Parametric Sketching

1
Parametric Sketching
2
Motivation

• Solid primitives not typically supported in
  parametric modelers ? must create a 2D profile,
  then sweep

3
Feature Creation Procedure

• Choose sketch plane, either a
• Default work plane
• Planar face of existing feature
• Work plane
• Rough sketch
• Some geometric constraints applied
• Add/delete geometric constraints
• Parametric dimensioning
• Feature creation
• Repeat 1 - 5

4
Construction Geometry

• Geometry created as part of the parametric
  modeling process that does not represent actual
  part geometry. Includes
• Work planes
• Work axes
• Work points

• Construction geometry appears in feature tree

5
Default Construction Geometry Inventor

• Work planes mutually perpendicular
• YZ
• XZ
• XY
• Work Axes
• X (red)
• Y (green)
• Z (blue)
• Work Point
• Origin of WCS

6
Rough Sketch

• Parametric sketching imitates actual sketching
  process ? rough, approximate

7
Sketch Plane Views
View normal to sketch plane
Isometric View
8
Geometric Constraints

• Typical constraints include vertical,
  horizontal, collinear, concentric, tangent, etc.
• Inventor constraints

9
Display Geometric Constraints

• Software includes option to show constraints

10
Add/Delete Constraints

• User can manually (explicitly) add constraints

concentric
tangent
equal
11
Parametric Dimensions

• Add parametric dimensions to fully constrain
  profile
• Each parametric dimension has two components
• Numerical value
• Name

Fully Constrained Sketch
12
Parametric Dimensions - 2

• Default parameter names (e.g., d0) can be changed
• Equations can be used to generate parameter value

13
Under and Over-constrained Sketches
Angle not necessary
Vertical position of hole not specified

• Under-constrained

Over-constrained
14
Parametric Sketching
