Network Infrastructure; Real time viewer; Telepresence; Data Management

1
Network Infrastructure Real time viewer
Telepresence Data Management

• Kent Polkinghorne
• Information Technology
• NEES CU Boulder

2

• Data Sources
• Local Data Storage
• Remote Data Viewing

3
Probably shouldnt mention Neespop at all since
it sounds like nada pasa
CU FHT Equipment Network
SCRAMNet Deterministic Optical Network (14)
Gigabit Ethernet LAN (2 x Cisco 3550 Switches)
(13)
Neespop.Colorado.Edu Remote Collaboration Host
NI Supplementary Data Acquisition and Control
System
Real-time Computation Target (OpenSEES/ETS or
Simulink)
Test Specimen
A/Ds
Neestp.Colorado.Edu Telepresence Portal
and Robotic Camera Control
Real-time Simulation Target (Simulink)
D/As
FPGA
Additional Computation Resources
Videoconference / Telepresence Hardware
MTS Digital Control System
A/Ds
High-speed Actuators
Neesdaq.Colorado.Edu Data Turbine Server Local
Data Repository
Real-time Hosts
Valve Drivers
Video/Still Image Sources
4
Video and Image Data Network
Gigabit Ethernet LAN
Robotic PTZ Video Camera
Robotic PTZ Video Camera
Robotic PTZ Video Camera
Neestp.Colorado.Edu Telepresence Portal
and Robotic Camera Control
Robotic PTZ Video Camera
Robotic Still Camera
Robotic Still Camera Host
Robotic Still Camera
Robotic Still Camera
Neesdaq.Colorado.Edu Data Turbine Server Local
Data Repository
MiniDV Camera
VIC 2D Image Correlation Host
VIC 2D Camera
5
Robotic PTZ Video Cameras

• Two fixed cameras at the north and south ends of
  lab
• Two wireless cameras for experiment-specific
  viewing
• Pan, tilt, and zoom controlled from telepresence
  portal
• Video streams can be routed to Data Turbine
  server and viewed with the Real-time Data Viewer
  (RDV)
• Up to 10 frames/second at 640x480 pixels

6
Robotic Still Image Cameras

• Three Olympus C750 4.0 megapixel cameras on
  robotic pan/tilt bases
• Controlled via LabVIEW GUI or web interface
• Captured images fed into Data Turbine for viewing
  with RDV
• Used for remotely viewing fine detail at low
  frame rates (10 seconds/frame)

7
MiniDV Camera

• Canon GL2 Three CCD digital video camcorder with
  16-bit stereo sound
• Captured video edited and reformatted with
  open-source video tools (Kino, MJPEG Tools)
• Reduced quality video can be streamed to Data
  Turbine in real time

8

• Data Sources
• Local Data Management
• Remote Data Viewing

9
Local Data Flow
MTS Digital Control System
Researcher
National Instruments Supplementary
Data Acquisition and Control System
Neesdaq.Colorado.Edu Real-time Streaming
Data Local Data Repository
NEES Central Repository
Video/Still Image Sources
500 GB RAID 5 Disk Array
OpenSEES and Simulink Real-time Hosts
2.5 TB Robotic Tape Library
10
Local Data Management

• Data is moved from data sources to local data
  repository via network file system
• Data from Data Turbine acquired with data sink
  tools
• Local repository stored on redundant disk array
  with automatic tape backup
• Data manually uploaded to NEES Central
• Metadata manually uploaded to NEES Central

11

• Data Sources
• Local Data Management
• Remote Data Viewing

12
Data Turbine

• Numeric and image data is fed into the Ring
  Buffered Network Bus (RBNB) Data Turbine
• Data Turbine is responsible for collecting and
  synchronizing data from data sources
• Synchronized data is streamed to Real-time Data
  Viewer (RDV) clients
• Synchronized data is also streamed to disk for
  later access

13
RDV

• Used to view real-time, streaming data over a
  network from a Data Turbine Server
• Instant Replay functionality with variable
  speed playback
• Synchronizes numeric, video, and still image data
• Allows user to overlay data from local PC onto
  streamed data
• Developed by Buffalo NEES equipment site

14
RDV
Time scale control
Zoom timeline
Real-time/ Pause control
Global timeline
Data Turbine server
Numeric data graph
Video channel list
Numeric data channel list
Video window
15
FlexTPS

• Allows remote viewing and robotic control of live
  video over the internet using only a standard web
  browser
• Digital Video Recorder (DVR) functionality allows
  video streams to be recorded and played back
• Collaboration function allows video streams from
  local site and other NEES sites to be viewed
  together
• Developed by University of Texas, Austin
  equipment site

16
FlexTPS

• http//neestp.colorado.edu/portal

Camera name
Zoom control
Camera section
Tilt control
Pan control
Frame rate
Snapshot button
17

• Data Sources
• Local Data Storage
• Remote Data Viewing
