Modelling and Analysis of TCP

1
Modelling and Analysis of TCPs Connection
Management Procedures

• Jonathan Billington and Bing Han
• Computer Systems Engineering Centre
• University of South Australia

2
Motivation

• Finding design flaws of complex protocols such as
  TCP is an important and difficult research
  problem.
• Design flaws
• Specification rather than implementation
• Including deadlocks, livelocks, sequence
  inconsistency, dead code, and so on
• Important problem
• TCP provides a reliable data transfer service to
  many Internet applications.
• TCP is used as the basis of new protocols, e.g.
  DCCP
• Difficult problem
• TCP is a complex protocol.
• The operation of TCP was originally specified in
  RFC 793 using narrative descriptions, message
  sequence diagrams, a FSM diagram and pseudo code.

3
Outline

• Research Scope
• TCP Connection Management
• Desired properties
• Termination
• Absence of deadlocks
• Approach
• Modelling approach
• Analysis approach
• Analysis Results

4
TCP and its Environment
Two peer TCP entities communicate over the
Internet Protocol (IP) as well as interacting
with their application processes.
5
TCP Segment Format
6
Normal Connection Establishment
7
Simultaneous Connection Establishment
8
Normal Connection Release (Graceful Close)
9
Simultaneous Connection Release
10
TCP State Variables

• SND_NXT (send next)
• Stores the sequence number of the next segment to
  be sent.
• RCV_NXT (receive next)
• Stores the sequence number of the next segment to
  be received.
• SND_UNA (send unacknowledged)
• Records the sequence number of the earliest
  segment that has been sent but has yet to be
  acknowledged.
• ISS (initial send sequence number)
• The first sequence number sent in a connection.

11
Our Approach
Model TCP Connection Management using CPNs
Define desired properties using ML
Configure the CPN model
Generate the state spaces
Automatically check the terminal states using ML
12
Top Level Page TCP Overview
13
Level 1
Level 2
Level 3
Level 4
Model Statistics Hierarchical Levels 4 CPN
Pages 19 Places 6 Substitution transitions
19 Executable transitions 97
1. Overview
2. Event Processing
3. User Commands Segment Processing
Retransmissions
4. Command Pages State Pages
14
Desired Properties (Termination)
Successful Establishment
Proper Establishment
Successful Abort
Successful Release
15
Desired Terminal State for Establishment
Successful Establishment
Proper Establishment
16
Acceptable Terminal State for Establishment
17
CPN Model Configurations Some Examples
Configuration Initial Marking
A C_S Opening
D C_S Opening Closing
E Sim. Opening Closing
18
Analysis Results of Model 1 No Loss, No Retrans
Config Time V A TMs DLs
A B C D E F G H I J K 0 0 0 0 3 0 1 1 0 0 1 11 42 57 225 2850 51 355 356 79 73 742 12 60 92 455 8260 91 870 792 141 129 1896 2 2 1 3 6 3 4 13 2 3 4 0 0 0 1 2 0 0 0 0 0 0

• Reordering channel with no loss
• No retransmission
• Run on a machine with 2.6GHz Pentium CPU and 1GB
  RAM.

19
Initial Marking
1 User_1 1A_Open1Close User_2
1P_Open1Close H1_H2 empty H2_H1 empty TCB
1 1CLOSED,RCV_NXT0,SND_NXT0,SND_UNA0,ISS10
,cls TCB 2 1CLOSED,RCV_NXT0,SND_NXT0,SND_U
NA0,ISS20,cls
20
Dead Marking
95 User_1 empty User_2 empty H1_H2
empty H2_H1 empty TCB 1 1FIN_W2,RCV_NXT21,SN
D_NXT12,SND_UNA12,ISS10,cls TCB 2
1CLOSING,RCV_NXT12,SND_NXT22,SND_UNA21,ISS2
0,lis
21
A Reachability Graph Path to the Deadlock of
Config.D
22
Connection Release Fails
23
Analysis Results of Model 2 (Configuration D)
Config D hhmmss V A TMs DLs
(0,0,0,1) (0,1,0,0) (1,0,0,0) (0,1,0,1) (0,0,1,0) (1,1,0,0) (1,0,0,1) (0,0,1,1) (0,1,1,0) (1,1,0,1) (1,0,1,0) (0,1,1,1) (1,0,1,1) 000001 000001 000002 000011 000015 000015 000016 000028 000426 000507 000716 001434 004835 1309 1362 1810 8743 10156 10381 10481 16612 64871 65381 77940 104046 126098 3899 3498 4810 31122 34825 33056 38071 59184 258399 273981 317337 426872 530381 5 7 6 11 11 16 10 15 24 24 24 32 32 1 2 2 2 0 4 2 0 0 4 0 0 0

• Reordering channel with no loss
• Retransmissions
• Run on a machine with 2.6GHz Pentium CPU and 1GB
  RAM.

24
Analysis Results of Model 2 (Configuration E)
Config E hhmmss V A TMs DLs
(0,0,0,1) (0,1,0,0) (1,0,0,0) (0,0,1,0) (0,1,0,1) 000048 000626 002250 002525 091037 19354 45293 98627 122654 328023 75158 163984 392610 516530 1524604 8 21 24 12 29 2 8 8 0 8

25
Conclusions

• Over a reordering channel without loss, TCP
  terminates correctly in the following scenarios
• Client-server connection establishment
• Simultaneous connection establishment
• Orderly release after the connection is
  established
• Aborting of connections
• However, TCP can deadlock when the user releases
  the connection before it is established, i.e.,
  while the TCP entity is in SYN_RCVD.
• Retransmissions of the FIN in state FIN_WAIT_1 or
  CLOSING removes these deadlocks.

26
Configuration 1A_Open1Close and 1P_Open
Nodes28 Arcs 37 DMs 4
27
Configuration 1A_Open and 1P_Open1Close
Nodes25 Arcs 33 DMs 3
