The Finger Lakes Watershed

1
The Finger Lakes Watershed
2
(No Transcript)
3
(No Transcript)
4
The Finger Lakes Region

• Formed approximately 12,500 years ago with the
  final retreat of the glacier
• An area of over 1.5 million acres of land
• Includes 14 counties
• Drains north to Lake Ontario via the Genesee
  River and Seneca-Oswego Rivers
• Approximately 40 of the total land within the
  Finger Lakes region is used for agricultural
  purposes.

5
http//www.dec.state.ny.us/website/reg8/lakes/lake
6
Can you name the 11 lakes?
www.visitfingerlakes.org
7
Conesus Lake place where there are lots of
berries

• Lake Surface Area 5.34 mi2
• Length 7.8 mi
• Width 1.5 mi wide max, 0.66 mile mean
• Depth 66 ft. max, 37.7 feet mean
• Volume 43 billion gallons
• Elevation 818 ft above sea level
• Shoreline 18.4 mi
• Provides Drinking water to 20,000
• Total Watershed Drainage Area 64.8 mi2
• Retention Time 1.4-3.2 years

8
Hemlock Lake

• Lake Surface Area 2.81 mi2
• Length 7 miles
• Width .5 mi max
• Depth 91 ft max
• Volume 29 billion gallons
• Elevation 905 ft above sea level
• Shoreline 17 mi
• Provides Drinking Water to 220,000 people in
  City of Rochester
• Total Watershed Drainage Area 40.9 mi2
• Retention Time 2 years

9
Canadice Lake long lake

• Lake Surface Area 1.01 mi2
• Length 3.2 mi
• Width .3 mi max
• Depth 53.8 feet mean, 83.3 ft max
• Volume 11 billion gallons
• Elevation 1,096 ft above mean sea level
• Shoreline 7 mi
• Provides Drinking Water to 220,000 people in
  City of Rochester
• Total Watershed Drainage Area 12 mi2
• Retention Time 4.5 years

10
Honeoye Lake lying finger

• Lake Surface Area 2.77 mi2
• Length 4.5 mi
• Width .8 mi max
• Depth 30 ft max, 15 ft avg
• Volume 9.5 billion gallons
• Elevation 804 ft
• Shoreline 11 mi
• Provides Drinking Water to unknown
• Total Watershed Drainage Area 36.7 mi2
• Retention Time 1 year

11
Canandaigua Lake the chosen place

• Lake Surface Area 16.5 mi2
• Length 15.5 miles
• Width 1.5 mi (max), 1.1 mi (average)
• Depth 276 ft (max)
• Volume 429 billion gallons
• Elevation 688 ft above mean sea level
• Shoreline 36 mi
• Provides Drinking Water to 60,000 people
• Total Watershed Drainage Area 174 mi2
• Retention Time 13 years

12
Keuka Lakecanoe landing

• Lake Surface Area 18.15 mi2
• Length 19.6 miles
• Width .71 mi wide avg, max 1.9 mi
• Depth 186 ft max
• Volume 375 billion gallons
• Elevation 709 ft, 715 feet mean
• Shoreline 39 mi
• Provides Water to 20,000 people
• Total Watershed Drainage Area 174 mi2
• Retention Time 6-8 years

13
Seneca Lake place of the stone or stony
place

• Lake Surface Area 66.3 mi2
• Length 35.1 miles
• Width 1.9 mi avg, 3.2 mi maximum
• Depth 651 ft max, 290 ft average
• Volume 4.2 trillion gallons
• Elevation 445.5 ft above sea level
• Shoreline 76 miles
• Provides Drinking Water to 70,000 people
• Total Watershed Drainage Area 457 mi2
• Retention Time 18 years

14
Cayuga Lake boat landing

• Lake Surface Area 66.4 mi2
• Length 38.2 mi
• Width 1.75 mi avg
• Depth 435 ft max
• Volume 2.4 trillion gallons
• Elevation 382 ft above mean sea level
• Shoreline 95.3 mi
• Provides Drinking Water to 86,950 people
• Total Watershed Drainage Area 785 mi2
• Retention Time 9-10 years

15
Owasco Lake the crossing or floating bridge

• Lake Surface Area 10.5 mi2
• Length 11 mi
• Width 1 mi avg
• Depth 177 ft max
• Volume 212 billion gallons
• Elevation 712 ft above sea level mean
• Shoreline 27.7 mi
• Provides Drinking water to 58,000 residents of
  Cayuga County
• Total Watershed Drainage Area 191 mi2

16
Skaneateles Lake long lake

• Lake Surface Area 13.6 mi2
• Length 16 miles
• Width 1 mi avg
• Depth mean 145 ft., max depth 300 feet
• Volume 424 billion gallons
• Elevation mean 863.27 ft.
• Shoreline34 mi
• Provides Drinking Water to 235,000 customers on
  the City of Syracuse
• Total Watershed Drainage Area 59 mi2
• Retention Time 18 yr

17
Otisco Lake place where waters dried up or gone
away

• Lake Surface Area 3.46 mi2
• Length 6 mi
• Width ¾ mile (widest point)
• Depth 60 feet, average 33 feet
• Volume 21 billion gallons
• Elevation 784 ft mean
• Shoreline 15 mi
• Provide Drinking Water to Onondaga County
  Residents
• Total Watershed Drainage Area 36 mi2

18
Finger Lakes Facts

• The bottoms of Seneca and Cayuga Lakes are so
  deep that they are below sea level!
• The Finger Lakes provide drinking water to over
  700,000 people!
• All but Canadice Lake have zebra mussels living
  in them!
• There are over 1.5 million permanent residents in
  the Finger Lakes and 22 million visit annually.

19
Name the Finger Lakes!
Canandaigua
Canadice
Skaneateles
Otisco
Conesus
Owasco
Hemlock
Cayuga
Seneca
Honeoye
Keuka
20
How the Lakes were Formed
21
How the FL Were Formed
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
The Finger Lakes

• Approximately 1.2 million people reside in the
  Finger Lakes
• Approximately 22.2 million people visit this
  region annually
• Permitted water withdrawals are estimated at 200
  million gallons per day

27
The Finger Lakes

• Provide Drinking Water
• Provide Recreational Opportunities
• Provide for Economic Viability
• Provide for Quality of Life

28
What are the Natural Resources in the Region?

• Montezuma Wetlands
• Several State Parks
• Historical Museums/events
• Birthplace of the Iroquois Nation
• Vineyards
• Fisheries
• Erie Canal

29
What are the Environmental Issues Facing the
Finger Lakes?
Farming
Fisheries
Recreational access
Development
Drinking Water
Invasive Species
Stormwater Runoff
Energy
30
References

• Geology Slides Fullerton, 1980. USGS
  Professional Paper 1089
• Maps Finger Lakes Institute,
• Pictures Sheila Myers, Sarah Meyer Finger Lakes
  Institute
• Other US Environmental Protection Agency
