Title: Interactive Workflow Mining


1
Interactive Workflow Mining
  • Markus Hammori, Joachim Herbst, Niko Kleiner

2
1 Introduction
2 Requirements Analysis
3 Selected Concepts
3.1 MaximumRecognition Layout
3.2 Measure for completeness
4 Prototypical Implementation
5 Conclusion
3
1 Introduction
2 Requirements Analysis
3 Selected Concepts
3.1 MaximumRecognition Layout
3.2 Measure for completeness
4 Prototypical Implementation
5 Conclusion
4
Basic Workflow Mining Approach
Model
5
Basic Workflow Mining Approach
Model
6
Basic Workflow Mining Approach
Model
7
Basic Workflow Mining Approach
Model
8
Why use Workflow Mining?
  • Acquisition Problem
  • Reverse Engineering of Workflow Models
  • Adaptation Problem

9
Why is Workflow-Mining interactive?
  • Basic conditions
  • Non-unique activity names ? Exponential search
    space
  • Best model is a compromise between accuracy and
    model size
  • Human users use soft measures as basis for a
    decision
  • The Standard Workflow Mining Process

10
1 Introduction
2 Requirements Analysis
3 Selected Concepts
3.1 MaximumRecognition Layout
3.2 Measure for completeness
4 Prototypical Implementation
5 Conclusion
11
Approach for requirements analysis
  • Initial situation
  • InWoLvE ? non-Interactive WF Mining prototype
  • ADONIS ? commercial BPMS, used for visualization
  • Approaches for requirements analysis
  • Systematic experiments using the combination of
    InWoLvE and ADONIS
  • Evaluation of other Workflow-Mining Tools with
    respect to support for interactive usage
  • Search for applicable techniques from Data-Mining

12
Interactive Requirements in the Standard
Workflow Mining Process
  • Choosing the initial Parameters for InWoLvE
  • Extract all helpful log information
  • Visualizing and evaluating the results in ADONIS
  • Close integration of user interface and mining
    tool
  • Possibility to influence an ongoing calculation
  • Layout algorithm featuring change resistance and
    well structured layout
  • Modifying parameters for a new iteration
  • Visualize all useful data associated to a model
  • Choosing a result model
  • Provide a measure for the completeness of a model

13
1 Introduction
2 Requirements Analysis
3 Selected Concepts
3.1 MaximumRecognition Layout
3.2 Measure for completeness
4 Prototypical Implementation
5 Conclusion
14
Layout Algorithm - Example for bad change
resistance
15
Layout Algorithm Example for bad structuring
16
Layout Algorithm
  • Task Produce Layout that is resistant to small
    changes
  • Problem Existing Approaches are based on
    incremental changes
  • Solution MaximumRecognition Algorithm
  • Static algorithm
  • Solves dynamic requirements by applying a strict
    set of rules
  • Exploit restrictions of graph model
  • Block-structured split / join blocks
  • Branches of splits are not connected
  • Restricted number of predecessors / successors
    for some vertex types

17
Layout Algorithm - Explanation
  • Sort the Vertices into Levels
  • Modified breadth-first search
  • Vertices must be positioned according to longest
    path

18
Layout Algorithm - Explanation
  • Sort the Vertices into Levels
  • Sort the Vertices into Columns
  • Decompose the graph
  • Split / join blocks
  • Decision paths
  • Compute the width of subgraphs
  • Set vertex positions
  • Sort paths according to well defined order

19
Layout Algorithm - Explanation
  • Sort the Vertices into Levels
  • Sort the Vertices into Columns
  • Split the graph
  • Compute the width of subgraphs
  • Set vertex positions
  • Refinements
  • Draw backward edges around intermediate vertices
  • Position stop vertex

20
1 Introduction
2 Requirements Analysis
3 Selected Concepts
3.1 MaximumRecognition Layout
3.2 Measure for completeness
4 Prototypical Implementation
5 Conclusion
21
Measure for the completeness of models
  • Problem When can we reliably believe that we
    have seen enough examples?
  • Solution Useful approach from Data Mining
  • Divide examples in training-/test-set
  • Estimate pred. accuracy using holdout measure
  • Result gives indication of probability that
    important data was missed
  • Missing Algorithm to validate a trace against a
    model

22
Validating a trace against a model - Basic Idea
  • Sequential
  • activity must match the node
  • activities must be sequential
  • Decision
  • at least one path must be validated
  • Split
  • all required paths must be validated
  • at least one path must be validated
  • arbitrary order between different paths
  • Entire model
  • the stop vertex must be reached
  • all activities in the trace must be used

A1, A2, A5, A4, A6
BPA1
BPA2
BPA3
BPA5
BPA4
BPA6
23
Validating a trace against a model - Basic Idea
  • Sequential
  • activity must match the node ?
  • activities must be sequential ?
  • Decision
  • at least one path must be validated
  • Split
  • all required paths must be validated
  • at least one path must be validated
  • arbitrary order between different paths
  • Entire model
  • the stop vertex must be reached
  • all activities in the trace must be used

A1, A2, A5, A4, A6
BPA1
BPA2
BPA3
BPA5
BPA4
BPA6
24
Validating a trace against a model - Basic Idea
  • Sequential
  • activity must match the node ?
  • activities must be sequential ?
  • Decision
  • at least one path must be validated
  • Split
  • all required paths must be validated
  • at least one path must be validated
  • arbitrary order between different paths
  • Entire model
  • the stop vertex must be reached
  • all activities in the trace must be used

A1, A2, A5, A4, A6
BPA1
BPA2
BPA3
BPA5
BPA4
BPA6
25
Validating a trace against a model - Basic Idea
  • Sequential
  • activity must match the node ?
  • activities must be sequential
  • Decision
  • at least one path must be validated ?
  • Split
  • all required paths must be validated
  • at least one path must be validated
  • arbitrary order between different paths
  • Entire model
  • the stop vertex must be reached
  • all activities in the trace must be used

A1, A2, A5, A4, A6
BPA1
BPA2
BPA3
BPA5
BPA4
BPA6
26
Validating a trace against a model - Basic Idea
  • Sequential
  • activity must match the node ?
  • activities must be sequential ?
  • Decision
  • at least one path must be validated ?
  • Split
  • all required paths must be validated ?
  • at least one path must be validated ?
  • arbitrary order between different paths
  • Entire model
  • the stop vertex must be reached
  • all activities in the trace must be used

A1, A2, A5, A4, A6
BPA1
BPA2
BPA3
BPA5
BPA4
BPA6
27
Validating a trace against a model - Basic Idea
  • Sequential
  • activity must match the node ?
  • activities must be sequential
  • Decision
  • at least one path must be validated ?
  • Split
  • all required paths must be validated ?
  • at least one path must be validated ?
  • arbitrary order between different paths ?
  • Entire model
  • the stop vertex must be reached
  • all activities in the trace must be used

A1, A2, A5, A4, A6
BPA1
BPA2
BPA3
BPA5
BPA4
BPA6
28
Validating a trace against a model - Basic Idea
  • Sequential
  • activity must match the node ?
  • activities must be sequential ?
  • Decision
  • at least one path must be validated ?
  • Split
  • all required paths must be validated ?
  • at least one path must be validated ?
  • arbitrary order between different paths
  • Entire model
  • the stop vertex must be reached
  • all activities in the trace must be used

A1, A2, A5, A4, A6
BPA1
BPA2
BPA3
BPA5
BPA4
BPA6
29
Validating a trace against a model - Basic Idea
  • Sequential
  • activity must match the node ?
  • activities must be sequential ?
  • Decision
  • at least one path must be validated ?
  • Split
  • all required paths must be validated ?
  • at least one path must be validated ?
  • arbitrary order between different paths
  • Entire model
  • the stop vertex must be reached
  • all activities in the trace must be used

A1, A2, A5, A4, A6
BPA1
BPA2
BPA3
BPA5
BPA4
BPA6
30
Validating a trace against a model - Basic Idea
  • Sequential
  • activity must match the node
  • activities must be sequential
  • Decision
  • at least one path must be validated
  • Split
  • all required paths must be validated
  • at least one path must be validated
  • arbitrary order between different paths
  • Entire model
  • the stop vertex must be reached ?
  • all activities in the trace must be used ?
  • ? Validation successful

A1, A2, A5, A4, A6
BPA1
BPA2
BPA3
BPA5
BPA4
BPA6
31
Validating a trace against a model The Reality
  • Simplified example
  • Generally
  • Non unique vertex names
  • Nested concurrencies / loops
  • Solutions
  • Constructive approach that discards impossible
    mappings early
  • Backtracking algorithm for solving concurrency
  • Propagate each successful step to all branches
    (full backtracking)
  • State based memory
  • Visited vertices
  • Depth of nesting

32
1 Introduction
2 Requirements Analysis
3 Selected Concepts
3.1 MaximumRecognition Layout
3.2 Measure for completeness
4 Prototypical Implementation
5 Conclusion
33
Prototypical Implementation
  • MaximumRecognition Layout
  • Measure for completeness
  • Project Management Management of results and
    configuration parameters
  • Post-pruning Hide paths with low probability
    after calculation stopped
  • Temperature-Color-Map Colored highlighting of
    graph sections according to absolute visiting
    frequency

34
1 Introduction
2 Requirements Analysis
3 Selected Concepts
3.1 MaximumRecognition Layout
3.2 Measure for completeness
4 Prototypical Implementation
5 Conclusion
35
Conclusion
  • Accomplished
  • Located aspects of Workflow Mining which require
    user interaction
  • Systematically extracted requirements for
    interactive Workflow Mining system
  • Developed concepts to meet various requirements
  • Prototypical implementation
  • Future Work
  • Improvement of the workflow mining algorithms
  • Application in a real scenario
  • Layout solution for very large models
  • Diff function for locating differences between
    models
  • Reliability measure based on cross-validation

36
Thank you for your attention!
37
Backup Slides
38
MaximumRecognition Layout
39
Layout Algorithms Related Work
  • Simple Approach Use static Layout with Animation
  • Incremental Graph Layout
  • Modify Graph step by step
  • Will only accept certain operation ( e.g. add
    vertex)
  • ? Extract differences between two graphs, split
    into valid operations
  • Foresighted Layout
  • Produces perfect results
  • Will use any static layout algorithm
  • Needs Information about all graphs
  • ? Can not be used for online layout

40
InWoLvE Explanantion of the SplitPar algorithm
41
The lifecycle Workflow-Modells
42
The Search Space
43
ProTo System setup
Write a Comment
User Comments (0)
About PowerShow.com
