  • Usability scope of staff resources needed to
    operate the software system.

23
Product revision software quality factors
  • Maintainability determine the efforts needed to
    identify the reasons for failure, to correct it,
    and to verify the success of the corrections.
  • Flexibility capabilities and efforts to support
    adaptive maintenance activities.
  • Testability related to special features in the
    programs that help the testers providing
    predefined results, logfiles.

24
Product transition software quality factors
  • Portability adaptation of a software system to
    other environments hardware, OS, etc.
  • Reusability use other softwares module in a new
    project.
  • Interoperability creating interfaces with other
    software systems or with other systems.

25
Alternative models of software quality factors
  • The Evans and Marciniak factor model (Evans
    Marciniak, 1987).
  • The Deutsch and Willis factor model (Deustch
    Willis, 1988).

26
Comparison
  • Both exclude testability factors.
  • Evan Marciniak1 12 factors, classified into 3
    categories.
  • Deustch Willis2 15 factors, classified into 4
    categories.
  • 5 new factors verifiability (both),
    expandability (both), safety2, manageability2,
    survivability2.

27
Additional factors
  • Verifiability design and programming features
    that enable efficient verification of the design
    and programming.
  • Expandability future efforts to improve service,
    or add new applications to improve usability.
  • Safety eliminate condition hazardous to
    operators of equipment as a results of errors in
    process control software.
  • Manageability administrative tools that support
    software modification.
  • Survivability continuity of service.

28
Those interested in defining software quality
requirements
  • The clients requirements document
  • Assure the quality of the software product.
  • The developers additional requirements document.
  • Adding requirements that represent his own
    interests reusability, verifiability and
    portability.

29
Additional notes and reference
  • Appendix 1
  • Table 2.2 The expanded SQA definition
    comparisons with other versions (pg 27).
  • Appendix 2
  • Table 3.3 Factors and sub-factors (pg 49).
  • Galin, D. 2004. Software Quality Assurance From
    Theory to Implementation.
