Shear Lines, Fronts and Areas of ConfluenceDiffluence

1
Shear Lines, FrontsandAreas of
Confluence/Diffluence

• Mike Davison
• HPC International Desks

2
Shearlines vs. Fronts

• Shear Lines are associated with wind shifts
  (direction and speed).
• A line or narrow zone across which there is an
  abrupt change in the horizontal wind component
  parallel to this line
• A line of maximum horizontal wind shear.
• An area of directional wind confluence along the
  tail end of a surface front.
• Lacks the baroclinicity/density discontinuity of
  surface fronts
• Fronts The interface or transition zone between
  two air masses of different density.
• Density depends on temperature and moisture
  content
• Fronts either lie along shear lines or can lag
  behind them.

3
Wind Confluence and Diffluence in the Caribbean
4
Wind Confluence and Diffluence in South America
5
Wind Divergence
6
Divergence of the Wind

• We can express the divergence equation in a
  simplified form, with two terms
• Direction
• Speed
• The direction and speed terms, in-turn, can be
  expressed as directional/speed diffluence and
  confluence
• Confluence is not equal to Convergence
• Diffluence is not equal to Divergence

7
Divergence (Cont)

• Divergence/convergence calculations need to take
  into account the direction and speed terms.
• This is done through objective analysis
• Streamline analysis is a subjective technique,
  and it only shows directional diffluence and
  confluence.
• It does not show convergence/divergence

8
Example Directional Diffluence/Confluence
Directional Confluence
Directional Diffluence
9
Speed Diffluence/Confluence
Speed Confluence
B
A
Speed Diffluence
10
Convergent or Divergent?
Directional Confluence
A
Speed Diffluence
11
Convergent or Divergent?
12
Convergent or Divergent?
Speed Confluence
A
Directional Diffluence
13
Convergent or Divergent?
14
Evaluation of Shear Lines
15
Front/Shear Line Evaluation
16
Front and Shear Line
17
Front and Shear Line
18
Front and Shear Line
19
Front and Shear Line
20
Forecast Hints

• During the Winter Months
• Convective activity over the Gulf of Mexico and
  gulf coast of Mexico tends to be capped below 500
  hPa (20,000 ft)
• Evaluate upper dynamics for CONVERGENCE or
  DIVERGENCE before forecasting thunderstorms.
• If models forecast post frontal northerlies of
  25Kt or greater, and dew point temperature of 20C
  (68F) or greater over southern Mexico.
• Forecast 12 hrs rainfall accumulation of at least
  2-4 inches.

21
Example of Ideal Conditions for Heavy Rainfall
22
Example Front/Shear Line Caribbean
23
Example Front/Shear Line South America
24
Identify Features
25
Satellite Interpretation
26
Analysis
27
Analysis
