ECE1747 Parallel Programming

1
ECE1747 Parallel Programming

• Shared Memory Multithreading Pthreads

2
Shared Memory

• All threads access the same shared memory data
  space.

Shared Memory Address Space
proc1
proc2
proc3
procN
3
Shared Memory (continued)

• Concretely, it means that a variable x, a pointer
  p, or an array a refer to the same object, no
  matter what processor the reference originates
  from.
• We have more or less implicitly assumed this to
  be the case in earlier examples.

4
Shared Memory
a
proc1
proc2
proc3
procN
5
Distributed Memory - Message Passing

• The alternative model to shared memory.

mem1
mem2
mem3
memN
a
a
a
a
proc1
proc2
proc3
procN
network
6
Shared Memory vs. Message Passing

• Same terminology is used in distinguishing
  hardware.
• For us distinguish programming models, not
  hardware.

7
Programming vs. Hardware

• One can implement
• a shared memory programming model
• on shared or distributed memory hardware
• (also in software or in hardware)
• One can implement
• a message passing programming model
• on shared or distributed memory hardware

8
Portability of programming models
shared memory programming
message passing programming
distr. memory machine
shared memory machine
9
Shared Memory Programming Important Point to
Remember

• No matter what the implementation, it
  conceptually looks like shared memory.
• There may be some (important) performance
  differences.

10
Multithreading

• User has explicit control over thread.
• Good control can be used to performance benefit.
• Bad user has to deal with it.

11
Pthreads

• POSIX standard shared-memory multithreading
  interface.
• Provides primitives for process management and
  synchronization.

12
What does the user have to do?

• Decide how to decompose the computation into
  parallel parts.
• Create (and destroy) processes to support that
  decomposition.
• Add synchronization to make sure dependences are
  covered.

13
General Thread Structure

• Typically, a thread is a concurrent execution of
  a function or a procedure.
• So, your program needs to be restructured such
  that parallel parts form separate procedures or
  functions.

14
Example of Thread Creation (contd.)
main()
pthread_ create(func)
func()
15
Thread Joining Example

• void func(void ) ..
• pthread_t id int X
• pthread_create(id, NULL, func, X)
• ..
• pthread_join(id, NULL)
• ..

16
Example of Thread Creation (contd.)
main()
pthread_ create(func)
func()
pthread_ join(id)
pthread_ exit()
17
Matrix Multiply

• for( i0 iltn i )
• for( j0 jltn j )
• cij 0.0
• for( k0 kltn k )
• cij aikbkj

18
Parallel Matrix Multiply

• All i- or j-iterations can be run in parallel.
• If we have p processors, n/p rows to each
  processor.
• Corresponds to partitioning i-loop.

19
Matrix Multiply Parallel Part

• void mmult(void s)
• int slice (int) s
• int from (slicen)/p
• int to ((slice1)n)/p
• for(ifrom iltto i)
• for(j0 jltn j)
• cij 0.0
• for(k0 kltn k)
• cij aikbkj

20
Matrix Multiply Main

• int main()
• pthread_t thrdp
• for( i0 iltp i )
• pthread_create(thrdi, NULL, mmult,(void)
  i)
• for( i0 iltp i )
• pthread_join(thrdi, NULL)

21
Sequential SOR

• for some number of timesteps/iterations
• for (i0 iltn i )
• for( j1, jltn, j )
• tempij 0.25
• ( gridi-1j gridi1j
• gridij-1 gridij1 )
• for( i0 iltn i )
• for( j1 jltn j )
• gridij tempij

22
Parallel SOR

• First (i,j) loop nest can be parallelized.
• Second (i,j) loop nest can be parallelized.
• Must wait to start second loop nest until all
  processors have finished first.
• Must wait to start first loop nest of next
  iteration until all processors have second loop
  nest of previous iteration.
• Give n/p rows to each processor.

23
Pthreads SOR Parallel parts (1)

• void sor_1(void s)
• int slice (int) s
• int from (slicen)/p
• int to ((slice1)n)/p
• for( ifrom iltto i)
• for( j0 jltn j )
• tempij 0.25(gridi-1j gridi1j
• gridij-1 gridij1)

24
Pthreads SOR Parallel parts (2)

• void sor_2(void s)
• int slice (int) s
• int from (slicen)/p
• int to ((slice1)n)/p
• for( ifrom iltto i)
• for( j0 jltn j )
• gridij tempij

25
Pthreads SOR main

• for some number of timesteps
• for( i0 iltp i )
• pthread_create(thrdi, NULL, sor_1, (void
  )i)
• for( i0 iltp i )
• pthread_join(thrdi, NULL)
• for( i0 iltp i )
• pthread_create(thrdi, NULL, sor_2, (void
  )i)
• for( i0 iltp i )
• pthread_join(thrdi, NULL)

26
Summary Thread Management

• pthread_create() creates a parallel thread
  executing a given function (and arguments),
  returns thread identifier.
• pthread_exit() terminates thread.
• pthread_join() waits for thread with particular
  thread identifier to terminate.

27
Summary Program Structure

• Encapsulate parallel parts in functions.
• Use function arguments to parameterize what a
  particular thread does.
• Call pthread_create() with the function and
  arguments, save thread identifier returned.
• Call pthread_join() with that thread identifier.

28
Pthreads Synchronization

• Create/exit/join
• provide some form of synchronization,
• at a very coarse level,
• requires thread creation/destruction.
• Need for finer-grain synchronization
• mutex locks,
• condition variables.

29
Use of Mutex Locks

• To implement critical sections (as needed, e.g.,
  in en_queue and de_queue in TSP).
• Pthreads provides only exclusive locks.
• Some other systems allow shared-read,
  exclusive-write locks.

30
Condition variables (1 of 5)

• pthread_cond_init(
• pthread_cond_t cond,
• pthread_cond_attr attr)
• Creates a new condition variable cond.
• Attribute ignore for now.

31
Condition Variables (2 of 5)

• pthread_cond_destroy(
• pthread_cond_t cond)
• Destroys the condition variable cond.

32
Condition Variables (3 of 5)

• pthread_cond_wait(
• pthread_cond_t cond,
• pthread_mutex_t mutex)
• Blocks the calling thread, waiting on cond.
• Unlocks the mutex.

33
Condition Variables (4 of 5)

• pthread_cond_signal(
• pthread_cond_t cond)
• Unblocks one thread waiting on cond.
• Which one is determined by scheduler.
• If no thread waiting, then signal is a no-op.

34
Condition Variables (5 of 5)

• pthread_cond_broadcast(
• pthread_cond_t cond)
• Unblocks all threads waiting on cond.
• If no thread waiting, then broadcast is a no-op.

35
Use of Condition Variables

• To implement signal-wait synchronization
  discussed in earlier examples.
• Important note a signal is forgotten if there
  is no corresponding wait that has already
  happened.

36
Use of Wait/Signal (Pipelining)

• Sequential
• Parallel
• (Pattern -- picture horiz. line -- processor).

37
PIPE

• P1for( i0 iltnum_pics, read(in_pic) i )
• int_pic_1i trans1( in_pic )
• signal( event_1_2i )
• P2 for( i0 iltnum_pics i )
• wait( event_1_2i )
• int_pic_2i trans2( int_pic_1i )
• signal( event_2_3i )

38
PIPE Using Pthreads

• Replacing the original wait/signal by a Pthreads
  condition variable wait/signal will not work.
• signals before a wait are forgotten.
• we need to remember a signal.

39
How to remember a signal (1 of 2)

• semaphore_signal(i)
• pthread_mutex_lock(mutex_remi)
• arrived i 1
• pthread_cond_signal(condi)
• pthread_mutex_unlock(mutex_remi)

40
How to Remember a Signal (2 of 2)

• semaphore_wait(i)
• pthreads_mutex_lock(mutex_remi)
• if( arrivedi 0 )
• pthreads_cond_wait(condi, mutex_remi)
• arrivedi 0
• pthreads_mutex_unlock(mutex_remi)

41
PIPE with Pthreads

• P1for( i0 iltnum_pics, read(in_pic) i )
• int_pic_1i trans1( in_pic )
• semaphore_signal( event_1_2i )
• P2 for( i0 iltnum_pics i )
• semaphore_wait( event_1_2i )
• int_pic_2i trans2( int_pic_1i )
• semaphore_signal( event_2_3i )

42
Note

• Many shared memory programming systems (other
  than Pthreads) have semaphores as basic
  primitive.
• If they do, you should use it, not construct it
  yourself.
• Implementation may be more efficient than what
  you can do yourself.

43
Parallel TSP

• process i
• while( (pde_queue()) ! NULL )
• for each expansion by one city
• q add_city(p)
• if complete(q) update_best(q)
• else en_queue(q)

44
Parallel TSP

• Need critical section
• in update_best,
• in en_queue/de_queue.
• In de_queue
• wait if q is empty,
• terminate if all processes are waiting.
• In en_queue
• signal q is no longer empty.

45
Parallel TSP Mutual Exclusion

• en_queue() / de_queue()
• pthreads_mutex_lock(queue)
• pthreads_mutex_unlock(queue)
• update_best()
• pthreads_mutex_lock(best)
• pthreads_mutex_unlock(best)

46
Parallel TSP Condition Synchronization

• de_queue()
• while( (q is empty) and (not done) )
• waiting
• if( waiting p )
• done true
• pthreads_cond_broadcast(empty, queue)
• else
• pthreads_cond_wait(empty, queue)
• waiting--
• if( done )
• return null
• else
• remove and return head of the queue

47
Pthreads SOR main

• for some number of timesteps
• for( i0 iltp i )
• pthread_create(thrdi, NULL, sor_1, (void
  )i)
• for( i0 iltp i )
• pthread_join(thrdi, NULL)
• for( i0 iltp i )
• pthread_create(thrdi, NULL, sor_2, (void
  )i)
• for( i0 iltp i )
• pthread_join(thrdi, NULL)

48
Pthreads SOR Parallel parts (1)

• void sor_1(void s)
• int slice (int) s
• int from (slicen)/p
• int to ((slice1)n)/p
• for(ifromilttoi)
• for( j0 jltn j )
• tempij 0.25(gridi-1j gridi1j
• gridij-1 gridij1)

49
Pthreads SOR Parallel parts (2)

• void sor_2(void s)
• int slice (int) s
• int from (slicen)/p
• int to ((slice1)n)/p
• for(ifromilttoi)
• for( j0 jltn j )
• gridij tempij

50
Reality bites ...

• Create/exit/join is not so cheap.
• It would be more efficient if we could come up
  with a parallel program, in which
• create/exit/join would happen rarely (once!),
• cheaper synchronization were used.
• We need something that makes all threads wait,
  until all have arrived -- a barrier.

51
Barrier Synchronization

• A wait at a barrier causes a thread to wait until
  all threads have performed a wait at the barrier.
• At that point, they all proceed.

52
Implementing Barriers in Pthreads

• Count the number of arrivals at the barrier.
• Wait if this is not the last arrival.
• Make everyone unblock if this is the last
  arrival.
• Since the arrival count is a shared variable,
  enclose the whole operation in a mutex
  lock-unlock.

53
Implementing Barriers in Pthreads

• void barrier()
• pthread_mutex_lock(mutex_arr)
• arrived
• if (arrivedltN)
• pthread_cond_wait(cond, mutex_arr)
• else
• pthread_cond_broadcast(cond)
• arrived0 / be prepared for next barrier
  /
• pthread_mutex_unlock(mutex_arr)

54
Parallel SOR with Barriers (1 of 2)

• void sor (void arg)
• int slice (int)arg
• int from (slice (n-1))/p 1
• int to ((slice1) (n-1))/p 1
• for some number of iterations

55
Parallel SOR with Barriers (2 of 2)

• for (ifrom iltto i)
• for (j1 jltn j)
• tempij 0.25 (gridi-1j
  gridi1j gridij-1 gridij1)
• barrier()
• for (ifrom iltto i)
• for (j1 jltn j)
• gridijtempij
• barrier()

56
Parallel SOR with Barriers main

• int main(int argc, char argv)
• pthread_t thrdp
• / Initialize mutex and condition variables /
• for (i0 iltp i)
• pthread_create (thrdi, attr, sor,
  (void)i)
• for (i0 iltp i)
• pthread_join (thrdi, NULL)
• / Destroy mutex and condition variables /

57
Note again

• Many shared memory programming systems (other
  than Pthreads) have barriers as basic primitive.
• If they do, you should use it, not construct it
  yourself.
• Implementation may be more efficient than what
  you can do yourself.

58
Busy Waiting

• Not an explicit part of the API.
• Available in a general shared memory programming
  environment.

59
Busy Waiting

• initially flag 0
• P1 produce data
• flag 1
• P2 while( !flag )
• consume data

60
Use of Busy Waiting

• On the surface, simple and efficient.
• In general, not a recommended practice.
• Often leads to messy and unreadable code (blurs
  data/synchronization distinction).
• May be inefficient

61
Private Data in Pthreads

• To make a variable private in Pthreads, you need
  to make an array out of it.
• Index the array by thread identifier, which you
  can get by the pthreads_self() call.
• Not very elegant or efficient.

62
Other Primitives in Pthreads

• Set the attributes of a thread.
• Set the attributes of a mutex lock.
• Set scheduling parameters.
