Networking for the Grid

1
Networking for the Grid

• Yee-Ting Li
• eScience Summer School _at_ Edinburgh

2
What the GRID is

• Worldwide Distributed System
• Interconnected with networks
• Balancing processors, storage and network
  utilization
• Networking is important to make GRID work

3
Networking Important!

• Only way two grid nodes can communicate with each
  other
• Need ways of determining how efficiently they
  talk
• Focus on
• The characterising how they talk
• The language they use to talk

4
Part 1

• Networking
• Networking Monitoring
• Networks are also transient
• Network performance also varies as youre sharing
  with n million other users
• Sometimes you can notice periodic patterns
  sometimes you cant
• Difficult to analyse and create
  trends/predictions
• Show steps towards

5
Networking 101

• Networking straight forward
• Just connect to the network and it works!
• HA!

6
Networking

• Complex? Gets more complex!
• Each node has its own scheduling priorities
• Routers must serve trillions of data units per
  second!

7
Networking

• Complex stack from which data has to flow to get
  onto network
• Each node on the network also has their own
  stacks
• Routers have IPR on stacks no one knows what
  Cisco stuff looks like!

8
Example Metrics

• Connectivity
• Delay
• One-way delay
• Two-way delay
• Throughput / goodput
• Network path
• Loss
• Jitter

9
Metrics Example

• Video Conferencing
• Needs predictable bit rate
• Doesnt usually matter if bit rate changes too
  much
• Needs constant jitter
• Low one-way delay preferable
• FTP
• Needs reliable transport
• Throughput depends on urgency of data
• Jitter and delay dont matter

10
Network Monitoring Uses

• Monitoring is measuring over long periods of time
• Gives an indication of network performance over
  time a baseline
• Allows comparison of different tools for analysis
• Allows analysis of how different protocols behave
  in different conditions in real life
• Allows tuning of existing protocols to make
  most out of network

11
Possible Users of a NM Web Service

• Network Managers
• See how much bandwidth is being used
• Network Analysts
• Make things faster and better!
• Resource Brokers
• Broker to determine where to send jobs Network
  Cost
• Bandwidth Brokers
• Allocate bandwidth depending on current network
  state
• Replication Managers
• Distribute data only when network is not busy
• QoS Brokers (aka Managed bandwidth Services)
• Universal language for intercommunication..?
• Next Generation FTP
• First look up historical throughputs before
  sending to determine best path

12
GridNM

• Architecture for monitoring the network
• Backend collects data for presentation
• Logs metrics in ASCII log files on a single host
• Allows mesh measurements all nodes performs
  measurements to al other nodes
• Uses standard UNIX infrastructure ssh
• Should be easily adaptable to using Globus
  certifications once interactive processing is
  introduced in EDG.

13
GridNM (cont)

• Uses existing (and future tools) to collect
  metrics
• Modular - uses XML to describe available
  resources
• Hosts
• Tools
• Locks hosts if under measurement prevents other
  tests affecting metrics
• Currently monitoring 6 sites around Europe using
  5 tools

14
GridNM plot
15
Web Service Network Monitoring

• GridNM just one Network Monitoring Program
• Many different programs out there!
• Unify data exchange between different monitoring
  infrastructures

16
piPEs

• Internet2 e2ePI Architecture for network
  monitoring
• Defines information flow to diagnose networks and
  hosts performance white paper
• Incorporates a finger pointing mechanism to
  identify poor performers
• Ideal starting point!
• BUT found out about it too late
• Currently investigating implementation with SLAC
  software web service as possible implementation
  of piPEs software

17
GGF NMWG

• Defines characteristics that are just the values
  that we are interested in
• Defines classes of metrics, e.g. bandwidth, delay
  etc. that these characteristics report
• Defines singleton and derived characteristics
• Defines samples of data and their inherent
  sampling patterns
• Timestamps
• Still in draft form

18
GGF NMWG cont. / Schema Design

• As its all in XML, designing a XML schema to
  describe objects to be passed around
• XML Schema Document (XSD)
• Focusing actually implementing what the NMWG
  document says and doesnt say
• Note We are also tackling this from a pure OO
  design too however, due to technical
  differences between objects in C, Java and
  SOAP/XML then there may be issues to overcome

19
Part 2

• Network Communication Languages
• Known as transport protocols - determines how
  applications put traffic into the network
• Sits on top of IP common language of the
  internet

20
Transport Level Protocols

• TCP (HTTP, FTP, GridFTP) used for file transfer
• Gives guarantee on delivery
• All data is copied precisely
• Performance can be poor
• Respects other internet users
• UDP (Real, H323) used for video conferencing
• Gives no guarantees on delivery
• Data may be incomplete
• Performance good
• Doesnt respect other internet users

21
UDP vs TCP

• Udp min274, max565, ave493, stdev43
• Tcp min37, max292, ave195, stdev40
• Summary tcp is rubbish! why?

22
Memory and Disk transfers
Fast Ethernet
Over 60Mbits/s iperf gtgt file copy
OC3
Disk limited
File copy disk-to-disk
Iperf TCP Mbits/s
Les Cottrell, SLAC
23
What does TCP do?
Socket buffer size

• TCP retransmits lost data
• Even retransmits data it thinks has been lost!
• Needs and uses a windowing system
• Uses ACKnowledgements from reciever
• Grows a Congestion Window cwnd to determine the
  size of window
• Model
• Tap is independent of Tank size
• Tank filled by application
• Valve opening (data rate) determined by feedback
  from network
• Small tanks mean small data rate
• Large tanks mean larger data rate

TCP Protocol
Network
24
TCP socket buffer sizes

• Iperf observations 490
• Standard socket buffer graph
• Shows linear(ish) region followed by plateau
• Optimal socket buffer size just over 2mB

25
Retransmitted Data

• Graph shows the amount of retransmitted data
  against the throughput
• Retransmitted data is due to loss on the network
• General case ACKs have to timeout before
  resending
• We get more retransmitted data for low
  throughputs with large windows

26
Measuring Performance of Transport Level Protocols

• Need to identify what we want to measure the
  metrics.
• Dependant on the use of the transport protocol.
  Need to analyse application level usage
• For Grid
• Movement of transient data
• File Transfer and Replication
• process jobs or sandboxes
• Movement of Real-Time Data
• Video Conferencing Access Grid
• Real-Time applications

27
Web 100 TCP

• OSI states that we should not know anything about
  the separate layers
• How do we know something is going wrong? your
  throughput decreases!
• Prevents congestion collapse!
• Need Web100! Allows in depth tcp stack analysis
  per flow
• Kernel patch 2.4.16, alpha1.2
• New version 2.4.19 alpha2.0pre1
• Using program to grab web100 results - logvars

28
Reliability of Web100 results

• Still alpha but reliable
• Graph against iperf throughputs correlate very
  well
• At least as reliable as the result offered by
  iperf!

29
Congestion Window

• Looking at the max_cwnd achieved for each
  measurement
• Appears to be two regions
• with high correlation of throughput and max cwnd
• A linear region where we get the a range of
  throughputs for same max_cwnd
• Cwnd never grows beyond 1500kbytes!

30
Bandwidth Delay Product

• Window bandwidth delay
• We want
• Bandwidth 1,000,000,000 bit/sec
• We have
• Delay 19ms
• Window needs to be an average of
• 1e9 19e-3 / 8 bytes
• 2.25mbytes!
• We only achieve 1.5mbytes max!
• Need to implement some monitoring of the degree
  of the average and variation of cwnd for each tcp
  connection

31
TCP Optimisation

• Its actually TCP that is limiting our transfer
  rates!
• All applications use it!
• Understandable as TCP hasnt changed much for the
  last 15-20 years!
• When standard link was about 56kbit/sec!
• Solution Need new TCP implementations!

32
What is High Speed TCP?

• Changes the way TCP behaves at high speed (ie
  large cwnd)
• Standard TCP has two modes
• Slow start (not very slow)
• Congestion Avoidance
• Focuses on Congestion Avoidance Region ie when
  TCP knows (thinks it knows) how well the network
  behaves
• BUT only when we are at high speeds, else do what
  normal Standard TCP does
• Readily deployable 1st step towards Equation
  Based Congestion Control

33
What does it do?

• Standard TCP uses two parameters
• Increase parameter, a
• Decrease parameter, b
• i.e. AIMD( a,b )
• Standard TCP uses
• a1
• b0.5
• High Speed TCP introduces
• a-gta(cwnd)
• b-gtb(cwnd)
• i.e. The value of a and b depends on the current
  congestion window size
• If we increase a more with larger cwnd we can get
  back up to our optimal cwnd size for the
  network path
• If we decrease b less we dont lose as much
  bandwidth due to a small congestion window

34
What exactly does it do?

• Based on the TCP response function
• Relates loss and throughput
• Uses the TCP response function to investigate
  certain parameters
• High_Window, High_Loss largest cwnd needed for x
  throughput and the required loss for that
  throughput
• Low_Window, Low_Loss smallest cwnd when we
  actually switch from Standard TCP and the
  required loss rate for that cwnd size
• High_B the smallest decrease in b when we are at
  a large cwnd
• Equations to transform this information into a
  table for a(cwnd) and b(cwnd)

35
Transport Protocols NG
Name Transport Notes
UDP Blast UDP
Tsunami UDP/TCP Uses TCP as control channel
High Speed TCP TCP For 10Gb/sec links
PGM / CC Modified UDP Multicast UDP new transport protocol
IBP Application logistical networking
