Title: Lysbilde%201


1
A brief introduction to MR physics
2
Hydrogen/Proton A spinning top
3
With and without the presence of an external
magnetic field (B0) in the z direction
Randomly oriented hydrogen atoms (spins) in
absence of an external magnetic field
The protons aligns with the external field Low
field 0.47 T, Clinical fields B0 1.5 3.0 T
Together they create a macroscopic magnetic M0
vector parallel with B0 (and z)
4
Radio Frequency (RF) coils in the xy-plane (B1)
A 900 pulse flips M0 into the xy-plane
M0 aligns with the z-axis
RF on
5
An oscillating FID signal in the xy-plane
(readout plane) When the protons aligns with the
external field again they give up their energy to
their surroundings. This signal is registered by
a coil (like an antenna)
RF off The spins relax back to their
equilibrium state (along z)
6
T1 relaxation The time it takes for M0 to
realign with B0 after the influence of an RF
pulse. Dependent of the exchange with the media.
T1 is short for fat and long for water
T2 relaxation The time it takes before the
spins (protons) reach equilibrium after
spin-spin exchange and thereafter dephasing in
the xy-plane T2 ? T1
7
The MR signal
  • Intrinsic parameters T1, T2, n(H)
  • Instrument parameters TR, TE
  • Pulse sequences vary TR and TE
  • Contrast agents manipulate T1 and T2

8
Contrast Agents (CA)
  • Even though MR has high specificity, CA are often
    used to better visualize specific structures and
    pathology
  • Indirect effect on hydrogen spins. The relaxation
    times (T1 and T2) are reduced, thus signal
    changes
  • Either T1 or T2 CAs, where T1 CAs increase the
    signal and gives positive contrast, whereas T2
    CAs reduces the signal and gives negative
    contrast in the image

9
Different CAs (exogenous)
  • Paramagnetic
  • Positive contrast n(H) increases, T1 reduces and
    T2 increases
  • Much stronger T1 than T2 reducing effect, which
    in total gives an improved T1 contrast by the
    addition of paramagnetic agents
  • T1-weighted images
  • Some paramagnetic ions Gd3, Mn2

10
  • Electron spin
  • Non-paired electrons
  • A magnetic moment analogous to the magnetic
    moment of protons
  • The magnetic moment of an electron 600 times
    stronger than the magnetic moment of protons, and
    will therefore have an influence on them
  • Change the magnetic environment of the protons,
    where T1 and T2 will be reduced

1H
Paramagnetic ion
11
Efficacy in a homogenous solution
  • Relaxivity r1 and r2
  • The measured effectiveness of an CA to reduce T1
    and T2
  • Given in (s mM)-1
  • A simple linear formula
  • T1 -1with CA T1-1without CA r1 CA

12
T1 relaxation shorter and shorter T1 (CA)
stronger and stronger signal in a T1 weighted
image where the CA is present

13
Different types
  • Free metal ions are toxic in large quantities,
    that is why they are bound to a chelate. This
    shielding influence the effectiveness of the
    CA, and safety is competing with efficacy
  • Few side effects does not result in severe
    allergic reactions as with X-ray CAs
  • Extracellular (infarction, pathology)
  • Gd-DTPA (Magnevist)
  • Liver CA (pathology)
  • MnDPDP (Teslascan)
  • Intravascular/E.C. (few protons lt 5 of all the
    tissue protons). Large complexes which are
    trapped in the blood pool
  • Gd-DTPA-BMA (Omniscan)

Small molecules
Schering,Amersham Health/GE Healthcare
14
(No Transcript)
15
Water Exchange Theory
16
Intrinsic values
17
A relaxivity in each homogenous water
compartment
Intracellular relaxivity r1ic
18
Monoexponential decay Inversion Recovery pulse
sequence
Mz(t) M0 ( 1 - 2e-t/T1 )
19
FAST EXCHANGE
T1
?-1
20




The apparent biexponential T1s are sums of the
intrinsic relaxation rates and the water
exchange in each compartment
1
1
1


T
T
?
1
ic
1
ic
ic
1
1
1


T
T
?
1
ec
1
ec
ec
21
SLOW EXCHANGE Apparent values
22
Biexponential signal
Mz pic ( 1 - 2e-t/T1ic ) pec ( 1 -
2e-t/T1ec ))
1/? (PA)/V
23
Intermediate exchange
24
2 SX equation for R1ic
25
2 SX equation for R1ec
26
2 SX equation for pic and pec
27
Calculating relaxivities, lifetimes of water and
population fractions
28
EKSTRASTOFF
29
(No Transcript)
30
E.C. Contrast Agent
Intravascular
1H20ic
?p-1
1H20p
?ic-1

Plasma
1H20CAp
CAp
?m-1
Extracellular
Vessel wall
Interstitium
1H20ic
? ic-1
?m-1
Intracellular
CAec 1H20ec
1H20CAec
?ec-1
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
Conclusions
  • Multi-component analyses of T1 and T2 revealed
    two compartments with different chemical
    environments in the heart cells detectable with
    0.47 T MR

35
Main findings
  • Two compartment model more suitable for T1
    analysis
  • Close correlation between tissue Mn content and
    T1relaxation
  • Slow water exchange in excised cardiac tissue
  • Remarkably high relaxivity of intracellular Mn2
    ions

36
Physiology and Mn content
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
