Chapter 21: Iterators

1
Chapter 21 Iterators
2
Objectives

• After studying this chapter you should understand
  the following
• the role of iterators in container classes
• various implementations of the Iterator
  interface
• iterators as an abstraction of indexes in list
  operations
• the notion of an internal iterator
• the basic structure of the java.util.Collection
  hierarchy.

3
Objectives

• Also, you should be able to
• use iterators in algorithms dealing with lists
• define a class that provides a new implement of
  the Iterator interface.

4
Cost of accessing list elements

• Need to access each element of a list.
• Use index to access an element of the list.
• for array-based implementations get(i) is
  constant.
• for linked implementations get(i) is linear.

5
Cost of accessing list elements

• For a linked implementation

for (int i 0 i lt list.size() i i1) do
something with list.get(i)

• Its quadratic, while

int i list.indexOf(element) list.remove(i)

• both statements are linear
• Need Reduce cost of linked-list traversals.

6
Iterator

• An object associated with container that
  sequentially accesses each element in the
  container.
• nhUtilites.containers2 contains classes
  described.
• The standard package java.util includes a
  different interface also named IteratorltEgt.

7
Iterator

• public interface IteratorltElementgt extends
  Cloneable
• Iterator for accessing and traversing elements of
  a container.
• public void reset ()
• Initialize this Iterator to reference the first
  element.
• public void advance ()
• Advance this Iterator to the next element.
• require !this.done()
• public boolean done ()
• No more elements to traverse in the container.
• public Element get ()
• Element this Iterator currently references.
• require !this.done()

8
Iterator (cont)

• public boolean equals (Object obj)
• The specified Object is an Iterator of the same
  class as this, and references the same relative
  element of the same container.
• public boolean traverses (Object container)
• This Iterator traverses the specified container.
• public Object clone ()
• A copy of this Iterator.
• public void setEqualTo (IteratorltElementgt other)
• Set this Iterator to reference the same
  container element as the specified Iterator. Both
  Iterators must traverse the same container.
• require this.traverses(container)
  implies other.traverses(container)
• ensure this.equals(other)

9
Using Iterator

• Assume container c, and i an iterator for it.
• Can access each element in container as follows

i.reset() while (!i.done()) do something with
i.get() i.advance()

• Example To see if element is in container

i.reset() while (!i.done() !i.get().equals(ele
ment)) i.advance()
10
int indices and iterators

• An index int variable is a simple for of
  iterator
• It is reset by setting variable to 0.
• Advanced by incrementing variable .
• It is done when variable equals the length of the
  list.

11
Iterator implementations

• Every iterator implementation is coupled to its
  container.

12
Iterator for array-based implementations

• public class ListIteratorltElementgt implements
  IteratorltElementgt
• private int current // index into
  theList
• private ListltElementgt theList // the
  List this Iterator references
• /
• Create a new iterator for the specified List.
• /
• public ListIterator (ListltElementgt list)
• theList list
• current 0

13
Iterator for array-based implementations

• //Initialize this Iterator to reference the
  first
• public void reset ()
• current 0
• //Advance this Iterator to next element.
• public void advance ()
• current current 1
• //No more elements to traverse in the
  container.
• public boolean done ()
• return current gt theList.size()
• //Container element this Iterator currently
  references.
• public Element get ()
• return theList.get(current)

14
Iterator for Linked lists

• Define an iterator for LinkedListltElementgt as a
  private inner class.
• It can then directly access implementation
  structure of the LinkedList and of component
  Nodes.
• It keeps a reference to Node containing current
  element.

15
Iterator for Linked lists
private class Iterator implements
nhUtilities.containers.IteratorltElementgt
private Node current //Create a new
Iterator for this LinkedList public Iterator ()
reset() //Initialize this Iterator to
reference the first element. public void reset
() current LinkedList.this.first //Adva
nce this Iterator to next element. public void
advance () current current.next
16
Iterator for Linked lists
//No more elements to traverse in the
container. public boolean done () return
current null //Container element this
Iterator currently references. public Element get
() return current.element
17
Creating iterators for containers

• ListltElementgt includes method for creating an
  iterator

public IteratorltElementgt iterator () Create a
new Iterator for this List.
18
Default creation of iterators

• AbstractListltElementgt creates ListIteratorltElement
  gt as the default iterator.

public abstract class AbstractListltElementgt
implements ListltElementgt public
IteratorltElementgt iterator () return new
ListIteratorltElementgt(this)

• This default implementation is only good for
  array-based implementations.

19
Creation of LinkedListltElementgt iterators

• The class LinkedListltElementgt,
• overrides iterator() method and returns an
  instance of LinkedListltElementgt.Iterator

20
ListltElementgt with Iterator parameters

• Wed like to be able to delete the element
  identified by an iterator, change it, insert an
  element in front of it, etc.
• Overload ListltElementgt methods that take index
  arguments with methods taking iterator arguments.

21
ListltElementgt with Iterator parameters

• public Element get (IteratorltElementgt iterator)
• The Element referenced by the specified Iterator.
• public IteratorltElementgt iteratorAt (Element
  element)
• An Iterator referencing first occurrence of
  specified Element in this ListltElementgt
  IteratorltElementgt is done if not found.
• public void add (IteratorltElementgt iterator,
  Element elm)
• Insert Element at position. The Iterator will
  reference the newly added Element.
• public void remove (IteratorltElementgt iterator)
• Remove Element at position. Iterator will
  reference Element following removed Element. If
  no Element follows removed Element
  iterator.done() is true.
• public void set (IteratorltElementgt iterator,
  Element elm)
• Replace the element at the specified position
  with the specified Element.

22
Improving Iterator for LinkLists

• LinkedListltElementgt.Iterator references current
  node of a LinkedListltElementgt.
• Sufficient to implement get and set.
• To implement remove and add, need reference to
  Node preceding current Node.
• Must traverse list to find needed Node.

23
Improving Iterator for LinkLists

• To solve problem
• keep a pair of references in the iterator, one to
  the current Node and one to the preceding Node.
• Or keep a reference to the Node preceding current
  one.
• In either case, it will simplify things if
  LinkedListltElementgt has a header

24
DoublyLinkedListltElementgt Iterators

• It is possible to move forward or backward
  through a doubly linked list as each node
  contains forward and backward references.
• Define an IteratorltElementgt extension that
  permits forward and backward traversal of a list,
  and ensure that a DoublyLinkedListltElementgt
  creates such an iterator.

25
BiDirectionalIteratorltElementgt
public interface BiDirectionalIteratorltElementgt
extends IteratorltElementgt public boolean done
() This Iterator has been advanced past the last
element, backed uppast the first element, or the
container is empty. Equivalent to offRight()
offLeft(). public boolean offRight () This
Iterator has been advanced past the last element,
or the container is empty. public boolean
offLeft () This Iterator has been backed up past
the first element, or the container is
empty. public void advance () Move this
Iterator forward to the next element. If
this.offLeft() and the container is not empty,
move to the first element. public void backup
() Move this Iterator back to the previous
element. If this.offRight() and the container is
not empty, move to the last element. require
!this.offLeft()
26
Iterators and List modifications

• what will the state of the i iterator be after
  executing

list.remove(j) or list.remove(2)
27
Iterators and List modifications

• If a List is modified via an index, all Iterators
  that reference the List become invalid.
• Furthermore, if a List is modified by an
  Iterator, all other Iterators that reference the
  List become invalid.

28
Internal Iterators forEachDo

• Client provides an operation and iterator itself
  applies operation to each container element.
• They support performing some specific operation
  on each item in the container.
• We consider adding this feature to the List
  interface.
• The operation to be performed should be provided
  as a method argument, encapsulated in an object.

29
Internal Iterators forEachDo

• We define an interface to model an operation

public void execute (Element element) The
operation. public interface OperationltElementgt An
operation to be performed on an Element.

• Method forEachDo has an Operation parameter

// Perform Operation on each element public void
forEachDo (OperationltElementgt operation)
30
Internal Iterators forEachDo

• Using an Iterator, forEachDo can be implemented
  in AbstractListltElementgt

public void forEachDo (OperationltElementgt
operation) IteratorltElementgt iterator
this.iterator() iterator.reset() while
(!iterator.done()) operator.execute(iterator.g
et()) iterator.advance()
31
Internal Iterators forEachDo

• For example, suppose roll is a ListltStudentgt and
  want to add ten points to each Students grade

roll.forEachDo( new OperationltStudentgt ()
public void execute(Student element)
element.setGrade(element.getGrade()
10) )
32
Limitations of forEachDo

• forEachDo allow to perform an operation on each
  list element.
• It does not allow to replace elements. Nor to
  query list for a value that requires querying
  each element.
• Handling such problems requires more structure.

33
Complexity of List features
feature Array-based linked
get(int) constant Linear
get(Iterator) constant constant
indexOf(Element) linear linear
iteratorAt(Element) linear linear
add(Element) constant constant
add(Iterator,Element) linear constant
add(int, Element) linear linear
remove(int) linear linear
remove(Iterator) linear constant
set(int,Element) constant linear
set(Iterator, Element) constant constant
34
The java.util CollectionltElementgt hierarchy

• Java package java.util defines a set of
  interfaces and classes rooted at interface
  CollectionltElementgt.
• This hierarchy contains members closely related
  to classes and interfaces described in this
  chapter.
• The library available since Java 1.2, and
  retrofitted for type parameters in Java 1.5.

35
The java.util CollectionltElementgt hierarchy

• Collection models a generalized container.
• Some Collections allow duplicate elements, others
  do not.
• Some Collections impose an ordering on the
  elements some are unordered.

36
The java.util CollectionltElementgt hierarchy

• Collection methods include

public boolean contains (Element e) This
collection contains the specified element. pubic
boolean isEmpty() This collection contains no
elements. public int size () The number of
elements in this collection. public
java.util.Iterator iterator() An iterator over
the elements in this collection.
37
The java.util CollectionltElementgt hierarchy

• Operations add and remove elements are
  optional. An implementing class can choose
  to support them or not.

public boolean add (Element element)
throws UnsupportedOperationException, ClassCastE
xception, IllegalArgumentException
38
The java.util CollectionltElementgt hierarchy

• List extends Collection. This interface models a
  sequential collection in which elements can be
  accessed by index.
• A List can contain duplicate elements, but
  operations to add and remove elements are still
  specified as optional.
• java.util.Set extends Collection and specifies a
  Collection that does not contain duplicate
  elements.
• Classes AbstractCollection, AbstractList, and
  AbstractSet provide skeletal implementations of
  the interfaces.
• Concrete implementation classes extend these
  abstract classes.

39
The java.util CollectionltElementgt hierarchy

• Array-based list implementations extending
  AbstractList
• Java.util.ArrayList
• java.util.Vector.
• Array-based implementations grow automatically.

40
The java.util CollectionltElementgt hierarchy

• java.util.LinkedList extends AbstractSequentialLis
  t, which extends AbstractList.
• It provides a doubly-linked list implementation.
• Its iterator() method returns an iterator that
  allows bi-directional traversal of the linked
  list.

41
The java.util CollectionltElementgt hierarchy
interface
AbstractCollectionltElementgt
CollectionltElementgt
interface
AbstractListltElementgt
ListltElementgt
AbstractSequentialListltElementgt
LinkedListltElementgt
42
Iterator interface

• Interface IteratorltElementgt specifies three
  methods

public boolean hasNext () The iteration has more
elements.next public Element next () throws
NoSuchElementException The next element in the
iteration. Throws NoSuchElementException if
hasNext() is false public void remove ()
throws UnsupportedOperationException, IllegalSta
teException Removes from the underlying
collection the last element returned by the
iterator (optional operation). This method can be
called only once per call to next.
43
Iterator interface

• Query hasNext is essentially the converse of our
  Iterator method done.
• Note that method next is not a proper query since
  it changes the state of the iterator.

44
Iterator interface

• We could implement next by accessing the current
  element and then advancing the iterator

public Element next () Element temp
this.get() this.advance() return temp
45
ListIterator interface

• ListIteratorltElementgt extends IteratorltElementgt.
• With a ListIterator,
• can traverse a list in either direction,
• can modify the list during iteration.
• It includes a method previous that serves as a
  companion to next, and optional methods for
  adding, removing, and setting list elements.

46
Summary

• Providing both array-based and linked
  implementations for List raises the question of
  method performance.
• Array-based access is in constant time.
• Linked based access requires linear time.
• Simple operations that iterate through each List
  element become quadratic for linked
  implementations when elements are accessed by
  index.

47
Summary

• Abstract index iterators.
• Iterators allow us to iterate through each
  element of a List in linear time, regardless of
  the implementing structure.
• Iterator provides operations for traversing a
  List while examining each List element.

48
Summary

• The structure of each List implementation
  dictates the algorithms used to traverse it
• iterator implementations are tightly coupled to
  the structure they traverse.
• Provide each implementation with an inner class
  that implements an appropriate iterator.
• List client is provided with a factory method to
  create iterators suitable for chosen
  implementation.

49
Summary

• List operations that take an index can be
  overloaded with operations that take Iterator
  instances, providing a richer List abstraction.
• Care must be taken in specifying Iterator
  behavior with regard to List modification.
• We chose to mimic the behavior of indexes as
  closely as possible.
• deleting an element with a given index moves
  the next element of the List up to that index
  position.

50
Summary

• Must exercise care when modifying a List
  referenced by an Iterator by a means other than
  with the Iterator.
• For instance, if we delete a List element by
  index, we assume that any Iterators referencing
  the List become invalid.

51
Summary

• Iterators give rise to the internal iterator
  abstraction, where the implementor is in full
  control of the traversal.
• Defined a List method forEachDo that performed an
  operation provided as an argument on each element
  of the List.

52
Summary

• Short tour of CollectionltElementgt interfaces and
  abstractions in the standard Java package
  java.util.
• Collection interface provides a very rich
  abstraction with several implementations.
• List is an interface that extends Collection and
  models a sequential collection in which elements
  can be accessed by index.
• java.util also provides iterators for Collections.
