BEE2243 Digital systems

1
BEE2243 Digital systems
2
Lecture 2

• Variable Entered Karnaugh Map
• Hazard and Glitch
• Espresso Software

3
VARIABLE-ENTERED KARNAUGH MAP
4
Minimization of Boolean expressions

• In most cases a canonical Boolean function can be
  minimized
• reduction of the number of gates required to
  implement the corresponding circuit
• To minimize the Boolean function the two step are
• reduce the number of terms
• reduce the number of literal

5
Example of Minimization
6
Karnaugh Maps

• Boolean expressions can be graphically
  represented and simplified using Karnaugh map
• In a Karnaugh map the 2n minterms are represented
  on separate cells
• Boolean expressions may be represented on a
  Karnaugh map if they are expressed in canonical
  form
• The main feature of a Karnaugh map is that each
  square is logically adjacent to the square that
  is physically adjacent to it

7

• Karnaugh map approach is not suitable for
  minimizing functions with more than six variables

8

• 1 are entered in the cells which correspond to
  the function minterm. In the other cells a 0 (or
  nothing) is entered

example
9

• Boolean function on the Karnaugh map can be
  simplified by using the property of adjacency
• In a four variable map, the top and the bottom
  rows and the left and right columns are logically
  adjacent

10
(No Transcript)
11
(No Transcript)
12
(No Transcript)
13
Dont Care Conditions

• Sometime it is not possible to specify the output
  for some input combinations, called dont care
  conditions (they do not have relevant effect on
  the output)
• Functions that include dont care conditions are
  said
• incompletely specified
• In a Karnaugh map, dont care conditions are
• represented with -
• Dont care conditions can be useful to minimize
  the function. Indeed, we can assumed them 1 or 0
  depending on the convenience

14
Example reduction with dont care conditions
15
The Complementary Approach

• Sometime it is more convenient to group on a
  Karnaugh map the 0 rather than the 1.
• The resultant sum-of-products grouping 0 is the
  complement of the desired expression. Then if we
  complement by using DeMorgans theorem we found a
  product-of-sum expression

16
Minimization of Multiple-Output Functions

• In minimizing multiple-output functions, the
  emphasis is on deriving product terms that can be
  shared among the function (instead of considering
  individual function)
• The resulting circuit has fewer gates which means
  lower area
• The determination of shared products term among
  many Boolean functions is an extremely
  complicated task (it can be efficiently performed
  by using a dedicated software)

17
(No Transcript)
18
(No Transcript)
19
VEM (Variable-Entered Maps)

• The variable-Entered map, VEM, is useful to plot
  and n-variable function on and n-1 variable
  Karnaugh map
• One variable is used inside the plot, map-entered
  variable, and becomes one of the possible value
  of the cells
• The use of the map is similar to a simple
  Karnaugh map

20
(No Transcript)
21
Map compressions of a three-variable function.

• A generic three-variable truth table.
• Conventional three-variable Karnaugh map.
• Compressed Karnaugh map of order 2 with x and y
  as the
• map variables and z as the map-entered variable.

22
(d) Compressed Karnaugh map of order 2 with y and
x as the map-entered variable. (e)
Compressed Compressed Karnaugh map of order 2
with x and z as the map variables and y as
the map-entered variable. (f) Karnaugh map of
order 1 with x as the map variable and y and z
as the map-entered variables.
23
Example of a three-variable function. (a) Truth
table. (b) Variable-entered map.
Literal Complement 0 1
24
An example of a variable-entered map with
infrequently appearing variables.
25

• Variable-entered maps grouping techniques.
• Grouping cells with the same literal.
• Grouping a 1-cell with both the z literal and
  the literal.
• Grouping a 1-cell with the z literal.

yz
xz
26
Ex1. Obtaining a minimal sum from a map having
single-variable map entries. (a)Variable-entered
map. (b) Step 1. (c) Step 2.
wxz
yz
xy
27
Ex2. Illustrating optimal groupings on a
variable-entered map.
28
Ex3. Obtaining a minimal sum from a map having
single-variable map entries. (a)
Variable-entered map. (b) Step 1. (c) Step 2.
29
Obtaining a minimal product from a map having
single-variable map entries.
30
Question??

• Exercise1.
