Forecasting Theory

1
Forecasting Theory

• J. M. Akinpelu

2
What is Forecasting?

• Forecast - to calculate or predict some future
  event or condition, usually as a result of
  rational study or analysis of pertinent data
• Websters Dictionary

3
What is Forecasting?

• Forecasting methods
• Qualitative
• intuitive, educated guesses that may or may not
  depend on past data
• Quantitative
• based on mathematical or statistical models
• The goal of forecasting is to reduce forecast
  error.

4
What is Forecasting?

• We will consider two types of forecasts based on
  mathematical models
• Regression forecasting
• Single-variable (time series) forecasting

5
What is Forecasting?

• Regression forecasting
• We use the relationship between the variable of
  interest and the other variables that explain its
  variation to make predictions.
• The explanatory variables are non-stochastic.
• The explanatory variables are independent the
  variable of interest is dependent.

6
What is Forecasting?

• Regression forecasting
• Height is the independent variable
• Weight is the dependent variable

7
What is Forecasting?

• Single-variable (time series) forecasting
• We use past history of the variable of interest
  to predict the future.
• Predictions exploit correlations between past
  history and the future.
• Past history is stochastic.

8
What is Forecasting?

• Single-variable (time series) forecasting

9
Normal Distribution

• A continuous random variable X is normally
  distributed if its density function is given by
• In this case
• EX ?
• var(X) ? 2.

10
Normal Density Function
11
Maximum Likelihood Estimation

• Suppose that Y1, , Yn are continuous random
  variables with respective densities fi(y ?) that
  depend on some common parameter ? (which can be
  vector-valued). Assume that
• ? is unknown
• we observe y1, , yn.
• We want to estimate the value of ? associated
  with Y1, , Yn . Intuitively, we want to find the
  value of ? that is most likely to give rise to
  the data sample y1, , yn.

12
Maximum Likelihood Estimation
Example Consider the data sample y1, , y20
below. Assume that all the densities are the
same, and that the unknown parameter is the mean.
Which of the two distributions most likely
produced the data sample below?
13
Maximum Likelihood Estimation

• Assume that the observations are independent. We
  define the likelihood function
• In maximum likelihood estimation, we choose the
  value of ? that maximizes the likelihood
  function.

14
Maximum Likelihood Estimation

• Furthermore, since logarithm is a monotone
  increasing function, then the value of ? that
  maximizes () also maximizes the log of the
  likelihood function

15
Maximum Likelihood Estimation and Least Squares
Estimation

• Now assume that Yi is normally distributed with
  mean ?i(?), where ? is unknown. Assume also that
  all of the densities have a common known variance
  ? 2. Then the log likelihood function becomes

16
Maximum Likelihood Estimation and Least Squares
Estimation

• Hence maximizing L(? y1, , yn) is equivalent
  to minimizing the sum of squared deviations
• The value of ? that minimizes S(?) is called the
  least squares estimate of ?.

17
Regression Forecasting

• We suppose that Y is a variable of interest, and
  X1, , Xp are explanatory or predictor variables
  such that
• Y h(X1, , Xp ß).
• h is the mathematical model that determines the
  relationship between the variable of interest and
  the explanatory variables
• ? (ß0, , ßm)? are the model parameters.

18
Regression Forecasting

• Further assume that
• we know h (i. e., the model is known), but we do
  not know ß
• we have noisy measurements of the variable of
  interest, Y
• yi h(xi1, , xip ß) ei.

19
Regression Forecasting

• the random noise ei satisfy
• Eei 0 for all i.
• var(ei) ? 2, a constant that does not depend on
  i.
• The eis are uncorrelated.
• The eis are each normally distributed (which
  implies that they are independent), i.e.,
• ei N(0, ? 2).

20
Regression Forecasting

• Note that since
• yi h(xi1, , xip ß) ei
• and
• ei N(0, ? 2)
• then
• yi N(h(xi1, , xip ß) , ? 2).

21
Regression Forecasting

• For any values of the explanatory variables x1,
  , xp, if ? is known, we can predict y as
• y h(x1, , xp ß).
• Since ? is unknown, we use least squares
  estimation to estimate ?, which we denote by
  . In this case, we forecast y as

22
Regression Forecasting
Example
What are the best values for ?0 and ?1?
23
Regression Forecasting
Residuals are the differences between the
observed values and the predicted values. We
define the residual for the ith observation
as A good set of parameters is one for
which the residuals are small.
ei
24
Regression Forecasting

• More specifically, if
• then we choose to minimize

25
Regression Forecasting

• Examples of Regression Models

26
Constant Mean Regression

• Suppose that the yis are a constant value plus
  noise
• yi ?0 ei,
• i.e., ? ?0. Hence
• yi N(?0, ? 2).
• We want to determine the value of ?0 that
  minimizes

27
Constant Mean Regression

• Taking the derivative of S(?0) gives
• Finally setting this equal to zero leads to
• Hence the sample mean is the least squares
  estimator for ?0.

28
Constant Mean Regression

• Example yi ?0 ei,

29
Simple Linear Regression

• Consider the model
• yi ?0 ?1xi ei,
• i.e., ? (?0, ?1). Hence
• yi N(?0 ?1xi, ? 2).
• We want to determine the values of ?0 and ?1 that
  minimize

30
Simple Linear Regression

• Setting the first partial derivatives equal to
  zero gives

31
Simple Linear Regression

• Solving for ?0 and ?1 leads to the least squares
  estimates
• (This is left as a homework exercise.)

32
Simple Linear Regression

• Define e (e1, , en)?, where
• The equations
• imply that

33
Simple Linear Regression

• Example

34
Simple Linear Regression

• Example continued

35
Simple Linear Regression

• Example (continued)
• Regression equation

36
General Linear Regression

• Consider the linear regression model
• or
• where xi (1, xi1, , xip)? and ? (?0, , ?p)?.

37
General Linear Regression

• Suppose that we have n observations yi. We
  introduce matrix notation and define
• y (y1, , yn)?, e (e1, , en)?,
• Note that y is n ? 1, e is n ? 1, and X is n ? (p
  1).

38
General Linear Regression

• Then we can write the regression model as
• Note that y has a mean vector and covariance
  matrix given by
• where I is the n ? n identity matrix.

39
General Linear Regression

• Note that by var(y), we mean the matrix
• Note that this is a symmetric matrix.

40
General Linear Regression

• We assume that the matrix X, which is called the
  design matrix, is of full rank. This means that
  the columns of the X matrix are not linearly
  related.
• A violation of this assumption would indicate
  that some of the independent variables are
  redundant, since at least one of the variables
  would contain the same information as a linear
  combination of the others.

41
General Linear Regression

• In matrix notation, the least squares criterion
  can be expressed as minimizing
• The least squares estimator is given by
• (Proof is omitted.)

42
General Linear Regression

• It follows that the prediction for Y is given by

43
General Linear Regression

• Example Simple Linear Regression

44
General Linear Regression

• Example Simple Linear Regression (p 1)

45
General Linear Regression

• Example Simple Linear Regression (p 1)

46
Properties of Least Squares Estimators

• The least squares estimator of ? is unbiased.
• The (p 1) ? (p 1) covariance matrix of the
  least squares estimator is given by
• If the errors are normally distributed then

47
Properties of Least Squares Estimators

• It follow from the derivation of the least
  squares estimate that the residuals satisfy
• X?e 0.
• In particular,

48
Testing the Regression Model

• How well does the regression line describe the
  relationship between the independent and
  dependent variables?

49
Testing the Regression Model
Explained deviation
Unexplained deviation
50
Testing the Regression Model

• Lets analyze these variations
• But

51
Testing the Regression Model

• Hence
• Total sum of squares (SSTO)
• Sum of squares due to regression (SSR)
• Sum of squares due to error (SSE)

52
Coefficient of Determination

• The coefficient of determination R2 is a measure
  of how well the model is doing in explaining the
  variation of the observations around their mean
• A large R2 (near 1) indicates that a large
  portion of the variation is explained by the
  model.
• A small value of R2 (near 0) indicates that only
  a small fraction of the variation is explained by
  the model.

53
Correlation Coefficient

• The correlation coefficient R is the square root
  of the coefficient of determination. For simple
  linear regression, it can also be expressed as
• It varies between -1 and 1, and quantifies the
  strength of the association between the
  independent and dependent variables. A value of R
  close to 1 indicates a strong positive
  correlation a value close to -1 indicates a
  strong negative correlation. A value close to
  zero indicates weak or no correlation.

54
Correlation
positive correlation
negative correlation
no correlation
55
Testing the Regression Model

• Example Simple Linear Regression
• Regression equation

56
Estimating the Variance

• So far we have assumed that we know the variance
  ? 2. But in general this value will be unknown.
  We can estimate ? 2 from the sample data by

57
Confidence Interval for Regression Line

• Simple Linear Regression Suppose x0 is a
  specified value of the independent variable. A
  100?(1-?) confidence interval for the value of
  the mean of the dependent variable y0 at x0 is
  given by

58
Prediction Interval for an Observation

• Simple Linear Regression A 100?(1-?) prediction
  interval for an observation y0 associated with x0
  is given by

59
What is Forecasting (Revisited)?

• Statistical forecasting is not predicting
• a value
• Statistical forecasting is predicting
• the expected value
• variability about the expected value

60
Homework

• Complete the proof for the result that for the
  simple linear regression model,
• Prove that if Y is a random variable with finite
  expected value, then the constant c that
  minimizes E(Y c)2 is c EY.

61
Homework

• Suppose that the following data represent the
  total costs and the number of units produced by a
  company.
• Graph the relationship between X and Y.
• Determine the simple linear regression line
  relating Y to X.
• Predict the costs for producing 10 units. Give a
  95 confidence interval for the costs, and for
  the expected value (mean) of the costs associated
  with 10 units.
• Compute the SSTO, SSR, SSE, R and R2. Interpret
  the value of R2.

62
Homework

• Consider the fuel consumption data on the next
  slide, and the following model which relates fuel
  consumption (Y) to the average hourly temperature
  (X1) and the chill index (X2)
• Plot Y versus X1 and Y versus X2.
• Determine the least squares estimates for the
  model parameters.
• Predict the fuel consumption when the temperature
  is 35 and the chill index is 10.
• Compute the SSTO, SSR, SSE and R2. Interpret the
  value of R2.

63
Data for Problem 4
64
References

• Bovas Abraham, Johannes Ledolter, Statistical
  Methods for Forecasting, Wiley Series in
  Probability and Mathematical Sciences, 1983.
• Stanton A. Glantz, Bryan K. Slinker, Primer of
  Applied Regression and Analysis of Variance,
  Second Edition, McGraw-Hill, Inc., 2001.
• Spyros Makridakis, Steven C. Wheelwright, Rob J.
  Hyndman, John Wiley Sons, Inc., 1998.
