Compact Semiconductor Laser Microphone and RF Transmitter

1
Compact Semiconductor Laser Microphone and RF
Transmitter

• Project Number 15
• Team Members
• Michael Bastin
• Patrick Cox
• TA
• Justin Foster

2
Project Introduction

• Design and engineer an accurate and compact
  optical listening device
• Couple optical device with a secure RF
  transmitter
• Receive transmitted RF signal at an off site
  location and reproduce audio signal originally
  detected by optical device

3
Reasons for Project Selection

• Combines the specialty interests of both team
  members (optics and RF)
• Opportunity to incorporate the newest
  technologies of each field in our project
• Opportunity to improve on previous designs used
  for the same purpose

4
Project Objective

• The end goal of the project is to be able to
  detect sound waves hitting a reflective object at
  one location optically, and then reconstruct
  those sound waves at a remote location via RF
  transmission

5
Uses of end product

• Eaves dropping device
• Room audio recorder for presentations
• Economical Physics Educational Demonstrations

6
Project Block Diagram
Reflective Surface
Interferometer Optics
High Gain Audio Amp
Voice
RF Transmitter
RF Receiver
Listening Equipment
Front End
Back End
7
Front End Components-Voice

• Our entire system must be able to work over the
  frequency range of the human voice (500 Hz to
  2000 Hz) at a minimum
• Must also be sensitive to loudness (amplitude) of
  voice sound waves

8
Front End Components- Reflective Surface

• For our demonstration and testing purposes we
  used a four pane-glass window mounted in a wooden
  frame for our standard
• Any reflective surface can be used to pick up
  sound
• Design and results will vary with different
  surfaces depending on type of surface and mounting

9
(No Transcript)
10
Front End Components- Optical Theory

• A Michelson Interferometer uses constructive and
  destructive interference to measure distance
• Sound waves impact the window and change the
  distance the light travels
• A direct change in distance in converted to a
  change in light intensity at the output of the
  interferometer

11
Front End Components-OpticsOriginal Setup
12
Front End Components-OpticsIntermediate Setup
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
Front End Components-OpticsBOM and Details

• An 850 nm VCSEL used for size and beam quality
  considerations
• 780 nm cube beam splitter
• Graded index mirror for equal reference and
  incident beam strengths
• Pane of glass for incident plane
• Variety of photo-detectors

17
Front End Components-OpticsTesting Procedures
and Results

• Beams must be aligned using infrared viewing
  cards
• Light intensity from each leg of the
  interferometer must be measured at output
• Movement in glass should be evident by voltage
  change across pull down resistor after
  photo-detector

18
(No Transcript)
19
Front End Components-Optics Conclusions

• Non-ideal components lead to poor signal
• Low gain PIN gives very quiet voice
• Large aperture Darlington introduces noise
• 780 nm Beam splitter degrades light quality
• Difficult to use on moving reflective surface
• Opportunity for surface to move more than 1 ?
• No contrast for sharp syllables

20
Front End Components- Audio Amplifier

• The audio amplifier must convert a light beam of
  time varying intensity to a time varying voltage
  wave
• Intensity changes are directly proportional to
  sound waves so the voltage wave should also be
  directly related
• Changes in light intensity are very small and
  must be highly amplified

21
(No Transcript)
22
Front End Components- Original Design Problems

• Photo-detector could not be effectively decoupled
  from rest of circuit caused current and voltage
  delivered to rest of circuit to vary
• Voltage controlled attenuation of signal to fixed
  gain amplifier over complicated since maximum
  gain was needed

23
Front End Components- Audio Amplifier Final
Design Results

• Capacitors heavily used to stabilize circuit
• Cross /- terminals to improve DC
• Small shunt capacitors prevent oscillations
• Decouple AC voice component from DC signal
• Circuitry had severe shielding problems
• Simple amplifier used at extremely high gain
  caused distortion
• Switched power to batteries to clear up high
  frequency noise

24
(No Transcript)
25
Front End Components- Bluetooth Protocol

• Short range radio link being developed to
  connect portable and/or stationary devices
• Uses the 2.4 GHz Industrial Science and Medicine
  Band (FCC non-licensed ISM band)
• Capable of replacing all communication wires
• LAN
• Audio
• COM Ports
• USB

26
Front End Components- Bluetooth Protocol

• High Level Security Encryption via
• Frequency Hopping (1600 Hops/sec)
• Individual Component address
• 128 bit private user keys for authentication and
  encryption
• Three-two way 64 kb/s audio channels and 723 kb/s
  asynchronous data channel
• Output power regulated as distance changes to
  extend battery life

27
Front End Components- Bluetooth Transmitter

• GN Netcom 9000 Wireless Bluetooth Headset
  (donated to us by Motorola PCS)
• Connected to the output of the Audio Amplifier
  via the headset microphone connection
• Participates as a slave in the Bluetooth Piconet

28
Front End Components- Bluetooth Transmission
29
Back End Components- Bluetooth Receiver

• Motorola Bluetooth PCMCIA PC Card (Donated by
  Motorola)
• Used with a Laptop for off site listening
• 10 meter range
• Shorter distance depending upon location

30
Back End Components- Bluetooth Software

• Used Digianswers Bluetooth Software Suite
• Established a General Audio Connection
  connection from Laptop (master) to Headset (slave)

31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
Back End Components- Listening Equipment

• Able to listen to transmitted audio signal in a
  variety of ways
• Laptop Speakers
• Headphones
• Record signal for later playback
• Transmit audio file via Bluetooth LAN to another
  offsite computer
• Transmit audio file via Bluetooth to a PDA

35
Bluetooth Transmission Testing

• Used CATC Merlin BT Protocol Analyzer to record
  and analyze a transmission between the BT headset
  (our transmitter) and the PCMCIA card (our
  receiver)

36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
System Tests

• Function Generator connected to speaker
  outputting a 1 KHz tone at 20 Vpp
• Was not able to hear the sound at the Back End
• The PC speaker may not have been able to create
  large enough sound waves to vibrate the large
  piece of glass
• Most likely explanation Voice comes from
  distance change. Non-affixed window was moved
  and held by sound waves.

43
System Tests

• Person Talking
• Yielded the best results
• Was able to distinguish major syllables of word
  spoken
• Not able to distinguish smaller one syllable
  words
• Somewhat hard to hear because of noise floor
• HVAC System
• Cooling fans of Power Supplies and Computers

44
Outcome

• Successfully engineered a compact optical
  listening device and with RF transmission to an
  off site location
• Successfully utilized two new and up in coming
  technologies to attain our goals

45
Outcome cont.

• Front end not as small as planned
• Can be easily accomplished with proper funding
  (smaller optics and stands, mounting)
• Background noise more significant than originally
  planned for (wind, rain etc)
• Voice reproduction not as clear as wanted
• Distortion from window looseness
• VCSEL was not of high enough quality
• Large aperture photo-detectors

46
Outcome cont.

• Sound source must be close to window
• May have to do with sensitivity of PIN
• Extremely lossy beam splitter and not designed
  for the wavelength of our beam
• Could be caused by not sensitive enough PIN

47
Miscellaneous Things we Learned From Project

• Necessity of having good Power Supplies
• Decoupling Power Supplies from circuits
• Effects of shielding and objects around you on
  circuitry
• Datasheets are not always accurate
• Quality components lead to quality systems

48
Ideas for Improvement

• Use a more efficient beam splitter that has a
  bandwidth centered at 850 nm
• Use a higher quality VCSEL
• Use a higher quality PIN
• Build facing much more secure reflective surface

49
Questions?
