From Client Server to WEB

1
From Client Server to WEB

• Rizwan Akhtar
• Tangible Technologies
• 703-568-3702
• rakhtar_at_tangible-tech.com

2
What we will discuss today

• Developer/2000 Client Server Components and their
  integration
• Migration from Client Server to Web.
• Integration of Developer/2000 components in Web
  environment.

3
Developer/2000 Client/Server runtime installation
8i
File Server with Application and Devloper/2000
runtime installed
Client machine with registry entries
Database Server
Three tier Client/Server
8i
Database Server
Developer/2000 runtime installed
Two tier Client/Server
4
Client Server Deployment Issues

• Not available from every where
• Individual Client machine installation and
  configuration required
• Updates have to be propagated to all Client
  machines.
• Memory requirement for Client Machines are
  generally higher to run Developer/2000 Application

5
Web FormsAre we there yet ?

• Forms Server under 9 IAS is much more reliable
  now
• Client Server forms and reports can be deployed
  as is (one set of runtime)
• SSL can be implemented with the use of Forms
  Servlet
• Newer versions of IE and Netscape are much more
  reliable.
• Use of Forms Servlet instead of Forms CGI is more
  memory efficient.
• Hardware to support a heavy middle tier machine
  has become more affordable
• Key mapping for runtime and .gif icons needed

6
9 IAS Forms and Reports WEB Server
8i
9 IAS
Client machine Oracle Jinitiator on IE or Netscape
9IAS Application Server running Forms Listener
Servlet
Database Server
9 IAS
9 IAS Application Server running Oracle Reports
Server
7
Oracle 9IAS Application Server

• Oracle HTTP Server powered by Apache
• Oracle 9i Portal and Portal to Go
• Oracle 9i Developer Forms and Report Services
• Oracle 9i Web Cache
• Oracle 9i Database Cache

8
Oracle 9i Developer Forms and Reports Services

• Oracle Developer Forms Server
• Forms CGI (Pre Oracle Forms 6i Patch3)
• Forms ListenerServlet
• The ListenerServlet enables Webforms to maintain
  the connections between Forms Java Applet and
  Forms Web Runtime through the standard Apache web
  server port
• Oracle Developer Reports Server
• Reports CGI
• Reports ListenerServlet (to be supported soon)
• Oracle JInitiator or JVM on IE 5.0 and above
• Oracle HTTP listener powered by Apache

9
Installation

• Oracle 9IAS Enterprise Edition
• Separate Oracle Homes for the Database and Oracle
  9IAS Application Server
• Isuites (IAS Home)
• Oracle_806 (Developer Home)
• OraHome81 if same machine for DB
• Customize configuration files

10
Apache Configuration Files

• httpd.conf
• Main Apache server configuration file. HTTP
  listener's settings such as directory mappings,
  protection, SSL, ports, hostname domains, etc.
• oracle_apache.conf
• Included in httpd.conf to bind other IAS
  configuration files. It contains includes to
  other configuration files.
• 6iserver.conf
• 6i configuration file for Apache listener. It is
  read when the Apache listener starts. Included in
  oracle_apache.conf .
• jserv.conf
• Directives for Jserv module. Included by
  httpd.conf
• ApJServManual auto
• ApJServProperties "C\ORACLE\iSuites\Apache\Jserv\
  conf\jserv.properties"
• plsql.conf
• Directives for mod_plsql, such as virtual paths
  handled by mod_plsql. This file is Included by
  oracle_apache.conf file.
• Reference
• http//httpd.apache.org/docs/

11
ListenerServlet Configuration

• zone.properties
• Each servlet has his own properties file, known
  as zone.properties. The zone property file
  contain settings specific to a single servlet
  zone
• repositoriesDEVELOPER_HOME\forms60\java\f60srv.ja
  r
• f60listener.servlet.f60listener.codeoracle.forms.
  servlet.ListenerServlet
• More documentation at http//java.apache.org/jserv
  /zones.html
• jserv.properties
• Main configuration file for Jserv engine. This
  file contains properties passed to the JVM and a
  list of servlet zones and their property files.
• wrapper.pathIAS_HOME\binDEVELOPER_HOME\binC\wi
  nntC\winnt\system32
• wrapper.envPATHIAS_HOME\binDEVELOPER_HOME\binC
  \winntC\
• change the line wrapper.envORACLE_HOMEIASHOME
  to wrapper.envORACLE_HOMEDEVELOPERHOME
• basejini.htm
• Default base HTML file to run a form on the web
  using JInitiator-Style tags to include the Forms
  applet. This file takes its input from
  formsweb.cfg
• formsweb.cfg
• Parameter file used by when initiating web
  connection to run a form. These parameters will
  replace the ones in base.htm or basejini.htm.
  Modify this file to tailor the html page used to
  start your forms application. Key parameters are
• serverURLhttp//hostnameport/servlets/f60listen
  enr
• connectModehttp
• jinit_download_page/jinitiator/us/jinit_download.
  htm
• URL to call web forms
• http//hostnameport/dev60cgi/ifcgi60.exe?formtes
  t.fmx

12
Compatibility Issues

• IE 4.0 or higher or Netscape 4.7 or below
  recommended. Netscape 6.0 or higher not supported
• JIntiator 1.8.0.0 or higher required with
  FormsServlet
• JVM (Java Virtual Machine) only works with IE
• http//hostnameport/dev60cgi/ifcgi60.exe?configI
  E50native

13
(No Transcript)
14
(No Transcript)
15
Reports Server Configuration

• Install Reports Server as a service using
  rwmts60.exe -install ltrep_servernamegt tcpip
• ltrep_servernamegt.ora created under Oracle
  Developer_Home\reports60\server
• Modify tnsnames.ora on the reports server machine
• lttnsnamegt ( ADDRESS (PROTOCOLTCP)
  (HOSTltrepserver_hostgt) (PORTltportnumgt))
• REPORTS60_PATH on the reports server machine must
  be set to the directory containing reports.

16
Oracle Reports Integration

• Run_product
• Can only be used in a client server environment
• Cannot take advantage of the report server
• Is going to be obsolete soon
• Run_report_object
• Can be used in a client server environment or web
  environment to integrate forms with report
• Takes advantage of the reports server
• Can be used to deploy reports on the web when
  coupled with web.show_document
• Cannot be used on the web to display the reports
  parameter window
• Rwcli60.exe
• Used from command line to a call a report with
  command line parameters
• Rwcgi60.exe
• Uses report server
• Can be used to run reports on the web when used
  in a URL
• http//mymachine.domain/dev60cgi/rwcgi60.exe?serve
  rrep_serverreporttest.repparamformhtmldestyp
  ecachedesformatpdf

17
(No Transcript)
18
Other Helpful Commands

• GET_APPLICATION_PROPERTY(USER_INTERFACE)
• Returns web or win32 depending on the
  environment
• Web.show_document
• Forms built that can be used to call any web page
  from within a PL/SQL trigger
• Web.show_document(http//www.yahoo.com)
• Web.show_document(http//mymachine.domain/dev60cg
  i/rwcgi60.exe?serverrep_serverreporttest.reppa
  ramformhtmldestypecachedesformatpdf)

19
Questions
