Environmental Modelling, Security Measures and Decision Making

1
Environmental Modelling, Security Measures and
Decision Making

• Zahari Zlatev
• National Environmental Research Institute
• Frederiksborgvej 399, P. O. Box 358
• DK-4000 Roskilde, Denmark
• zz_at_dmu.dk

2
CONTENTS

• Two types environmental models
• Critical levels established in EU
• Critical levels and decision making
• Critical levels and climatic changes
• UNI-DEM Mathematical Description
• Numerical Treatment
• Parallel Computations
• Designing a Set of Scenarios
• Some Results
• Major Conclusions

3
Generic Formulation of an Air Pollution Model
Using splitting advantages and drawbacks
4
Applying splitting techniques
Coupling the sub-models
5
Numerical treatment of the horizontal transport
1. How to obtain the system of ODEs? 2. How to
solve the system of ODEs? Explicit methods with a
stability control
Need for faster but still sufficiently accurate
methods
6
Numerical treatment of the chemical reactions
1. No spatial derivatives 2. Non-linear and stiff
system of ODEs 3. Extremely badly scaled 4.
Implicit numerical methods
Need for faster but still sufficiently accurate
methods
7
Numerical treatment of the vertical exchange
1. P and H depend on the spatial
discretization 2. Linear and stiff system of
ODEs 3. Implicit numerical methods 4. This
sub-model is cheaper than the other two
Need for faster but still sufficiently accurate
methods
8
UNI-DEM

• Initializing the model
• NX 96, 288, 480
• NY NY NX (rectangular domains)
• NZ 1 or 10 (easy to put more layers)
• N_SPECIES 35, 56, 168 (RADM2, RACM)
• N_CHUNKS chunks for parallel runs
• N_REFINED related to emissions, 0 or 1
• N_YEAR year (any year from 1989 to 2004)

9
Size of the involved matrices

• Discretization Equations Time-steps
• 96x96x10 3 225 600 35 520
• 288x288x10 29 030 400 106 560
• 480x480x10 80 640 000 213 120
• Assumption 35 chemical species are used
• Why refined grids are needed?

10
Nitrogen dioxide pollution in Europe
11
Nitrogen emissions in Denmark
12
NO2 pollution in Denmark (coarse grid)
13
NO2 pollution in Denmark (fine grid)
14
Variation of the numbers of bad days
15
Conclusions

• Take the inter-annual variations into account
  runs over long time periods (20-30 years) are
  necessary
• It is not enough to use scenarios based only on
  variations of the anthropogenic emissions the
  natural emissions are also important
• Comparing only concentrations is not enough
  quantities related to the concentrations and
  having damaging effects might vary very much even
  if the variations of the concentrations are small
• Large sets of scenarios are to be used
• The use of fine resolution discretization is
  highly desirable
• A direct consequence of the above requirements
  need for better and faster mathematical and
  computational tools (numerical methods,
  reordering the computations, parallel codes,
  efficient exploitation of computer grids)
• Data assimilation might lead to some considerable
  improvements
• Statistical and graphical representation of the
  results to make them easily understandable even
  for non-specialists

16
More details

• Z. Zlatev and I. Dimov Computational and
  Numerical Challenges in Environmental Modelling,
  Elsevier, Amsterdam - Boston - Heidelberg -New
  York - Oxford - Paris - San Diego - Singapore -
  Sydney - Tokyo, 2006.
• Z. Zlatev et al. Impact of Climate Changes on
  Pollution Levels in Europe,
• http//www.softasap.net/ips/climatic_sce
  narios_NATO.pdf
• http//www2.dmu.dk/atmosphericenvironment/Climate
  20and20Pollution
