Carrier Ethernet Services Overview

1
Carrier Ethernet Services Overview
Mike Lerer Consultant, Office of the
CTO Soapstone Networks Inc. www.soapstonenetworks.
com
2
Agenda

• An Introduction to Soapstone Networks Inc.
• Carrier Ethernet Defined a quick review
• The Five Attributes
• Carrier Ethernet Terminology
• The UNI
• Ethernet Virtual Connections (EVCs)
• E-Line Services
• Ethernet Private Line
• Ethernet Virtual Private Line
• E-LAN Services
• Multipoint Services
• E-Tree Services
• Point to Multipoint Services
• EVCs and Services

March 2007
3
Soapstone Networks PNC

• Provider Network Controller (PNC) provides
  quality and capacity management for transport
  resources
• The tight coupling of fulfillment and assurance
  results in a true control plane
• Create and maintain resources through active
  monitoring of network elements
• Uniform reporting of performance, utilization,
  faults, and resource inventory
• Supports provisioning, fault correlation,
  performance and monitoring, capacity planning,
  and optimization as part of an overall integrated
  management system

4
Carrier Ethernet Defined
Carrier Ethernet is
A ubiquitous, standardized, carrier-class
Service and Network
Defined by five attributes that distinguish it
from familiar LAN based Ethernet
5
The 5 Attributes Carrier Ethernet (1)
Attribute 1 Standardized Services

• E-Line, E-LAN provide transparent, private line,
  virtual private line and multi-point to
  multi-point LAN services.
• A ubiquitous service providing globally locally
  via standardized equipment
• Requires no changes to customer LAN equipment or
  networks and accommodates existing network
  connectivity such as, time-sensitive, TDM traffic
  and signaling
• Ideally suited to converged voice, video data
  networks
• Wide choice and granularity of bandwidth and
  quality of service options

6
The 5 Attributes Carrier Ethernet (2)
Attribute 2 Scalability

• The ability for millions to use a network service
  that is ideal for the widest variety of business,
  information, communications and entertainment
  applications with voice, video and data
• Spans Access Metro to National Global
  Services over a wide variety of physical
  infrastructures implemented by a wide range of
  Service Providers
• Scalability of bandwidth from 1Mbps to 10Gbps
  and beyond, in granular increments

7
The 5 Attributes Carrier Ethernet (3)
Attribute 3 Reliability

• The ability for the network to detect recover
  from incidents without impacting users
• Meeting the most demanding quality and
  availability requirements
• Rapid recovery time when problems do occur, as
  low as 50ms

8
The 5 Attributes Carrier Ethernet (4)
Attribute 4 Quality of Service

• Wide choice and granularity of bandwidth and
  quality of service options
• Service Level Agreements (SLAs) that deliver
  end-to-end performance matching the requirements
  for voice, video and data over converged business
  and residential networks
• Provisioning via SLAs that provide end-to-end
  performance based on CIR, frame loss, delay and
  delay variation characteristics

9
The 5 Attributes Carrier Ethernet (5)
Attribute 5 Service Management

• The ability to monitor, diagnose and centrally
  manage the network, using standards-based vendor
  independent implementations
• Carrier-class OAM
• Rapid service provisioning

10
MEF Carrier Ethernet Terminology

• The User Network Interface (UNI)
• The UNI is the physical interface or port that
  is the demarcation between the customer and the
  service provider/Cable Operator/Carrier/MSO
• The UNI is always provided by the Service
  Provider
• The UNI in a Carrier Ethernet Network is a
  physical Ethernet Interface at operating speeds
  10Mbs, 100Mbps, 1Gbps or 10Gbps

Carrier Ethernet Network
UNI
CE
CE Customer Equipment, UNI User Network
Interface. MEF certified Carrier
Ethernet products
11
MEF Carrier Ethernet Terminology

• Ethernet Virtual Connection (EVC)
• Connects two or more subscriber sites (UNIs)
• An association of two or more UNIs
• Prevents data transfer between sites that are not
  part of the same EVC
• Three types of EVC
• Point-to-Point
• Multipoint-to-Multipoint
• Rooted-Multipoint (Point-to-Multipoint)

12
Carrier Ethernet Service Types Using EVCs
E-Line Service type

• E-Line Service used to create
• Ethernet Private Lines
• Virtual Private Lines
• Ethernet Internet Access
• E-LAN Service used to create
• Multipoint L2 VPNs
• Transparent LAN Service.

Point-to-Point EVC
UNI
UNI
CE
CE
Carrier Ethernet Network
E-LAN Service type
CE
UNI
Carrier Ethernet Network
UNI
Multipoint-to-Multipoint EVC
CE
UNI User Network Interface, CE Customer
Equipment
MEF certified Carrier Ethernet products
13
Carrier Ethernet Service Types Using EVCs

• E-Tree Service used to create
• Point-to-multipoint
• Like EPON Ethernet
• Root-to-Leaf and Leaf-to-Root

E-Tree Service type
UNI User Network Interface, CE Customer
Equipment
MEF certified Carrier Ethernet products
14
EVCs and Services

• In a Carrier Ethernet network, data is
  transported across Point-to-Point,
  Point-to-Multipoint and Multipoint-to-Multipoint
  EVCs according to the attributes and definitions
  of the E-Line and E-LAN services

Point-to-Point EVC
UNI
UNI
Carrier Ethernet Network
15
Services Using E-Line Service Type

• Ethernet Private Line (EPL)
• Replaces a TDM Private line
• Dedicated UNIs for Point-to-Point connections
• Single Ethernet Virtual Connection (EVC) per UNI

Storage Service Provider
UNI
CE
Carrier Ethernet Network
UNI
ISP POP
CE
Internet
UNI
UNI
Point-to-Point EVC
CE
16
Services Using E-Line Service Type

• Ethernet Virtual Private Line (EVPL)
• Replaces Frame Relay or ATM services
• Supports Service Multiplexed UNI (i.e. multiple
  EVCs per UNI)
• Allows single physical connection (UNI) to
  customer premise equipment for multiple virtual
  connections

Service Multiplexed Ethernet UNI
CE
UNI
Carrier Ethernet Network
CE
UNI
UNI
CE
Multipoint-to-Multipoint EVC
17
Services Using E-LAN Service Type

• Ethernet Private LAN and Ethernet Virtual Private
  LAN Services
• Supports dedicated (EP LAN) or service-multiplexed
  (EVP LAN) UNIs
• Supports transparent LAN services and multipoint
  VPNs

Service Multiplexed Ethernet UNI
UNI
UNI
CE
Carrier Ethernet Network
UNI
CE
UNI
CE
Multipoint-to-Multipoint EVC
18
Services Using E-Tree Service Type

• Ethernet Private Tree and Ethernet Virtual
  Private Tree Services
• Ethernet Services distributed from centralized
  site (Root) to remaining sites (Leaves)
• Root provides a well defined source access point

Service Multiplexed Ethernet UNI
UNI
UNI
CE
Carrier Ethernet Network
UNI
CE
UNI
CE
Rooted Multipoint EVC
19
Related MEF Services Specifications
MEF 6.1
Metro Ethernet Services Definitions Phase 2
Purpose
Defines the Ethernet Services (EPL, EVPL,
E-Line, ELAN,EP-Tree,EVP-Tree etc)
Ethernet Services Attributes Phase 2
MEF 10.1
Purpose
Defines the service attributes and parameters
required to offer the services defined in MEF 6.
Updated from Original MEF 10 in October 2006
Audience
Appropriate for equipment vendors, service
providers, and business customers, since it
provides the fundamentals required to build
devices and services that deliver Carrier
Ethernet. For Enterprise users it gives the
background to Service Level Specifications for
Carrier Ethernet Services being offered by their
Service Providers and helps to plan Ethernet
Services as part of their overall network.
20
MEF Membership
June 2008

• Membership doubled over 2 years
• Diverse mix of SP, vendor and test groups
• Commitment, involvement in Forum workgroups

Service Provider, Cable/MSO Members
Now 148 Members

• AboveNet
• Alpheus Communications
• ATT
• Belgacom
• Bell Canada
• Bright House Networks
• British Telecom
• Cable Wireless
• Charter Communications
• China Telecom
• Cincinnati Bell
• Colt
• Comcast
• Cox Business
• Demand Broadband
• Embarq
• IPC
• KDDI RD Laboratories
• KPN Telecom

• PT Inovação
• PT Prime
• Qwest Communications
• RCN Business Solutions
• Reliance Communications
• Shanghai Information Network
• Singapore Telecom
• Sprint
• Suddenlink
• Swisscom
• Symphony Communication
• TATA Communications
• Telecom Italia
• Telekom Malaysia
• Teliasonera AB
• Telus
• Time Warner Cable
• Time Warner Telecom
• T-Systems

Equipment Vendors, Software Test Companies, Lab
Members

• Accedian Networks
• Actelis Networks
• Adtran
• Adva Optical Networking
• Aethera Networks
• Agilent Technologies
• Aktino
• Alcatel- Lucent
• AMCC
• ANDA Networks
• ARRIS International
• Atrica
• Aurora Networks
• Axerra Networks
• Bay Microsystems
• Broadcom
• BTI Photonics
• CableLabs
• Calix

• D-Link
• Do Networks
• Dowslake Microsystems
• DragonWave
• EANTC
• ECI Telecom
• Ericsson
• Ethos Networks
• EXFO
• Extreme Networks
• FibroLAN
• FiberHome Technologies
• Fluke Networks
• Foundry Networks
• Fujitsu Network Communications
• Gridpoint Systems
• Hammerhead Systems
• Harris Stratex
• Hatteras Networks

• Ixia
• JDSU
• Juniper Networks
• Lightstorm Networks
• Maipu Communications
• Matisse Networks
• Maxim
• Motorola
• MRV Communications
• Nakina Systems
• NEC
• Nokia Siemens Networks
• Nortel Networks Corp.
• Occam Networks
• Omnitron Systems
• Overture Networks
• Qosera
• PCT International
• RAD Data Communications

• Soapstone Networks
• Spirent Communications
• Starhub
• Sunrise Telecom
• T Pack
• Tejas Networks
• Telco Systems
• Telcordia Technologies
• Tellabs
• Telrad Networks
• Transition Networks
• Transmode Optical
• Transwitch Corporation
• Turin Networks
• UNH-IOL
• UTStarcom
• Vitesse
• Wipro
• Wintegra

20
21
More at

• www.MetroEthernetForum.org/presentations.htm
