Title: EPRI PILC Cable Condition Assessment Project Summary


1
EPRI PILC Cable Condition Assessment Project
Summary
To ICC Educational Program
  • 30 April 2003

EPRI Project Manager Rob Keefe
Presented by Vern Buchholz Powertech Labs
2
Project Objectives
  • Examine five field, diagnostic techniques for
    PILC cable insulation.
  • Compare the results of the field techniques to
    lab measurements
  • Evaluate five diagnostic methods for lead sheath.

3
Project Tasks
  • Collect lengths of PILC cable
  • Field Testing
  • Insulation diagnostics on terminated cables
  • Lead sheath diagnostic tests
  • Tests in Substation on 2.5 km long cable.
  • Lab Testing
  • Conduct chemical lab tests on insulation samples
  • Conduct AC Breakdown tests
  • Conduct water ingress test
  • Conduct accelerated aging test on lead.

4
Cables Tested
Cable Type Age Utility
D 12 kV, 1-Ph, U/J 1938 Reliant Energy
E 5 kV, 3-Ph, U/J gt40 yrs Northern States Pwr
F 14 kV, 3-Ph, U/J 1961 San Antonio Pub Srv
G 5 kV, 3-Ph, Jacket 1956 BC Hydro
H 5 kV, 3-Ph, U/J 1955 BC Hydro
I 15 kV, 3-Ph, Jacket 1986 BC Hydro
J 15 kV, 3-Ph, U/J 1959 BC Hydro
K 12 kV, 1-Ph, Cambric Tapped ? Reliant Energy
5
Cables Tested (cont)
Cable Type Age Utility
L 12 kV, 1-Ph, U/J 1956 Reliant Energy
M 12 kV, 1-Ph, U/J 1952 Reliant Energy
N 15 kV, 3-Ph, Jacket 1993 BC Hydro
O 13.8 kV, 1-Ph, U/J 1931 Toronto Hydro
P 15 kV, 3-Ph, Jacket 1973 BC Hydro
Q 15 kV, 3-Ph, Jacket 1973 BC Hydro
R 26 kV, 3-Ph, Jacket 1969 PSEG
S 15 kV, 3-Ph, Jacket 1986 United Illuminating
6
Cable Cross Sections
7
Diagnostic Tests for Insulation Evaluation on
Terminated Cables
  • Isothermal Relaxation Currents (IRC)
  • Return Voltage Method (RVM)
  • LIpATEST
  • Dielectric Spectroscopy
  • Harmonic Method

8
Isothermal Relaxation Currents (IRC) Model KDA-1
from SebaKMT Sold in North America by HDW
Electronics
9
Isothermal Relaxation Currents (IRC)
10
Return Voltage Method (RVM)
  • Automated measurement
  • Charge _at_ 1kV dc for 30 minutes
  • Quick discharge for 2-5 seconds
  • Measure record return voltage for 30 min.
    (typ.)
  • Discharge for 30 min.
  • Charge _at_ 2 kV dc for 30 minutes
  • Quick discharge for 2-5 seconds
  • Measure record return voltage for 30 min.
    (typ.)

11
Return Voltage Method (RVM) Model CD 31 made by
SebaKMT Sold in North America by HDW Electronics
12
Return Voltage Method (RVM)
13
LIpATEST Leakage Current pico amp
TEST LIpATEST service provided by Powertech Labs
14
(No Transcript)
15
Dielectric Spectroscopy Model IDA 200 from
Programma Sold by General Electric
16
Dielectric Spectroscopy
17
Harmonic Method
18
Lead sheath diagnostic tests
  • Rebound Hardness Tests
  • Dye Penetrant Examination
  • Eddy Current Examination
  • In-Situ Metallography (Replica)
  • Chemical Analysis of small samples

19
Rebound Harness
20
Rebound Harness
21
Rebound Harness
22
Fluorescent Dye Examination
Cracks on the Wrinkled Area of the Lead Sheath
23
Eddy Current Dye ExaminationEstablished NDT
method usually applied to metal structures
Impedance-phase Diagram
Surface of the lead sheath
24
In-situ Metallogaphic Examination
Replica of the surface structure taken on
acetate film
25
In-situ Metallogaphic Examination
Micrograph of the lead directly
Micrograph of the Replica
26
Chemical Tests on paper and oil samples
  • Karl-Fischer Moisture Measurement
  • Fourier Transform Infra-Red (FTIR)
  • Fluorescence Measurements under UV Light
  • Dielectric Thermal Analysis (DTA)

27
AC break down tests
28
AC break down test procedure
  • All cables in ACBD test were 9 m long terminated
    with stress tubes
  • Tested one phase at a time with other phases
    grounded
  • Test started at two times normal operating
    voltage and held for 6 hours
  • Voltage increased in steps equal to normal
    operating voltage
  • At each step voltage held for 6 hours
  • After each failure cable examined to determine
    were cable failed

29
Water Ingress Test
30
Water Ingress Test Procedure
  • Cable P ( 1973) placed in tank under 1 m of tape
    water
  • 3 phase connected in series for current cycling
  • 330 A on for 8 hrs, off for 16 hrs
  • 8 kv always on
  • 12.5 cm slit cut in lead sheath for 1.5 months
  • Slit enlarged to 1 cm by 12.5 cm hole
  • Measure LIpATEST and RVM at intervals
  • Monitor current and voltage for harmonic
    measurement

31
Water Ingress test failure site
32
REPORT
Available on EPRI.com Assessment of
Paper-Insulated Lead-Covered Cable Condition
Electrical, Chemical, and Metallurgical
Condition 1001724 - 2/25/2003
