Title: Model Checking Approaches for Web Service Verification


1
Model Checking Approaches for Web Service
Verification
  • Hidayet Ozgur Sanli
  • hedo_at_asu.edu

2
Contents
  • Motivation
  • Whats model checking?
  • Model checking tools
  • Model-Based Verification of Web Service
    Compositions
  • Verification of Web Service Flows with
    Model-Checking Techniques
  • Conclusions
  • References

3
Motivation
  • Service aggregation
  • Combining existing web services
  • Robustness against requirements change
  • Flow description is used for expressing how
    various web services should be composed
  • Faulty flow descriptions is not desirable since
    tremendous amount of shared network resources are
    consumed
  • Runtime verification of compositions for
    properties such as deadlocks and usability
    assessment of partnered services is needed

4
Motivation (contd)
Control flow
Data flow
Late Binding in Web Service Composition
5
Motivation (contd)
Ticket Order as a composite web service
6
Whats model checking? 1
  • Model checking is a method to algorithmically
    verify finite state systems formally
  • Model checking is to verify that, the model,
    often deriving from a hardware or software
    design, satisfies a logical specification
    (determining the truth of formulas)
  • The model is usually expressed as a directed
    graph with nodes, representing states of the
    system, and edges represent possible alterations
    of the state

7
What is model checking? (contd)
  • Requirements for model checking
  • Modelling language to describe the system
  • Specification language to formulate properties
  • Calculus/Algorithm to verify specification
  • Automated model checkers traverse all reachable
    system states
  • Many practical applications
  • Communication Protocols
  • Electrical Circuits
  • Digital Controllers

8
What is model checking? (contd)
  • Correctness properties
  • Safety
  • Nothing bad ever happens
  • Formalized using state invariants (execution
    never reaches a bad state)
  • Liveness
  • Something good eventually happens
  • Formalized using temporal logic
  • (always)
  • ltgt (eventually)
  • () (next cycle)
  • (-) (previous cycle)
  • U (strong until)

9
What is model checking? (contd)
  • (signalA 1 -gt ()signalB 0)
  • It is always the case that signalA equals one
    implies signalB equals zero on the next cycle
  • (signalA 1 -gt (-)signalB 0)
  • It is always the case that signalA equals one
    implies signalB equals zero on the previous cycle
  • ltgt(signalA1()()signalBlt2)
  • Eventually, if signalA is equal to one, and then
    two cycles and always after that, signalB is less
    than 2

10
Model Checking Tools (SPIN)
  • The most popular model checker (ACM Software
    Award)
  • Automata based model checker
  • System is described as programs in the Promela
    language which is close to a real programming
    language
  • Finite state model is generated from the Promela
    description automatically
  • System described as a collection of concurrent
    processes
  • Processes communicate and synchronize via message
    channels and global variables

11
Model Checking Tools (contd)
  • Promela
  • Macro definitions
  • define NBUF 1
  • Symbolic constants
  • inputtype LOW, MEDIUM, HIGH
  • Synchronous message channel
  • chan sender NBUF of short
  • Process Instances
  • active proctype Receiver()
  • Sending messages
  • receiver!MSG0
  • Receiving messages
  • sender?ACK0

12
Model Checking Tools (contd)
Alternating Bit Protocol in Promela
13
Model Checking Tools (contd)
  • Promela code is used to generate Labelled
    Transition System (LTS)
  • SWITCH OFF,
  • OFF (on -gt ON) ,
  • ON (off -gt OFF).

14
Model-Based Verification of Web Service
Compositions 2
  • A Comparison based Verification Approach
  • Use Labelled Transition System Analyzer (LTSA)
    and Message Sequence Charts (MSC) of UML to
    capture desired user workflow behavior
  • Write BPEL4WS implementation
  • Generate BPEL4WS model in FSP for use within LTSA
  • Use LTSA model checker to detect possible
    scenarios that the model supports but undefined
    by user
  • Examine trace results of the FSP model checking
    and iterate tracing until no violations
    deadlocks discovered.

15
Model-Based Verification of Web Service
Compositions (contd)
Model Based Verification Architecture
16
Model-Based Verification of Web Service
Compositions (contd)
Layers of modeling abstraction and implementations
17
Model-Based Verification of Web Service
Compositions (contd)
  • Specification is created as part of requirements
    consisting the upper two layers
  • The workflow is implemented by the software team
    focusing on the lower two layers
  • FSP representation forms the bridge between
    specification and implementation
  • Model checking is done on the design and
    implementation models using trace equivalence

18
Model-Based Verification of Web Service
Compositions (contd)
Market Place Context Diagram
19
Model-Based Verification of Web Service
Compositions (contd)
Seller
Market Place
Buyer
offer product
require product
Model the composition using LTSA-MSC scenarios
20
Model-Based Verification of Web Service
Compositions (contd)
LTSA tool provides a translation mechanism to
convert scenarios to FSP
21
Model-Based Verification of Web Service
Compositions (contd)
BPEL4WS Process Token Groups
22
Model-Based Verification of Web Service
Compositions (contd)
Conversion table for BPEL4WS structured and
concurrent groups to Promela
23
Model-Based Verification of Web Service
Compositions (contd)
Verification Process Map
for BPEL4WS Compositions
24
Verification of Web Service Flows with
Model-Checking Techniques 3,4
Verification Process Map
for WSFL based compositions
25
Verification of Web Service Flows with
Model-Checking Techniques
A
Deadlocked Flow Model
26
Verification of Web Service Flows with
Model-Checking Techniques
Promela Process
corresponding to a WSFL activity
27
Verification of Web Service Flows with
Model-Checking Techniques
  • Wait loop
  • Checks all the channels of the incoming control
    flows and waits until all the channels have
    definite values
  • Join Step
  • Reads out all logical values from the control
    channels and evaluates the join condition
  • Materialize Step
  • Extracts the necessary data from the input links
  • Perform Step
  • Kicks the service provider entry
  • Call Exit Step
  • Checks exit condition of activity for
    re-execution of Perform Step
  • Control Step
  • Computes information that will flow along the
    output control links
  • Propagate Step
  • Propagates information along all the output links
    of both control and data

28
Verification of Web Service Flows with
Model-Checking Techniques
Dead Path
Elimination
29
Conclusion
  • Current web composition workflow languages
    lacks verifications testing aspect
  • Model checking technique is useful for web
    services testing
  • Recent work in verification of web services is
    transformation-based to make use of existing
    tools.

30
References
  • 1 J. Magee and J. Kramer, Concurrency State
    Models and Java Programs, John Wiley, 1999
  • 2 H. Foster, S. Uchitel, J. Magee, J. Kramer,
    Model-based verification of web service
    compositions, Proceedings of 18th IEEE
    International Conference on Automated Software
    Engineering, 6-10, Oct 2003 ,Pages152 161
  • 3 S. Nakajima Model-Checking Verification for
    Reliable Web Services, OOPSLA 2002 Workshop on
    Object-Oriented Web Services, Nov 2002.
  • 4 S. Nakajima Verification of Web Services
    Flows with Model-Checking Techniques, Proc. Cyber
    World 2002, pp. 378-385 (November 2002).
