Linked Structures

1
Linked Structures

• Computer Science and Engineering

2
Linked List

• We will study
• The concept of linked structure (list)
• Java Linked list
• State design pattern-based realization of a
  linked list

3
Consider an Array

• Array is fixed size (non-mutable, static)
• Array insert is difficult
• Default indexing 0..n-1, predefined sequence of
  elements
• Allows random access

Insert here

N-1
0 1 2 3 4
4
Linked List

• A linked list is an empty list or collection of a
  number of nodes, each containing one data element
  and one (or more) links to other nodes.
• Linked lists permit dynamic insertion and removal
  of nodes at any point in the list. Linked lists
  do not allow random access.
• The simplest kind of linked list is a singly
  linked list, which has one link per node. This
  link points to the next node in the list, or to a
  null value if it is the last node. This kind of
  list allows sequential access to elements.
• It is used where the size and structure of the
  data needs to be flexible and dynamic.

5
Varieties of Linked List

• Simple linked list
• Linked list with special node(s) for head and/or
  tail
• Null terminator
• Sentinel as terminator
• Single link, double link, multi-link, circular
  linked
• Pointer to first and last node

6
A node of linked list
public class Node Object item Node
next some times you have explicit
representation for a head and or tail.
7
Node Class
8
Linked List Operations

• Construct
• Insert (first, last, anywhere)
• Delete (first, last, anywhere)
• Size
• Search for an item
• Process Traverse, iterate to do something

9
JDK1.4 Linked List
Object
AbstractCollection
Collection
AbstractList
List
AbstractSequentialList
List, java.io.Serializable, java.lang.Cloneable
LinkedList
10
LinkedLists inheritance and related classes

• Most of the linked list functionality is
  specified in the interface List.
• Serializable defines the disk archiving (object
  read/write) functionality.
• Cloneable defines the cloning ability.
• LinkedList class defines the variables needed for
  storing the header and size.
• A ListIterator class offers the Iterator facility.

11
Linked List class
//constructors add (index I, Object o) //
inserts add(Object o) //appends addFirst(Object
o) addLast(Object o) Object remove(index
i) boolean remove(Object o) Object
removeFirst() Object removeLast() Object
get(index i) Object getFirst() Object
getLast() Object set(index i, Object o) returns
replaced Object
12
Linked List Class (contd.)
ListIerator listIterator(index i) boolean
contains(Object o) clear() int indexOf(Object
o) int lastIndexOf(Object o) // first
occurrence or 1 Object toarray() int size()
13
(No Transcript)
14
java.util.LinkedList Empty List
object
header
Doubly linked list with a special node
header. For an empty list all three fields point
to the header itself
15
Java.util.LinkedList Non-Empty List
16
remove(Object o)

• Locate the Entry e with Object o (Object can be
  null).
• If no such Entry throw an exception.
• Update pointers
• 3.1 Update previous entrys next to es next
• 3.2 Update es nexts previous to es previous
• 3.3 update size size size 1

17
Remove an entry
Step 3.2
Step 3.1
18
Remove an entry
Header
Step 2
Object
Object
Object
Entry e
Step 1
19
Java Code for Step 3 of remove

• e.previous.next e.next //3.1
• e.next.previous e.previous //3.2
• size-- //3.3

20
add(int index, Object o)

• Inserts an Entry of Object o before Entry at the
  given index.
• Retrieve the Entry e at the given index.
• Construct an Entry out of Object o and add it
  before e
• 2.1 Construct Entry x with o as Object, e as
  next and e.previous as previous.
• 2.2 Update next pointer of xs previous Entry
• 2.3 Update previous pointer of xs next Entry.
• 2.4 size

21
add(int index, Object o) Step 2
Entry e at given index
Entry x
22
add(int index, Object o) Step 2

• Let e be the entry at the given index.
• Entry x new Entry(o, e, e.previous) //step 2.1
• x.previous.next x //step 2.2
• x.next.previous x //step 2.3
• size

23
add(int index, Object o) Step 2
header
Object
Object
Object
Entry e at given index
2.2
2.3
24
Iterator Pattern

• When you want to access elements of a collection
  sequentially without the knowledge of the
  underlying representation.
• Ex 1 MineSweeper surroundIterator that presents
  you list of all valid surrounding cells (0-8) for
  sequential access
• Ex 2 Maze sequence of valid neighbors
• Ex 3 winterMonths sequence of all winter months
  from a list of all months can be defined for
  polymorphic dispatch for various types of
  geographic zones
• A simple iterator interface hasNext(), next(),
  hasPrevious(), previous(), currentElem()

25
Java Linked List Iterator

• Implemented as an inner class.
• Review an inner class is a class embedded within
  another class. Scope is limited to the embedding
  class.
• In fact, LinkedList has two inner classes
  ListItr and Entry.
• A listIterator(int index) index specifies the
  starting point in the list for generating the
  elements of the iterator. You may request a
  partial list Iterator.

26
Using a List

• Problem Make a list of all routes in city map.
• class Route int origin
• int dest
• Route (int a, int b)
• LinkedList map new LinkedList()
• map.add( route(23,45))
• etc.
• //print me a list of all train routes
• // assume a trainIterator is available
• //think about the implementation of trainIterator

27
Using an Iterator

• // generate the iterator
• ListIterator tR map.trainIterator()
• while (tr.hasNext())
• System.out.println(tr.next())
