Title: Evaluating Provider Reliability in Risk-aware Grid Brokering Iain Gourlay


1
Evaluating Provider Reliability in Risk-aware
Grid BrokeringIain Gourlay
2
Outline
  • AssessGrid background
  • Problem Statement
  • Basic Reliability
  • Analysis of behaviour
  • Stationarity Problem
  • Weighted Reliability
  • Simulations and Results
  • What if a provider is unreliable?
  • Alternative Bayesian Inference
  • Summary and Conclusions

3
AssessGrid Background
  • AssessGrid addresses Risk Management in the Grid.
  • This is a necessity in the drive towards
    commercialisation of Grid technology
  • The goal is to move beyond best-effort, using
    SLAs to specify agreed upon level of service.
    However,
  • For resource providers, offering an SLA with
    service guarantees and penalties is a business
    risk!
  • For end-users, agreeing to an SLA is a business
    risk!
  • A large part of AssessGrid is concerned with
    methods to support providers with tools and
    methods to
  • Monitor and collect useful data.
  • Assess risk associated with accepting an SLA
    request, based on this data.

4
What is risk?
  • Risk is Hazard, danger, exposure to mischance or
    peril (Oxford English Dictionary).
  • Risk Management is a discipline that addresses
    the possibility that future events may cause
    adverse events.
  • Economics, Operations Research, Engineering,
    Gambling,
  • In Risk Management, risk is quantified with two
    parameters
  • Risk Probability of Occurrence x Impact
  • Grid computing Event is SLA failure!

5
Scenario
6
Role of the Broker
  • Key role Finding/Negotiating with providers on
    behalf of end-users.
  • Broker can also act as an independent party
  • Providers may have motivation to lie!
  • Providers may have unidentified problems in their
    infrastructure.
  • Here, we assume the broker is independent and
    honest.
  • Broker can give a second opinion on risk
    assessments.
  • Broker can agree its own SLAs (virtual provider).

7
Problem statement What do we mean by reliability?
  • A provider makes an SLA offer
  • includes an estimate of the Probability of
    Failure (PoF).
  • Each time an offer is accepted, the details are
    stored in a database, including
  • Final status (Success/Fail)
  • Offered PoF
  • The problem is
  • Given a providers past data, can their risk
    assessments be considered reliable?

8
What is reliable?
  • Considering only systematic errors!
  • Assume s SLAs in the database for the same
    provider.
  • Offered PoFs,
  • Assume number of fails
  • We define a reliable provider as one that does
    not systematically underestimate or overestimate
    the PoF, so that

9
Is it normal?
10
Is it normal? (2)
11
Basic Reliability Identifying Systematic Errors
  • Using the providers offered PoFs
  • The evaluation is based on the following measure

12
Basic Reliability Identifying Systematic
Errors(2)
13
Basic Reliability Identifying Systematic
Errors(3)
  • We note that
  • and recall the condition,
    leading to

14
Analysis How does the measure behave?
  • Simple Example
  • m SLAs in database.
  • Offered PoF is constant, p.
  • There is a systematic overestimation/underestimati
    on of the PoF, such that

15
Analysis (2)
16
Stationarity Problem
  • Conditions are not static!
  • Example 60 red balls in a bag.
  • 40 blue balls in the same bag.
  • You try to estimate the number of red balls by
    taking a ball out and replacing it, repeating
    this 50 times.
  • Someone is secretly removing a red ball and
    replacing it with a blue after every sample.
  • E(red) 17.5
  • Number of reds 10!

17
Stationarity Problem(2)
  • A providers behaviour could change as a
    consequence of a variety of factors, e.g.
  • A providers infrastructure is updated.
  • A providers risk assessment methodology or model
    parameterisation may change.
  • A providers policy may change, for example due
    to economic considerations.

18
Weighted Reliability
  • Use a weighted average, ensuring more recent SLAs
    have a larger influence.
  • Total of mk SLAs are split into k categories,
    with the kth consisting of the most recent SLAs.
  • Here, is the basic measure R over the
    ith category.

19
Simulations
  • A database of SLAs is generated
  • Each SLA object has an offered PoF, true Pof and
    final status.
  • Reliability computed.
  • Process repeated 10000 times for each scenario.
  • Simple case considered here
  • Offered PoF is fixed and true PoF is fixed.

20
Results
21
Results(2)
22
Results (3)
23
Results(4)
24
Results (5)
25
What if the provider is unreliable?
  • Discrete approximation When SLA Offer received
    with offered POF of p, estimate POF by looking at
    failure rate for all SLAs with offered POF of p.
  • Then,
  • If (reliability measure lt threshold) Believe
    provider.
  • Else(PoF estimate numFails(POFp)/numSLAs(POFp)
  • Use all SLAs with offered PoF within x of the
    offered PoF in the current SLA.

26
Weighted Average risk assessment
  • Split km SLAs into k categories.
  • Compute the estimate PoF, for each category,
    i0,,k-1.

27
Never Trust Doctors
  • You are tested for a disease, which 2 of the
    population has.
  • The test never gives a false-negative.
  • If you are clear, there is still a 5 chance of a
    false positive.
  • You test positive.
  • What is the probability you have the disease?

28
Alternative Approach Bayesian Inference
  • The provider offers a linguistic risk assessment,
    e.g. the failure probability is
  • extremely low lt1
  • very low 1-5
  • low 5-10
  • medium 10-20
  • high 20-30
  • very high 30-50
  • extremely high gt50
  • If the broker/end-user requests the PoF exact
    value this can be provided.

29
Alternative Approach Bayesian Inference (2)
  • The broker does not consider the providers
    reliability directly. Instead it takes the
    following approach
  • Having received a linguistic risk assessment for
    a new SLA, the broker first computes a prior
    distribution for the PoF, given the linguistic
    category by considering data across all other
    providers.
  • The broker computes a posterior distribution,
    based on the failure rate observed in past SLAs
    from the same provider with the same linguistic
    risk assessment.
  • The broker returns an object which contains
  • (PoF_broker, confidence)

30
Alternative Approach Bayesian Inference (3)
31
Summary/Conclusions
  • A detailed analysis has been carried out for a
    method to identify providers who are
    systematically unreliable.
  • The stationarity problem has been addressed.
  • Weighted Average
  • Results indicate good performance relative to
    basic measure and moving average.
  • This can be extended to other measures for
    non-systematic errors.
  • Bayesian approach has been considered and is also
    promising.
