Chpter 9 Normal and Abnormal Sexual Development

1
Chpter 9 Normal and Abnormal Sexual Development
CLINICAL GYNECOLOIC ENDOCRINOLOGY AND INFERTILITY

• OBGY R1 Lee
  Eun Suk

2
Normal Sex Differentiation

• Gender identity the result of the following
  determinants
• Genetic sex
• Gonadal sex
• Internal external genitalia
• The secondary sexual characteristics that appear
  at puberty
• The role assigned by society
• Four major steps which constitute normal sexual
  differentiation
• Fertilization and determination of genetic sex
• Formation of organs common to both sexes
• Gonadal differentiation
• Differentiation of the internal ducts and
  external genitalia

3
Fertilization and Determination of Genetic Sex

• Step 1 in sex differentiationDetermination of
  genetic sex
• Egg (23,X) Sperm (23,X)46,XX genetic
  female
• OR
• Egg (23,X) Sperm (23, Y)46, XY genetic
  male karyotype

4
Formation of Organs Common to Both Sexes

• The fertilized egg multiplies to form a large
  number of cells
• Differentiation of the sex organs in
  this development
• At that stage, both 46,XX 46,XY
  fetuses have similar sex
• organs, specifically
• Gonadal ridges
• Internal ducts
• External genitalia

5
Internal reproductive organs
6
(No Transcript)
7
Gonadal Differentiation

• The important event in gonadal differentiation is
  of the gonadal ridge to become either an ovary or
  a testis
• In males, the gonadal ridge develops into testes
  as a result of a product from a gene located on
  the Y chromosome
• Testis determining factor" (TDF)
• Gonadal medullary resion -gt Sertoli
  cell
• Sex determining region of the Y
  chromosome" (SRY)
• In females, the absence of SRY, due to the
  absence of a Y chromosome, permits the
  expression of other genes
• which will trigger the gonadal ridge to
  develop into ovaries

8
Gonadal Differentiation

• Pseudoautosomal region
• The distal ends of the short arms of the X and Y
  chromosomes
• During meiosis the homologous distal short arms
  of the X and Y chromosomes pairs, and interchange
  of genetic material occurs in autosomes
• Gene deletions in this area of the X chromosome
  (Xp22.3) are associated with various conditions
  short stature , mental retardation, X-
  linked ichthyosis, Kallmanns sydrome

9
Gonadal Differentiation

• Subsequent sexual differentiation requires
  direction by various genes with TDF
• SRY The Y chromosome sex determinants region
• SOX9 An autosomal testis-determining gene
• DAX1 A potential testis-suppressing gene on
  X-chromosome
• SF1 The link between SRY and the male
  development pathway
• WT1 necessary for normal renal and gonadal
  development
• WNT4 A potential ovary-determining gene on an
  autosome

10
Gonadal Differentiation

• SRY
• Sex determining region of the Y chromosome
• Locate on the short arm of the Y chromosome
• Transcription factor contains HMG (high-mobility
  group) box
• - a DNA binding domain gt conrol of
  gene transcrition
• Investigations of the DNA-binding properties of
  the protein of SRY in the promoter P450 aromatase
  (conversion of testosterone to estradiol that is
  down-regulated in the embryo) anti-mullerian
  hormone (responsible for regression of the
  mullerian ducts)
• The expression of SRY in the tissue destined to
  become a gonad directs the cells of this gonadal
  primordium to differentiate as Sertoli cell

11
Gonadal Differentiation

• SOX9 An autosomal testis-determining gene
• (SRY-like box) genes are similar
  in sequence to SRY
• an extra copy of SOX9 developes
  males, even if they have no
• SRY gene XX mice made
  transgenic for SOX9 develop testes
• SF1 Steroidogenic factor, necessary to make the
  bipotential gonad
• Collaboration with SOX9 ? elevate
  levels of AMH transcription
• Wnt4 Activate DAX1 expression
• Lack the Wnt4 gene
• ? Ovary fail to form properly,
  express testis specific markers

12
Postulated cascades leading to the formation of
the sexual phenotypes
13
Summary of key genetic events in early sex
determination

• Migration of primordial germ cells to the
  urogenital ridge
• Differentiation of the bipotential gonadal tissue
  under the direction of WT-1 and SF-1
• SRY activation of male-specific genes,
  especially SOX9, to produce the testes by cell
  proliferation, differentiation, migration and
  vascularization
• Ovarian differentiation by suppression of SOX9
  through the activity of DAX1 and Wnt4

14
Summary of the genetics of gonadal dysgenesis

• Gonadal streaks without germ cells in XX or XY
  (female phenotype)
• Deficiencies in WT-1 or SF-1
• Lack of testicular development in XY individuals
• pure gonadal dysgenesis (female phenotype)

• Deficiencies in SRY or SOX9
• Male phenotype in a 46,XX individual
• Presence of SRY
• Mixed gonadal dysgenesis in mosaics (varying
  phenotype)
• Excess DAX1

15
Internal reproductive organs - Embryonic
development

• Urinary and genital tract
• Closely related, anatomically and embryologically
• Embryologic urinary system -gt important inductive
  influence on developing genital system
• Anomalies in one system are often mirrored by
  anomalies in another system
• Urinary system, internal reproductive organs
  external genitalia
• Develop synchronously at an early embryologic age


16
Kidney, renal collecting system ureters from
nephrogenic cord
17
Mesonephric (Wolffian) duct

• Singular importance for the following reasons
• Grows caudally in developing embryo to open an
  excretory channel into the primitive cloaca and
  outside world
• Serves as starting point for development of the
  metanephros which becomes definitive kidney
• Differentiates into the sexual duct system in
  male
• Although regressing in female fetuses, inductive
  role in development of the paramesonephric or
  mullerian duct

18
Mullerian duct

• Paramesonephric or mullerian ducts - development
• Form lateral to mesonephric ducts
• Grow caudally and then medially to fuse in
  midline
• Contact urogenital sinus in region of the post.
  urethra at slight thickening known as sinusal
  tubercle

19
Duct System Differentiation - Male

• TDF
• Results in degeneration of gonadal cortex and
  differentiation of the medullary region of the
  gonad into Sertoli cells
• Sertoli cells
• Secrete glycoprotein known as anti-mullerian
  hormone(AMH)
• Regression of paramesonephric duct system in male
  embryo
• Signal for differentiation of Leydig cells from
  the surrounding mesenchyme

20
Duct System Differentiation - Female fetus

• In the absence of TDF, medulla regresses and
  cortical sex cords break up into isolated cell
  clusters (-gt primordial follicles)
• In the absence of AMH testosterone
• Mesonephric duct system degenerates
• Then, paramesonephric duct system develops
• Inf. fused portion
• Uterovaginal canal -gt uterus and upper vagina
• Cranial unfused portions
• Open into celomic cavity (future peritoneal
  cavity)
• Fallopian tubes

21
Anti-Müllerian Hormone

• A member of the transforming growth factor-ß
  family
• Regression of Müllerian duct system in male
  embryo
• AMH has an inhibitory effect on oocyte meiosis
• Plays a role in the descent of the testes
• Inhibits surfactant accumulation in the lungs
• Proteolytic cleavage of AMH produces fragments
  that have the ability to inhibit growth of
  various tumor ( a potential therapeutic
  application)

22
Duct System Differentiation

• Leydig cells
• Produce testosterone dihydrotestosterone with
  5a-reductase
• Testosterone
• Responsible for evolution of mesonephric duct
  system into vas deferens, epididymis, ejaculatory
  duct seminal vesicle
• At puberty, leads to spermatogenesis changes in
  primary and secondary sex characteristics
• DHT(dihydrotestosterone)
• Results in development of the male external
  genitalia , prostate and bulbourethral glands

23
External Genitalia Differentiation

• In the female, absence of androgens permits the
  external genitalia to remain feminine
• The genital tubercle becomes the clitoris
• The labioscrotal swellings ? the labia majora
• The urogenital folds ? the labia minora
• In the male, fetal androgens from the testes
  masculinize the external genitalia
• The genital tubercle grows to become the penis
• The labioscrotal swellings fuse to form the
  scrotum

24
External Genitalia
25
Abnormal Sexual Development

26
CLASSIFICATION OF INTERSEXUALITY
Disorders of fetal Endocrinology
27
CLASSIFICATION OF INTERSEXUALITY
Primary gonadal defect Swyer syndrome
28
How many children are born with intersex
conditions?

• A conservative estimate is that 1 in 2000
  children born will be affected by an intersex
  condition
• 98 of affected babies are due to congenital
  adrenal hyperplasia

29
FEMALE PSEUDOHERMAPHRODITISM

• EXCESS FETAL ANDROGENS
• Congenital adrenal hyperplasia
• 21 -hydrxylase deficiency
• 11-hydroxylase deficiency
• 3ß-hydroxysteroid
• dehydrogenase deficiency

• EXCESS MATERNAL ADROGEN
• Maternal androgen secreting tumours (ovary,
  adrenal)
• Maternal ingestion of androgenic drugs

30
21-hydrxylase deficiencycongenital adrenal
hyperplasia
Cholesterol
Pituitary
Pregnenolone
ACTH
Progesterone
17-OH progesterone
Adrenal cortex
21-hydroxylase
?? Androgens
Cortisol
Androgens
Cortisol
31
Masculinized females CONGENITAL ADRENAL
HYPERPLASIA

• There are several different forms of CAH, each
  related to one of the enzymes necessary to
  transform cholesterol to cortisol
  (hydrocortisone)
• StAR / 20,22-hydroxylase, 3 -hydroxysteroid-dehydr
  ogenase / 17-hydroxylase /
  21-hydroxylase and 11 -hydroxylase
• When one of these enzymes is deficient, this
  leads to a hyperfunction and increased size
  (hyperplasia) of the adrenals
• Among the various forms of CAH, the
  21-hydroxylase deficiency is by far the most
  frequent, representing more than 95 of all cases
• Defect in cortisol biosynthesis, with or without
  aldosterone def, androgen excess

32
Masculinized females CONGENITAL ADRENAL
HYPERPLASIA - Biochemistry

• Steroid 21 hyrdoxylase is a cytochrome p-450
  enzyme located in ER
• Catalyzed the conversion of 17-hydoxyprogesterone
  to 11-hydroxycortisol
  precursor of cortisol
• Conversion of progesterone

  to deoxycortisterone precursor of aldosterone

• This enzyme deficiency -gt adrenal cortex is
  stimulated
• over
  production of cortisol precursor

33
Pathways of steroid biosynthesis in the adrenal
cortex
34
Hypothalamic pituitary adrenal axis
Renin-angiotensin-aldosterone axis
35
Clinical menifestation

• Salt wasting type
• severe form with a concurrent defect in
  aldosterone synthesis
• Simple virilizing type normal aldosterone
  biosynthesis
• Both are together termed classic 21-hydroxylase
  deficiency
• There is also a mild,nonclassic form may be
  asymptomatic
• Classic 21-hydroxylase deficiency 1 in 16,000
  births

36
CONGENITAL ADRENAL HYPERPLASIA - salt wasting

• 75 percent of patients with classic
  21-hydroxylase deficiency
• ? severely impaired 21-hydroxylation of
  progesterone
• ? cannot synthesis of aldosterone
• Elevated of 21-hydroxylase precursor aldosterone
  antagonist
• Aldosterone deficiency
• ? hypovolemia and hypereninemia, and
  hyperkalemia (esp. in infant)
• Cortisol deficiency
• ?poor cardiac contractility, poor vascular
  resp. to catecholamine, and
• GFR ? , antidiuretic H ?

37
CONGENITAL ADRENAL HYPERPLASIA - salt wasting

• So together hyponatremic dehydration and shock
• Adrenal medulla depending on the glucocorticoid
  in part
• ? so salt wasting 21hyroxylase deficiency
• ? catecholamine deficiency
• ? exacerbating shock Identify e,
  aldosterone, plasma renin
• (hyperkalemia and low aldosterone and
  hyperreninemia)

38
Ambiguous genitalia

• Girls with classic 21-hydroxylase deficiency
• exposed to high level of adrenal androgen
  level (GA 7 wks)
• Girls with ambiguous genitalia
• -a large clitoris
• -rugated and partially fused labia
  majora
• -uterus,fallopian tubes, and ovaries
  normal
• Boys
• -no overt signs of the disease
• except variable and subtle
  hyperpigmentation
• and penile en-largement

39
Postnatal virilization

• Exposed to the high levels of sex steroids
• Rapid growth (usually androgen effect)
• Advanced bone age ? premature epiphyseal closure

  (androgens extragonatal aromatization of
  estrogen)
• Pubic and axillary hair early develop
• Girl clitorial growth
• Young Boys penile growth
• Long term stimulation central precocious puberty

40
Linear growth

• A meta-analysis of data from 18 centers showed
• 1.4 SD below the population mean
• Both undertreatment and overtreatment risk for
  short stature
• Undertreatment causing premature epiphyseal
  closure induced
• by high levels of sex
  steroids
• Overtreatment glucocorticoid-induced inhibition
  of the growth

41
Reproductive function

• Girls problem at the reproductive system
• -oligomenorrhea, amenorrhea
• -prenatal androgen exposure effect to
  sex-role behavior
• Boys fewer problems

42
CONGENITAL ADRENAL HYPERPLASIA - Diagnosis
43
CONGENITAL ADRENAL HYPERPLASIA

• Normal infant 100ng/dl (17 hydroxyprogesterone)
• Affected infants10000ng/dl ?
• New born -gt screening test
• 10 (severe affected infant) 17
  hydroxyprogesterone level ?
• Preterm or sick infants -gt 17 hydroxyprogesterone
  level ??
• The severity of hormonal abnormalities depends
  on the type of 21-hydroxylase def
• Salt wasting 17-hydroxyprogesterone
  100000ng/dl

44
CONGENITAL ADRENAL HYPERPLASIA

• Random 17-hydroxyprogesterone(17-Ohpro) gt80 ug/L
  or 242 nmol/L (nl lt2.95 ug/L or 9 nmol/L)
• Salt losing gt nonsalt loser
• -gt corticotropin stimulation test unneeded
• Genetic analysis -gt prenatal testing
• Nonclassic CAH random 17-OHpro nl
• -gt Screening
• early morning basal 17-OHpro level
  gt1.5 ug/L (4.5 nmol/L) in children
• gt2.0 ug/L(6nmol/L) in women during
  follicular phase of menstrual cycle
• -gt Corticotropin ST(250ug of
  tetracosactide(cosyntropin) )
• any time during the day gt positive
  17-OHpro gt15.0 ug/L(45nmol/L)

45
CONGENITAL ADRENAL HYPERPLASIA

• Heterozygote carrier
• mild elevation, 17-OHpro lt10 ug/L(30nmol/L)
  following CST
• Carrier symptoms or signs of the disease
• Premature adrenarche 1/3 heterozygote carriers
  of 21-OH def (recent)
• 17-OHpro 10-15 ug/L
• -gt DDx of heterozygote carrier or homozygote
  affected Pt
• -gt Genetic analysis

46
CONGENITAL ADRENAL HYPERPLASIA Management

• According to the clinical course hormonal level
• Purpose
• normal growth, B.Wt, pubertal development,
  optimal adult height
• Growth velocity, body Wt velocity, bone age
  maturation F/U
• Classic 21-OH def
• -gt glucocorticoid adrenal androgen
  secretion ?
• -gt mineralocorticoid electrolytes plasma
  renin activity normalization

47
Treatment Problems

• Hypercortisolism (iatrogenic Cushings syndrome)
  - Sn Sx
• obesity, growth failure, adult short
  stature, striae,
• osteoporosis, hyperlipidemia
• Symptoms of hyperandrogenism
• virilism, infertility of female, precocious
  virilisation of male,
• early puberty, adult short stature

48
Glucocorticoid and mineralocorticoid therapy

• Hydrocortisone of physiologic dose
• -gt corticotropin androgen production
  suppression (?) 6 mg/m2/day
• Hydrocortisone 12-15mg/m2/day -gt sufficient
  androgen suppression
• 20 mg/m2/day (neonatal period)
• 25 mg/m2/day -gt do not use
• Dose variability factor
• Indivudual variation in the metabolism and
  sensitivity
• Previous degree of hypothalamic-pituitary-adrenal
  axis suppression
• High dose glucocorticoid short course therapy

49
Glucocorticoid and mineralocorticoid therapy

• Mineralocorticoid (fludrocortisone)
• plasma renin activity -gtmid normal range
• Dose 100-200 ug/day
• Nonsalt losing elevated plasam renin activity
• Infant with salt losing NaCl supply -gt1-2
  g/day
• 17mEq Na/NaCl 1g

50
CONGENITAL ADRENAL HYPERPLASIA Monitoring
therapy

• Commonly, serum 17-hydroxyprogesterone
  androstenedione level
• Testosterone level in female and prepubertal male

• Test time early morning(800 AM)
• Target level of 17-OHpro 4-12 ug/L (12-36
  nmol/L)

51
CONGENITAL ADRENAL HYPERPLASIA Prenatal therapy

• Classic CAH fetus pregnant women
• Dexamethasone-gt fetal pituitary adrenal
  axis inhibition
• affected females genital ambiguity?
• Risk mother father - carrier
• -gt classic CAH females 1/8
• Masculinisation of external genitalia
• 6weeks gestation -gt start Tx
• Chorionic villi sampling or amniocentesis
• -gt male or unaffected female -gt Tx stop
• Affected female -gt70 normal birth or sl
  virilization

52
(No Transcript)
53
Incompletely Masculized Males
54
What is AIS?

• A genetic condition where affected people have
  male chromosomes male gonads with complete or
  partial feminization of the external genitals
• An inherited X-linked recessive disease with a
  mutation in the Androgen Receptor (AR) gene
  resulting in
• Functioning Y sex chromosome
• Abnormality on X sex chromosome
• Types
• CAIS (completely insensitive to AR
  gene)-External female genitalia -Lacking female
  internal organs
• PAIS (partially sensitive-varying
  degrees)-External genitalia appearance on a
  spectrum (male to female)
• MAIS (mildly sensitive, rare)-Impaired sperm
  development and/or impaired masculinization
• Also called Testicular Feminization

55
Androgen Receptor Gene

• AIS results from mutations in the androgen
  receptor gene, located on the long arm of the X
  chromosome (Xq11-q12)
• The AR gene provides instructions to make the
  protein called androgen receptor, which allows
  cells to respond to androgens, such as
  testosterone, and directs male sexual
  development
• Androgens also regulate hair growth and sex drive
• Mutations include complete or partial gene
  deletions, point mutations and small insertions
  or deletions

56
The Process of Sexual Development

• In AIS the chromosome sex and gonad sex do not
  agree with the phenotypic sex
• Phenotypic sex results from secretions of
  hormones from the testicles
• The two main hormones secreted from the testicles
  are testosterone and mullerian duct inhibitor
• Testosterone is converted into dyhydrotestosterone

• Mullerian duct inhibitor suppresses the mullerian
  ducts and prevents the development of internal
  female sex organs in males
• Wolffian ducts help develop the rest of the
  internal male reproductive system and suppress
  the Mullerian ducts
• Defective androgen receptors cause the wolffian
  ducts genitals to be unable to respond to the
  androgens testosterone and dihydrotestosterone

57
AIS Fetus Development

• Each fetus has non-specific genitalia for the
  first 8 weeks after conception
• When a Y-bearing sperm fertilizes an egg an XY
  embryo is produced and the male reproductive
  system begins to develop
• Normally the testes will develop first and the
  Mullerian ducts will be suppressed and
  testosterone will be produced
• Due to the inefficient AR gene cells do not
  respond to testosterone and female genitalia
  begin to form
• The amount of external feminization depends on
  the severity of the androgen receptor defect
• CAIS complete female external genitalia
• PAIS partial female external genitalia
• MAIS Mild female external genitalia, essentially
  male

58
5-alpha reductase deficiency

• Normal internal genitalia
• testes secrete T, MIH causes Mullerian
  ducts to degenerate
• Lack of DHT leads to inadequate masculinization
  of external genitalia at birth
• Testes in labia or inguinal canal
• Urogenital sinus urethra blind vagina
• Prostate gland small or absent
• At puberty, lots of T
• ? testes descend, scrotum darkens, phallus
  enlarges, muscular
• deep voice

59
Testing for AIS

• Tests
• During Pregnancy
• Chorionic Villus Sampling (9-12 weeks)
• Ultrasound and Amniocentesis (after 16 weeks)
• After Birth
• Presence of XY Chromosomes
• Buccal Mouth Smear
• Blood Test
• Pelvic Ultrasound
• Histological Examination of Testes

60
Treatments

• Surgery
• Orchidectomy or gonadectomy
• Removal of the testes
• Vaginal lengthening
• Genital plastic surgery
• Reconstructive surgery on the female genitalia if
  masculinization occurs
• Phalloplasty
• Vaginoplasty
• Pressure dilation
• Clitorectomy
