The Worlds First Triple Nested HF Radar Test Bed
for Current Mapping and Ship Detection
Hugh Roarty Scott Glenn Josh Kohut Rutgers
University Don Barrick Pam Kung CODAR Ocean
Sensors
2
Rutgers University Coastal Ocean Observation Lab
Operate New Jersey Shelf Observing System
1) L-Band and X-Band satellite receivers 2)
Nested Multi-static HF radar array 3)
Long-duration fleet of autonomous
underwater gliders
CODAR HF Radar Operations with the New Jersey
Shelf Observing System
1998 - First 25 MHz system test 1999 - 25 MHz
system setup for continuous operation 2000 -
First 5 MHz system deployed - Begin
testing 25 MHz Bistatic Augmentation 2001 -
Operational 5 MHz network with four systems
- Deploy 25 MHz bistatic transmitting buoy
- Begin testing 5 MHz Bistatic
Augmentation 2002 - Implement multistatic/multi-fr
equency network - 2 25 MHz
systems - 4 5 MHz systems 2003 -
Deploy 5 MHz bistatic buoy - Help extend
coverage along entire Northeast coast
as part of NEOS Currently operate 10
systems from Wildwood, New Jersey to
Nantucket, Ma.
3
CODAR Ocean Sensors, Ltd.The Leader in HF
Surface-Wave Radar Ocean Monitoring

• Company principals have been continuously
  involved in HFSWR for 35 years
• Patented CODAR Hallmarks
• Compact antenna system --small footprint offers
  unobtrusive coastal presence
• Unmanned, real-time operation
• Low power -- both radiated and required input
  supply
• GPS-synchronized multiple-radar and multi-static
  operation at same frequency
• Currents mapped to 200 km with Long-Range
  backscatter SeaSondes
• Bistatic augmentation by CODAR demonstrates
  coverage extension to 330 km
• Over 150 CODAR SeaSondes manufactured and sold --
  85 of all HFSWRs
• Systems logged over 4 million operating hours to
  date
• Recent "Dual-Use" objectives being pursued to
  examine ship detection/tracking
• Robust, multiple-look at same target defies
  evasion
• HFSWR is CODAR's only product -- provides us
  unparalleled focus of direction

4
Applied Mathematics, Inc.
SHIP-TRACKING SAMPLE
SHIP-TRACKING SAMPLE
COMPANY BACKGROUND
COMPANY BACKGROUND

• Extensive experience in development, at sea
  testing, and analysis of ship detection and ship
  tracking algorithms for US Navy and the United
  Kingdom Royal Navy
• Have provided on site technical support for 28
  years in search and ship tracking tactics to
  Commander Submarine Development Squadron TWELVE,
  the tactical development agent for the Submarine
  Force
• Developed over past twenty-five years search and
  tracking computer programs (called tactical
  decision aids) for real time use on board
  submarines
• Developed ocean current data assimilation and
  area of uncertainty tracking algorithms for US
  Coast Guard Search and Rescue applications

5
OBJECTIVES

• Test new transmission waveforms
• Multistatic SeaSonde data from the network will
  be collected, however, this initial set of tests
  will focus on analyzing the backscatter data only
• Test different detection algorithms
• Test the sensitivity of the MUSIC direction
  finding algorithm to ideal versus measured beam
  patterns for hard targets
• Define the parameters to optimize dual-use ship
  tracking and current mapping with a Codar
  SeaSonde

6
HF RADAR NETWORK
180 km
RUTGERS
7
Ship Tracking Throughout Rutgers HF Radar Network
8
60 Transits of Oleander in 2004
9
5 MHz Loveladies, NJ
New Jersey Installations Used for Oleander Tests
5 MHz Sandy Hook ,NJ
10
Detection Algorithm

• Simultaneous multiple sliding window
• FFTs in Doppler processing
• Two types of background calculation ---
• median and IIR
• 3D background (Time, Range and
• Doppler) varying with sea echoes
• Thresholding of peaks --- local SNR of
• monopole or at least one of the two
• dipole antennas have to be above the
• threshold
• MUSIC algorithm used to determine
• bearing
• Bearing precision determined by SNR
• (1/sqrt(SNR))

11
Pepper Plots

• All targets detected 9 dB above background

12
Ship Tracking Algorithm

• A Kalman Filter provides a recursive solution to
  the least squares problem.
• Assumptions include linear target motion and
  normally distributed measurement errors.
• Tracker inputs are time radar transmitter and
  receiver positions range, bearing, and range
  rate and range, bearing, and range rate
  uncertainties.
• Tracker outputs are target position velocity
  and estimates of position and velocity
  uncertainties (covariance matrix).
• Target Maneuver Test a statistical test is used
  to estimate whether a combination of two straight
  tracks fit the data better than a single straight
  track.

Oleander Constant Course and Speed Tracker
Solution Using CODAR Detections from 23 November
2002
13
Tx
Rx
14
RESULTS
SMALL BOATS

• SeaTow 41 41 length
• SeaTow 25 25 length

15
SeaTow 41
Loveladies 5 MHz
13 nm
Tuckerton 5 MHz
16
SeaTow 41
Boat Speed 25 knots
17
SeaTow 25
18
SeaTow 25
19
Present Focus

• Hardware Improvements
• 13 MHz Codar SeaSonde, December 2004
• 13 MHz Codar Superdirective System, July 2005
• Software Improvements
• SIFTER Algorithm

20
Sandy Hook Facility March 2004Continuous
Operation Since July 2001
21

• Sandy Hook
• Test Bed
• Present Day
• 25 MHz system installed March 2004
• 5 MHz Transmit Antenna moved 1 wavelength back
  from shoreline
• 13 MHz System Installed December 2004

22
25 MHz Tx/Rx
5 MHz Tx
13 MHz Rx
5 MHz Rx
13 MHz Tx
23
Three Frequency Coverage

• 5 MHz
• 13 MHz
• 25 MHz

24
Pattern Measurement
25
25 MHz System in Clear Environment
26
25 MHz HOSR
Pattern Measurement
Radial Distribution
27
(No Transcript)
28
Low Pass
Hook
29
(No Transcript)
30

• Sandy Hook
• Test Bed
• Future
• 13 MHz SuperDirective System Installation July
  2005

31
13-MHz Heptagonal Array Being Built and Tested at
CODAR
SuperDirective System

• 23-foot (7-m) high mast
• 2 masts 21 dB directivity over ground
• -32 dB efficiency
• The gain of a directional antenna with the
  footprint of an omni directional antenna

32
Future Work

• Utilize AIS signal to ground truth multiple ship
  tracks
• New and Different Targets

33
Automatic Identification System (AIS)

• Required on vessels of
• 300 gross tonnage or greater,
• Length Over All (LOA) over 20 meters, or
• carries more than 50 passengers for hire

34
(No Transcript)
35
GPS Track of RV Hatteras April 5-21, 2005
36
GPS Track of Oceanus April 7-25, 2005
37
Transits of Oleander in 2005
38
(No Transcript)
39
How did the move of the Transmit Antenna Affect
Radial Coverage?
5 MHz Rx
40
5 MHz Transmit Antenna Move
BEFORE
AFTER
25
50
75
Radial CoverageApril 2005
Radial CoverageNovember 2004
41
13 MHz HOMR
Pattern Measurement
Radial Distribution
42
(No Transcript)
43
Simulated Bearing Error with Distorted, Measured
Antenna Patterns Compared with Real Ship Bearing
Data

• Simulated points follow power law
• Compared to
• Ship detections at lower SNRs may differ
  because
• Noise peaks are mis-identified as ships
• "Noise" near peak contains ship signal,
  i.e., it is too high

44
5 13 MHz Receive Antennas in Cluttered
Environment
45
Simulated Bearing Error with Added Bias from
Improper Antenna Pattern Compared with Real Ship
Bearing Data

• For Simulation
• Measured distorted pattern inputted
• Ideal pattern used to recover echo
• Expected power-law fit is offset by 16
• Ship is also offset when inappropriate ideal
  pattern is used

46
Oleander DetectionsFebruary 28, 2005 Outbound
128 point FFT 6 dB Threshold
256 point FFT 7 dB Threshold
512 point FFT 8 dB Threshold
47
SuperDirective Beam Patterns 360 degree coverage

• Blue curve is theoretical pattern for 7-element
  array
• Red results from use of measured transponder
  pattern

48

• Developed by Mission Research Corporation (MRC)
• Originally developed for ROTHR (Relocatable Over
  The Horizon Radar)
• SIFTER rejects peaks that do not move in a
  consistent way
• SIFTER finds smoothest distribution of
  scatterers that reproduces HFSWR or ROTHR
  measurements
• Targets appear as localized peaks

49
SIFTER Results
Cross Spectra after SIFTER
Cross Spectra before SIFTER
