14 Dec 2005

1
CENG 710Fundamentals of Autonomous Robotics

• Scale Invariant Feature Transform
• Maya Çakmak

2
VISION

• the most powerful sense
• Area Computer/Robot Vision
• Sub-area Object Recognition
• Problem Obtain a representation that allows us
  to find a particular object we've encountered
  before

3
Key properties of a good feature

• Highly distinctive
• Easy to extract
• Invariant, tolerant to changes
• Easy to match against a large database

4
SIFT

• SIFT is an approach for detecting and
  extracting local feature descriptors in which
  image content is transformed into local feature
  coordinates.

5
The Paper

• Distinctive Image Features from Scale
  Invariant Key-points
• International Journal of Computer Vision, 2004
• International Conference of Computer Vision, 1999
• David Lowe
• CS Department, Univ. of British Columbia

6
The method is

• Invariant to
• Image scaling
• Translation
• Rotation
• Partially invariant to
• Illumination changes
• View points

7
Stages in SIFT

• Scale-space extrema detection
• Keypoint localization
• Orientation assignment
• Keypoint descriptor

8
Scale Space Extrema
Stage 1

• Extrema of difference-of-Gaussian (DoG) of

• Gaussian-blurred image
• DoG for image

9
Method to obtain DoG
Stage 1
10
Key Point Localization
Stage 2

• Find local minimum and maximum of DoG

11
Stage 2

• For each candidate
• Remove keypoints with low contrast
• (with value treshold)
• Remove responses along edges ( with
  principle curvatures)

12
Orientation Assignment
Stage 3

• For the selected keypoint, at the closest scale
• compute a gradient orientation histogram
• determine dominant orientation

13
Scale Space Images
Example
5th
4th
3rd
1st image in 2nd octave
14
DoG Images
Example
4th level 2nd octave
2nd level 2nd octave
3rd level 2nd octave
1st level 2nd octave
15
Keypoint Images
Example
16
Effect of eliminations
Stage 3

• 233x189 image
• (b) 832 DoG extrema
• (c) 729 left after elimination of low contrast
• (d) 536 left after eliminating edge responses

17
Keypoint Descriptor
Stage 4
Keypoint is localized by (x, y, scale,
orientation) How to describe image content at
the keypoint?

SIFT descriptors are a set of orientation
histograms on 4x4 pixel neighborhoods of the
keypoint
18
Matching SIFT features

• Feature vector dimension 4x4x8128
• Find nearest neighbor in a database of SIFT
  features from training images.
• For robustness, use ratio of nearest neighbor to
  ratio of second nearest neighbor.

19
Matching in different scales
20
Matching in different scales
21
Matching different view points
22
Matching in different illumination
23
Multiple object instances
24
Closing Comments

• SIFT features are reasonably invariant to
  rotation, scaling, and illumination changes
• We can use them for matching and object
  recognition among other things
• Robust to occlusion, as long as we can see at
  least 3 features from the object we can compute
  the location and pose
• Efficient on-line matching, recognition can be
  performed in close-to-real time (at least for
  small object databases)

25
References

• 1 Lowe, David Object Recognition from Local
  Scale-Invariant Features, ICCV, 1999 and IJCV,
  2004
• 2 Lowe, David CVPR 2003 Tutorial
• 3 Matlab SIFT toolbox tutorial
• 4 Computer Vision Lecture Notes, by Pinar
  Duygulu, Bilkent University, CS department.
