QNT 531 Advanced Problems in Statistics and Research Methods

1
QNT 531Advanced Problems in Statistics and
Research Methods

• WORKSHOP 3
• By
• Dr. Serhat Eren
• University OF PHOENIX

2
SECTION 3 OBJECTIVES

• Find the linear regression equation for a
  dependent variable Y as a function of a single
  independent variable X
• Determine whether a relationship between X and Y
  exists
• Analyze the results of a regression analysis to
  determine whether the simple linear model is
  appropriate

3
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• 1. Deterministic and Statistical Relationships
• In some cases where two variables, x and y, are
  related, the relationship is deterministic, or
  functional. This means that when a value of x is
  selected, the value of y is uniquely determined.
• Figure 15.1 illustrates this type of relationship.

4
(No Transcript)
5
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• If a person were to order x 100 items, then the
  corresponding cost would be y 50 (1.20)
  (100) 170.
• Every person who orders 100 items will incur the
  cost of 170. That is, the value of y is unique,
  for a given value of x.
• Suppose that we are looking at the relationship
  between dollars spent in advertising and the
  revenues from sales.

6
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• Clearly, we expect the two variables to be
  related, but we do not expect that every time a
  company spends x in advertising it Will always
  have y in revenues.
• We know that there are other factors, or
  variables, such as the type of product, location,
  and various economic factors that will affect the
  value of Y for a given value of X

7
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• When we collect our data we are collecting pairs
  of observations on the two variables, X and y
  Thus, we will have a set of n data pairs
• (X1, Y1), (X2,Y2), . . . , (Xn,Yn)
• This type of plot, Figure 15.2, a scatter plot,
  is of primary importance in exploring
  relationships between variables, and should be
  done before any type of statistical analysis is
  performed.

8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• 2. The Simple Linear Regression Model
• The true relationship between the variables X and
  Y, the simple regression model, can be described
  by the equation
• This equation says that for a given value of the
  variable X x, the actual value of Y will be
  determined by the expression ,plus
  some random variation, ?, due to other
  unmeasured, factors.

12
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• Thus, if we knew the values of , the true
  population intercept, and , the true
  population slope, we could predict the value of Y
  to within some random error, ?.
• Figure 15.3 shows the population model for a
  linear regression. Figure 15.4 shows such a line
  along with the data.

13
(No Transcript)
14
(No Transcript)
15
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• The equation of the line that we draw will be
• Where y is the predicted value of Y for a
  particular value of X x. The quantities b0 and
  b1 are the estimates of the population values

• and . This line is called the
  regression line of y on X or the estimate of the
  simple regression model.

16
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• 3. The Least-Squares Line
• Figure 15.6 shows a set of data and a line drawn
  to represent the relationship between the
  variables.
• The distance between the predicted value of
  Y,,and the actual value of Y, y, is called the
  deviation of error.

17
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• The technique that finds the equation of the line
  that minimizes the total or sum of the squared
  deviations between the actual data points and the
  line is called the least-squares method.

18
(No Transcript)
19
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• The least-squares method finds the equation of
  the line
• that minimizes

20
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• The total of squared deviations from the data
  points to the line. The values for b0 (the
  intercept of the line) and b1 (the slope of the
  line) are found by using the following equations

21
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• The easiest way to look at what is involved in
  the calculations is to make a table with a column
  for each sum needed. The table will look like the
  one in Table 15.1.

22
(No Transcript)
23
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• 4. Using the Computer to Do Regression
• Analysis
• Any statistical software that you might be using
  is capable of performing regression analysis.
• In addition, most spreadsheet packages also do
  regression. We will start by identifying the
  estimates for the parameters of the regression
  equation in the output for several software
  packages.

24
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• 5. Using the Regression Equation to Make
• Predictions
• In Figure 15.3 we saw that the values of Y vary
  around the true regression line. The value of we
  find is really a prediction of the mean value of
  Y for a given value of X.
• There are two kinds of predictions that you can
  do, interpolation and extrapolation.

25
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• Using the equation to predict values of Y within
  the range of the X data is called interpolation.

• Predicting values of Y for values of X outside
  the observed range is called extrapolation.

26
(No Transcript)
27
(No Transcript)
28
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• 6. Calculating Residuals
• The difference between the observed value of Y
  (yi), and the predicted value of Y from the
  regression equation , for a value of X xi
  is called the ith residual, .

29
(No Transcript)
30
SECTION 3 THE SIMPLE LINEAR REGRESSION MODEL

• 7. The Standard Error of the Estimate
• The standard error of the estimate, sylx is a
  measure of how much the data vary around the
  regression line.

31
(No Transcript)
32
SECTION 3INFERENCES ABOUT THE LINEAR REGRESSION
MODEL

• 1. Hypothesis Testing About the Slope, ?1
• If the variables X and Y are related, the slope
  of the line will be some number. If there is no
  relationship between X and Y then the slope of
  the line is zero.
• That is, we say that as X changes, Y does not
  change in a related way, Figure 15.9.
• We will use hypothesis testing to decide whether
  the slope of the regression line is significantly
  different from zero.

33
SECTION 3INFERENCES ABOUT THE LINEAR REGRESSION
MODEL

• The first step in testing a hypothesis is to set
  up the appropriate hypotheses. In this case we
  want to test
• Ho ?1 0
• HA ?1 ? 0

34
(No Transcript)
35
SECTION 3INFERENCES ABOUT THE LINEAR REGRESSION
MODEL

• If the test results in rejecting the null
  hypothesis, then we will conclude that the slope
  of the regression line is not equal to zero, and
  that the relationship between the X and Y
  variables is real.
• Our estimate of ?1 is b1, and to proceed with the
  steps of the hypothesis test we need to know
  about the sampling distribution of b1.

36
SECTION 3INFERENCES ABOUT THE LINEAR REGRESSION
MODEL

• It turns out that the sampling distribution
  associated with the least-squares estimate of the
  slope is the Student t distribution.
• The test statistic for our hypothesis test is
  therefore

37
SECTION 3INFERENCES ABOUT THE LINEAR REGRESSION
MODEL

• which has a t distribution with n-2 degrees of
  freedom. In the formula, is the standard error of
  the slope b1 and is calculated by

38
SECTION 3INFERENCES ABOUT THE LINEAR REGRESSION
MODEL

• Since the test is a two-sided test, once the
  significance level of the test, ?, is chosen, the
  critical values of the test are
• ? t?/2,n-2.
• We now have the test set up. All that remains is
  to perform the test and make a decision.

39
(No Transcript)
40
(No Transcript)
41
SECTION 3INFERENCES ABOUT THE LINEAR REGRESSION
MODEL

• 2. Partitioning the Variance in Linear Regression
• SST- the total variation in the y values around
  the mean
• SSR- the variation in Y that is caused by Y's
  relationship with X
• SSE- the variation in Y that remains unexplained.

42
SECTION 3INFERENCES ABOUT THE LINEAR REGRESSION
MODEL

• The quantities SST, SSR, and SSE are known as the
  sums of squares SST is the N total sum of
  squares, SSR is the regression sum of squares,
  and SSE is the error sum of squares.
• Figure 15.11 illustrates how these quantities
  relate to the data and to the regression line.

43
(No Transcript)
44
SECTION 3INFERENCES ABOUT THE LINEAR REGRESSION
MODEL

• In addition you see that
• SST SSR SSE

45
SECTION 3INFERENCES ABOUT THE LINEAR REGRESSION
MODEL

• When X and Y are related, SSR is a large part of
  the total variation. This implies that a major
  reason that Y varies so much is because it is
  related to X.
• When this is true, the SSE component of the
  variation is small and is the variation in Y that
  happens "naturally" or entirely due to chance.

46
SECTION 3INFERENCES ABOUT THE LINEAR REGRESSION
MODEL

• When X and Y are not related, the regression line
  is horizontal (?1 0) and the SSR component of
  the variation disappears.
• The SSE part of the variation becomes dominant
  and we say that we cannot really explain the
  variation in Y using the linear model with X.

47
SECTION 3INFERENCES ABOUT THE LINEAR REGRESSION
MODEL

• The test is referred to as an analysis of
  variance (ANOVA) test, because it is based on
  looking at the variation in the Y variable.
• The hypotheses that we test are
• Ho The linear regression model is not
  significant.
• HA The linear regression model is significant.

48
SECTION 3INFERENCES ABOUT THE LINEAR REGRESSION
MODEL

• The test statistic for this test uses the mean
  squares, which are obtained by dividing the sums
  of squares, SSR and SSE, by their respective
  degrees of freedom

49
SECTION 3INFERENCES ABOUT THE LINEAR REGRESSION
MODEL

• The regression sum of squares (SSR) measures the
  amount of the variation in the Y variable that
  can be accounted for or explained by Y's
  relationship with X.
• If you look at SSR as a portion of SST, then you
  can determine the amount of the variability in Y
  that can be explained, or accounted for.

50
SECTION 3INFERENCES ABOUT THE LINEAR REGRESSION
MODEL

• This value is called the coefficient of
  determination, R²

51
SECTION 3INFERENCES ABOUT THE LINEAR REGRESSION
MODEL

• R² is usually part of the general information in
  the output from statistical packages.
• The coefficient of determination gives you a
  measure of how much the variation in Y could be
  reduced if X were controlled to a single value.
• This is a way of measuring how useful a model is
  for planning purposes.

52
SECTION 3 CORRELATION ANALYSIS

• 1. The Correlation Coefficient
• In Figure 15.14, you see three types of
  relationships perfect negative, none, and
  perfect positive.
• The correlation coefficient is used as a measure
  of the strength of a linear relationship.

53
SECTION 3 CORRELATION ANALYSIS

• A correlation of -1 corresponds to a perfect
  negative relationship, a correlation of 0
  corresponds to no relationship, and a correlation
  of 1 corresponds to a perfect positive
  relationship.

54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
58
SECTION 3 CORRELATION ANALYSIS

• The correlation coefficient, r, is calculated
  using the formula

59
SECTION 3 CORRELATION ANALYSIS

• The correlation coefficient is also related to
  one of the quantities that we looked at in
  regression analysis, the coefficient of
  determination, R².
• The value of r is equal to the positive square
  root of R².

60
SECTION 3REGRESSION ASSUMPTIONS AND RESIDUAL
ANALYSIS

• 1. Assumptions and Problems in the Regression
  Models
• Remember that the simple linear model is given by


61
SECTION 3REGRESSION ASSUMPTIONS AND RESIDUAL
ANALYSIS

• The basic assumptions about the error term ? are
• It has a mean value of zero
• For every value of X, the standard deviation, s,
  of ? is the same.
• The distribution of ? is normal.
• The error terms for the different observations
  are nor correlated with each other.

62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
SECTION 3MULTIPLE REGRESSION MODEL

• Multiple regression analysis is the study of how
  a dependent variable y is related to two or more
  independent variables.
• In the general case, we will use p to denote the
  number of independent variables.

68
SECTION 3MULTIPLE REGRESSION MODEL

• 1. Regression Model and Regression Equation
• The equation that describes how the dependent
  variable y is related to the independent
  variables x1, x2,..., xp and an error term is
  called the multiple regression models.

69
SECTION 3MULTIPLE REGRESSION MODEL

• 2. Estimated Multiple Regression Equation
• Unfortunately the
  parameter values will not be known and must be
  estimated from sample data.
• A simple random sample is used to compute sample
  statistics that are used
  as the point estimators of the parameters

• .

70
SECTION 3MULTIPLE REGRESSION MODEL

• where
• estimated value of the dependent variable
• are the estimates of
  .

71
SECTION 3LEAST SQUARE METHOD

• The least squares method develops the estimated
  regression equation that best approximated the
  straight-line relationship between the dependent
  and independent variables.
• 1. Least Squares Criterion

72
SECTION 3LEAST SQUARE METHOD

• where
• observed value of the dependent variable
  for the i th observation.
• estimated value of the dependent variable
  for the i th observation.

73
SECTION 3MULTIPLE COEFFICIENT OF DETERMINATION

• The total sum of squares can be partitioned into
  two components the sum of squares due to
  regression and the sum of squares due to error.
• 1. Relationship Among SST, SSR, and SSE

74
SECTION 3MULTIPLE COEFFICIENT OF DETERMINATION

• where

75
SECTION 3MULTIPLE COEFFICIENT OF DETERMINATION

• 2. Multiple Coefficient of Determination
• Many analysts prefer adjusting R² for the number
  of independent variables to avoid overestimating
  the impact of adding an independent variable on
  the amount of variability explained by the
  estimated regression equation.

76
SECTION 3MULTIPLE COEFFICIENT OF DETERMINATION

• With n denoting the number of observations and p
  denoting the number of independent variables, the
  adjusted multiple coefficient of determination is
  computed as follows.

77
SECTION 3MULTIPLE REGRESSION MODEL ASSUMPTIONS

• 1. Multiple Regression Model
• 2. Assumptions About the Error Term in the
• Multiple Regression Model
• The error ? is a random variable with mean or
  expected value of zero that is, E(?) 0.

78
SECTION 3MULTIPLE REGRESSION MODEL ASSUMPTIONS

• The variance of ? is denoted by ?² and is the
  same for all values of the independent variables
  x1, x2,..., xp .
• The values of ? are independent.
• The error ? is a normally distributed random
  variable reflecting the deviation between the y
  value and the expected value of y given by

79
SECTION 3TESTING FOR SIGNIFICANCE

• The F test is used to determine whether a
  significant relationship exists between the
  dependent variable and the set of all the
  independent variables.
• If the F test shows an overall significance, the
  t test is used to determine whether each of the
  individual independent variables is significant.
  A separate t test is conducted for each of the
  independent variables in the model.

80
SECTION 3TESTING FOR SIGNIFICANCE

• 1. F-Test
• For the multiple regression models as defined
  below
• The hypotheses for the F test involve the
  parameters of the multiple regression models.

81
SECTION 3TESTING FOR SIGNIFICANCE

• If H0 is rejected, we have sufficient statistical
  evidence to conclude that one or more of the
  parameters is not equal to zero and that the
  overall relationship between y and the set of in
  dependent variables x1, x2,..., xp is
  significant.
• However, if H0 cannot be rejected, we do not have
  sufficient evidence to conclude that a
  significant relationship is present.

82
SECTION 3TESTING FOR SIGNIFICANCE

• F Test for Overall Significance
• Test Statistic

83
SECTION 3TESTING FOR SIGNIFICANCE

• Rejection Rule
• Using test statistic
• Reject H0 if
• Using p -value
• Reject H0 if p-value lt ?

84
SECTION 3TESTING FOR SIGNIFICANCE

• 2. t-Test
• If the F test shows that the multiple regression
  relationship is significant, a t test can be
  conducted to determine the significance of each
  of the individual parameters.
• t Test for Individual Significance
• For any parameter

85
SECTION 3TESTING FOR SIGNIFICANCE

• Test Statistic
• Rejection Rule
• Using test statistic Reject H0 if
• Using p -value Reject H0 if p-value lt ?

86
SECTION 3TESTING FOR SIGNIFICANCE

• 3. Multicollinearity
• Multicollinearity refers to the correlation among
  the indeendent variables.

87
SECTION 3QUALITATIVE INDEPENDENT VARIABLES

• We must work with qualitative independent
  variables such as gender (male, female), method
  of payment (cash, credit card, check), and so on.

88
SECTION 3RESIDUAL ANALYSIS

• 1. Standardized Residual for Observation i
• where
• is the standard deviation of residual i.
• The general formula for the standard deviation of
  residual i is defined as follows.

89
SECTION 3RESIDUAL ANALYSIS

• 2. Standard Deviation of Residual i
• where
• s standard error of the estimate
• leverage of observation i

90
SECTION 3RESIDUAL ANALYSIS

• 3. Detecting Outliers
• An outlier is an observation that is unusual in
  comparison with the other data in other words,
  an outlier does not fit the pattern of the other
  data.
• In general, the presence of one or more outliers
  in a data set tends to increase s, the standard
  error of the estimate, and hence increase
  , the standard deviation of residual i .

91
SECTION 3RESIDUAL ANALYSIS

• The size of the standardized residual will
  decrease as s increases.
• 4. Influential Observations
• The rule of thumb is used to identify influential
  observations.
• For the Butler Trucking example with p2
  independent variables and n10 observations.

92
SECTION 3RESIDUAL ANALYSIS

• The critical value for leverage is
• The leverage values for the Butler Trucking
  example obtained by using Minitab are reported in
  Table 3-24, in your textbook. Because hi does not
  exceed 0.9, we do not detect influential
  observations in the data set.

93
SECTION 3RESIDUAL ANALYSIS

• 5. Using Cook s Distance Measure to Identify
• Influential Observations
• Cook s distance measure uses both the leverage
  of observation i, hi, and the residual for
  observation i, , to determine whether
  the observation is influential.
• Cooks Distance Measure

94
SECTION 3RESIDUAL ANALYSIS

• where
• Cooks distance measure for observation i
• the residual for observation i
• the leverage for observation i
• p the number of independent variables
• s the standard error of the estimate
• The value of Cooks distance measure will be
  large and indicate an influential observation if
  the residual and/or the leverage is large.

95
SECTION 3RESIDUAL ANALYSIS

• As a rule of thumb, values of indicate that the
  i th observation is influential and should be
  studied further.
