CHALLENGE

1
(No Transcript)
2
Overall Goal

• To understand the genetic basis of plant
  adaptation to adverse drought prone environments.
• To identify and characterize genes and gene
  regulatory networks that contribute to
  adaptation.
• To identify, map and utilize beneficial alleles
  for traits that contribute to improved crop
  productivity in adverse environments.

3
Focus on Sorghum

• 5th most important cereal grain world wide
• Excellent biomass feedstock for bioenergy
• Reference C4 grass for maize, millet, sugarcane
• 800Mbp genome, 2n 20 (S. bicolor)
• High colinearity with the rice genome (C3 grass)
• Africa center of origin, diverse germplasm
• Excellent drought tolerance
• C4 photosynthesis, thick cuticle, deep roots
• Inducible tolerance, flexible phenology (escape)
• Special avoidance adaptations such as the stay
  green trait

4
Recent Progress in Sorghum Genome Research

• Integrated genetic/physical maps TAMU-ARS,
  AGI/UGA
• Chromosome numbering and cytogenetic architecture
  determined Kim et al., 2005
• 22,000 EST/gene clusters Pratt et al., 2005,
  2006
• Microarray profiling Buchanan et al., 2005
  Salzman et al., 2005
• Map-based cloning validated Klein et al., 2005
• TILLING populations Xin et al., Henry et al.,
  2006
• Transformation technology Howe et al., 2006
• 500,000 methyl filtered sequences Bedell et
  al., 2005
• 8X whole genome sequence DOE/JGI, 2007

5
TAMU-ARS Integrated Sorghum Genome Platforms

• RIL population (BTx623 X IS3620C) - gt 3,000 DNA
  markers
• HICF fingerprinting of BAC libraries - 2,200
  contigs (6X) 1,200 BAC contigs genetically
  mapped using 6D BAC pools
• Chromosome architecture analyzed by BAC FISH
• Sorghum/cereal comparative maps aligned by BAC
  sequencing
• EST/microarray analysis identify genes and
  regulons
• Germplasm diversity, graphical genotypes,
  haplotypes

6
(No Transcript)
7
Integrated Sorghum Genome Map Construction
8
(No Transcript)
9
Cytogenetic Analysis of Sorghum Chr. 3

• 800Mbp
• 10 Chromosomes
• 50 Euchromatin
• 40,000 genes
• 75 of the genes in euchromatin
• Heterochromatin- low recombination

10
(No Transcript)
11
(No Transcript)
12
Map-based Cloning Projects

• Fertility restorer (Rf1)
• Klein et al., 2005
• Aluminum tolerance
• Kochian et al., 2005/6
• Maturity, flowering time
• Childs et al., 1998 Brady et al., 2006
• Midge resistance
• Hardy et al., in progress
• Stay green QTL
• Borrell, Jordan et al., in progress

13
Sorghum Gene Expression
Comparison of sorghum, maize and rice
Biochemical pathways
Microarrays
Regulons
Regulatory elements
14
The Effect of Osmotic Stress on Gene Expression
as determined by qRT-PCR
15
Functional Classification of Osmotically Induced
Genes
Kinase/Phosphatase, Signaling
Transcription, RNA stability
Stress Responsive
Regulatory
Translation
Protein degradation
Growth/ Metabolism
Unknown
Ubiquitous
General plant
Monocot-including rice
Monocot-excluding rice
Sorghum-specific
16
Kinetic and Amplitude-Specific Gene Clusters in
ABA-Treated Roots
10000
10
A
B
1000
1
100
10
0.1
1.
0.1
0.01
100000
100
D
C
10000
1000
10
100
10
1
1
100000
10
F
E
10000
1000
100
10
1
1
1
G
H
1
0.1
0.1
0.01
0.01
0.00
0 h 3 h 27 h
0 h 3 h 27 h
17
Himmelbach et al., 2003
18
rab16/17 Genes from Sorghum, Maize and Rice
16MY
50MY
19
(No Transcript)
20
A
Sb17/Zm17
10
-10
-30
-50
Fold difference
-70
-90
-110
Control3R
ABA3R
ABA27R
Control3S
ABA3S
ABA27S
seed
B
16B/16C
16A/OS17
Zm17/Os17
20
15
10
5
Fold difference
0
-5
-10
Control3R
ABA3R
ABA27R
Control3S
ABA3S
ABA27S
seed
21
Sb Zm ( Os) Comparisons

• Gene complement
• differential gene family expansion
• Biochemical pathways
• MetaCyc enabled pathway comparison
• RiceCyc
• SorghumCyc
• Gene regulation
• regulon structure, cis-elements, etc.
• Traits, QTL, eQTL, CNS

22
Acknowledgements
Genome Map Construction
Gene Expression
Project PIs

• Jeong-soon Kim
• Monica Menz
• Bin Zhou
• Jeff Brady
• Karen Harris
• Natalie Unruh
• Julie McCollum

• Daryl Morishige
• Jeff Brady
• Karen Harris
• Brock Weers
• Sanghyun Lim
• Christina Buchanan
• Ron Salzman

• Patricia Klein
• John Mullet
• Robert Klein

23
Collaborators

• Andy Borrell and David Jordan (DPI) Drought
  tolerance and midge resistance
• Bill Rooney (TAMU) Yield, maturity, fertility
  restoration, grain mold, biomass production
• David Stelly and Jim Price (TAMU) Molecular
  cytogenetics
• Leon Kochian (USDA) Al tolerance
• Jurandir Magalhaes (EMBRAPA Maize and Sorghum)
  Al tolerance
• Darrell Rosenow and Henry Nguyen (TAMU and MU)
  Drought tolerance
• Mitch Tuinstra (KS) Seedling vigor at low
  temperature
• Daryl Pring (USDA) Fertility restoration
• John Burke (USDA) Thermotolerance
• Georgia Davis (MU) Root architecture under
  drought conditions
• Lincoln Stein (CSHL) and Doreen Ware (USDA/ARS,
  CSHL) Incorporation of sorghum data into
  Gramene SorghumCyc pathway development
• Lee Pratt and Marie-Michele Pratt (UGA) Sorghum
  EST production, expression profiling, database
  development
• Catherine Feuillet (Univ. of Zurich) Rph7 locus
• Jeff Bennetzen (UGA) Mapping the Pc locus
• Doreen Ware (USDA/ARS, CSHL) Comparative
  analysis of rice, maize and sorghum
• Stephen Kresovich (Cornell) Sorghum panicle
  architecture, sorghum biomass production

24
Funding Sources

• NSF Plant Genome Program
• Texas AM University System
• USDA-ARS
• Texas Advanced Technology Program
• Australia QDPI, GRDC
• USAID
• Perry Adkission Chair
