Title: Biodegradability of Select Polycyclic Aromatic Hydrocarbon Mixtures


1
Biodegradability of Select Polycyclic Aromatic
Hydrocarbon Mixtures
  • By Jennifer N. Stark
  • REU Project
  • Professor Autenrieth
  • Summer 2005

2
What are PAHs?
  • Largest and most structurally diverse class of
    hydrocarbons
  • --Formed naturally and anthropogenically
  • Formation methods include incomplete combustion,
    burning of biomass, slow burning in sediments
  • Are hydrophobic and dont solubilize easily in
    water
  • Are lipophilic
  • HMW more persistent and difficult to degrade

3
Environmental Significance of PAHs Studied
  • Carcinogenic, toxic, and mutagenic properties
  • Partition in fatty tissues when digested

4
Characteristics of PAHs Studied
5
What is Biodegradation?
  • Uses natural biological activity to make
    contaminants less harmful compounds or are
    mineralized
  • Microorganisms attack using enzymes
  • Example naphthalene dioxygenase

http//www.ch.qub.ac.uk/staff/boyd/fig1.gif
6
Sphingomonas paucimobilis EPA505
  • Originates in soil, air, and freshwater and
    marine environments
  • Able to use fluoranthene as sole source of carbon
    and energy
  • Versatile and able to degrade many PAHs
  • Produce enzymes needed as catalysts for reactions

7
Biodegradation andMonod Kinetics
  • Is how fast microbes degrade a substrate
  • Monod kinetics-applicable when contaminant is
    adequate food source for organisms
  • Rate of biotransformation increases until store
    of contaminant is used up
  • First Order Kinetics- substrate concentration
    neglected since its much smaller than the
    saturation constant
  • Used for most bioremediation applications
  • The rate of degradation is proportional to the
    concentration of the substrate

8
Monod Equation for Sole Substrates

9
Assumptions for Multisubstrate Kinetics in
Experiment
  • Extant kinetics
  • Does not account for growth of biomass
  • Low initial substrate to biomass ratio
  • All PAHs compete for the same enzyme

10
Experimental Set-up
  • Separated experiments into sole substrate
    experiments and binary mixture experiments
  • Performed an initial experiment to determine
    concentrations of PAHs to prepare and sampling
    times needed

11
Concentrations of PAHs Determined
12
Concentrations of PAHs Present
13
Bacteria Inoculation
  • Bacteria grown with 800 ml of a nutrient broth
  • Nutrient broth incubated for thirty-six hours
    while on horizontal shaker for 160 rpm
  • When harvested, bacteria centrifuged and washed
    three times

14
Experimental Procedure
  • Conducted using 250 mL amber bottles
  • reactors were placed on a horizontal shaker
  • Required concentration of bacterial solution was
    determined to be .25

15
Experimental Procedure
  • 7 ml samples taken from the reactor and added to
    the sampling vial
  • Sampling vials placed on a rotary shaker for
    twelve hours
  • 1 mL sample extracted from each vials and added
    to a GC vial
  • Vials analyzed using the GCMS.

16
Working with the GC/MS
17
Kinetic Parameters Obtained
18
Discussion-Sole Substrate Experiments
  • First order rate constants comparable
  • Comparable affinity constants for naphthalene and
    1-methylfluorene phenanthrene and fluorene.
  • Naphthalene constants could be accurately
    estimated but not for others

19
Degradation of 1-Methylfluorene
20
Degradation of Fluorene
21
Degradation of Naphthalene
22
Degradation of Phenanthrene
23
Discussion-Binary Substrate Experiments
  • Model does not fit 1-methylfluorene degradation
  • Naphthalene and phenanthrene degradation suggests
    that sequential metabolism occurs

24
Results for Binary Mixtures
  • Naphthalene degradation predicted by model, not
    phenanthrene
  • Kinetic parameters not accurate since more points
    needed for trend line

25
Conclusions
  • Replicated Anuradha Desais and Petros Petros
    Dimitriou-Christidis experiments
  • Observed four compounds had comparable
    degradation rates
  • They will likely compete with one another

26
Acknowledgments
  • My parents and brother
  • The NSF-REU Program
  • Dr. Autenrieth
  • Dr. McDonald
  • Anuradha Desai, for all her help and answering my
    (frequent) questions
