Title: CS 432 Object-Oriented Analysis and Design


1
CS 432 Object-Oriented Analysis and Design
  • Week 6
  • Design Patterns
  • Architecture Designs

2
(No Transcript)
3
Design Principles-Protection From Variations
  • Parts of a system that are unlikely to change are
    segregated from those that will
  • Drives the multilayer design pattern
  • Stable business logic can be protected from
    variations in the user interface
  • Changes in the business logic are isolated to the
    controller class

4
Design Principles-Indirection
  • Indirection is an implementation of the
    protection from variations principle
  • Decouples classes or other system components by
    placing an intermediate classes between them
  • Used in many corporate security systems between
    an internal network and the Internet
  • A proxy server catches all incoming messages and
    redistributes them to the recipients

5
Importance of Design Patterns
  • Standard design templates can speed OO design
  • Patterns can exist at different levels of
    abstraction
  • At the most concrete level, a class definition
    with code
  • At the most abstract level, an approach to a
    problem
  • Patterns should contain five main elements
  • Pattern name, problem, solution, example,
    benefits and consequences

6
Pattern description for the controller pattern
7
Basic Design Patterns
  • The authors of Elements of Reusable
    Object-Oriented Software (referred to as the Gang
    of Four) developed a basic classification scheme
    for patterns (Figure 9-7)
  • The 23 GoF patterns are some of the most
    fundamental and important patterns in use
  • Scores of other patterns have been defined
  • For example, both Java and .NET have sets of
    enterprise patterns

8
Classification of design patterns
9
Singleton Pattern
  • For classes that must have only one instance, but
    need to be invoked from several classes and
    locations within the system
  • The class itself controls the creation of only
    one instance
  • A static variable of the class refers to the
    object that is created
  • A class method instantiates the object on the
    first call, and returns a reference to the object
    on subsequent calls

10
Singleton Pattern
11
Singleton pattern template
12
Adaptor Pattern
  • Plugs an external class into a system
  • Converts the method calls from within the system
    to match the method names in the external class
  • A standard solution for protection from
    variations
  • Insulates the system from frequently changing
    classes
  • An interface is frequently used to specify and
    enforce the use of correct method names

13
Adapter Pattern
14
Adapter pattern template
15
Design Activities in the UP Life Cycle
16
Design the Support Services Architecture and
Deployment Environment
  • Three organizational dispositions to new systems
  • Integrate new systems into existing systems
  • Install support services for the first time
  • Replace existing systems
  • Design issues for all organizations
  • Reliability
  • Security
  • Throughput
  • Synchronization

17
Design the Software Architecture
  • Software architecture refers to the big picture
  • Two important aspects
  • Division of software into classes
  • Distribution of classes across processing
    locations
  • Modify class diagrams into software classes
  • Determine where classes and objects execute
  • Determine whether they will be distributed
  • Determine communication methods
  • Select programming language(s) to write classes

18
Design Use Case Realizations
  • Use case realizations offer a lower-level view
  • Two-tiered focus
  • Class interactions supporting a particular use
    case
  • Interactions among software, users, and external
    systems
  • Design typically spread over many iterations
  • UML design class diagrams and interaction
    diagrams document design

19
Design the Database
  • Designing database as a key design activity
  • Physical model of database based on class diagram
  • Physical model describes relational or OO
    database
  • Some technical issues
  • Performance, such as response time
  • Integration with existing databases
  • Legacy databases

20
Design the System and User Interfaces
  • System interface issues
  • Different types of systems will interface
  • Systems interact with internal and external users
  • User interface issues
  • User capabilities and needs differ widely
  • User interacts with the system in different ways
  • Approaches to interface vary by system
  • Has nature of interface emerged from earlier
    models?

21
Design the System Security and Controls
  • User-interface controls limit access to
    authorized users
  • System interface controls protect system from
    other systems
  • Application controls record transactions and
    validate work
  • Database controls ensure data protected from
    unauthorized access and accidental loss
  • Network controls protect network communication

22
Design Activities and the UP
  • Focus in early iterations of elaboration phase
  • System architecture and databases
  • Evenly distributed throughout project
  • Detailed design activities
  • Criteria analyst uses to schedule design
    activities
  • Experience
  • Forecasting capabilities
  • Every design impacts other parts of system

23
Single-Computer and Multitier Architecture
  • Single-computer architecture
  • Single system attached to peripheral devices
  • PC and mainframe applications qualify
  • Advantages easy to design, build, operate,
    maintain
  • Disadvantages capacity limits

24
Single-computer, Clustered, and
Multicomputer Architectures
25
Single-Computer and Multitier Architecture
(continued)
  • Multitier architecture (multiple computer
    systems)
  • Clustered architecture
  • Group of computers logically operate as one
  • Nodes from same manufacturer and model family
  • Multicomputer architecture
  • Cluster whose nodes are optimized or specialized
  • Hardware and operating systems may be dissimilar

26
Centralized and Distributed Architecture
  • Centralized architecture
  • Deploys computer systems in single location
  • Used for large-scale processing applications
  • Constraint geography
  • Implements subsystems in larger information
    system
  • Distributed architecture
  • Software/data spread across systems and locations
  • Relies on communication networks to interconnect

27
Client/Server Architecture
  • Client/server architecture tiers
  • Client requests resources or services from a
    server
  • Server manages information system resources
  • Architectural issues for client/server software
  • Decomposing software into client and server
    programs (objects)
  • Determining where clients and servers will
    execute
  • Describing interconnection protocols and networks

28
Client/Server Architecture with a Shared
Database
29
Client/Server Architecture(continued)
  • Client and server communicate via well-defined
    protocols over a physical network
  • Client/server architecture advantages
  • Location flexibility, scalability,
    maintainability
  • Client/server architecture disadvantages
  • Additional complexity, potential poor
    performance, security issues, and reliability

30
Interaction Among Multiple Clients and a
Single Server
31
Three-Layer Client/Server Architecture
  • Variant of client/server architecture
  • Divides application software into independent
    processes
  • Three-layers
  • The data layer
  • The business logic layer
  • The view (presentation) layer
  • Three-tier architecture advantages
  • Additional flexibility and reliability

32
Three-Tier Logical Layers
33
Three-Tier Architecture
34
Four-Tier Architecture
35
Model-View-Controller (MVC)Design Pattern or
Framework
36
Middleware
  • Middleware
  • Connects parts of an application
  • Enables requests and data to pass among them
  • Common types of middleware
  • Teleprocessing monitors
  • Transaction processing monitors
  • Object request brokers (ORBs)
  • Each type of middleware has its own set of
    protocols

37
Differences between client/server and
Internet systems
38
Web Client/Server Architecture
39
Internet and Web-Based Software Architecture
  • Web is complex example of client/server
    architecture
  • Web resources are managed by server processes
  • Clients are programs that send requests to
    servers
  • Web protocols define valid resource formats and
    communication standards
  • Web-like capabilities embedded in ordinary
    applications
  • Web-oriented client/server architecture
    service-oriented architecture (SOA)

40
Internet and Web-Based Software Architecture
(continued)
  • Flexibility is the key to the Internet
    alternative
  • Accessibility, low cost communication, widely
    used standards
  • Disadvantages of Web technologies
  • Security, reliability, throughput, and volatile
    standards
  • The key architectural design issues
  • Defining client and server processes or objects
  • Distributing processes across hardware platforms
  • Connecting processes

41
Simple Internet Architecture
  • Used for viewing static information
  • The browser component executes on the client
    computer
  • The Internet server component executes on the
    server computer
  • Pages reside on the server and are sent to the
    browser for display
  • Program logic is inserted through scripting
    languages (JavaScript, VBScript), applets, or
    other controls

42
Simple Internet architecture
43
Two-layer Architecture
  • Primarily captures information from the user and
    updates the database
  • The domain layer and data access layer are
    usually combined
  • Input data is sent to a CGI or an application
    server
  • The user-interface classes often contain the
    business logic and data access
  • Processing takes place with servlets (Java) or
    code behind classes (.NET)

44
Two-layer Internet architecture
45
Three-layer Architecture
  • Separates domain layer and data access layers
  • Necessary for systems with complex business logic
    or multiple user interfaces
  • Using CGI
  • Provide a use case controller for each form that
    distributes messages to the individual objects of
    the system.
  • Using an application server
  • Java tools Java Server Pages and servlets
  • .NET tools Common Runtime Language and code
    behind classes

46
Three-layer Internet architecture
47
Invoking a Web service
48
Designing Enterprise-level Systems
  • Enterprise-level systems share components among
    multiple people or groups in an organization
  • Enterprise-level systems almost always use
    multiple tiers of computers
  • Can be client/server network-based or Internet
    based
  • Designed with deployment diagrams
  • A type of implementation diagram that shows
    physical components across different locations
