Massively Parallel Cosmological Simulations with ChaNGa

1
Massively Parallel Cosmological Simulations with
ChaNGa

• Pritish Jetley, Filippo Gioachin, Celso Mendes,
  Laxmikant V. Kale and Thomas Quinn

2
Simulations and Scientific Discovery

• Help reconcile observation and theory
• Calculate final states of theories of structure
  formation
• Direct observational programs
• What should we look for in space?
• Help determine underlying structures and masses

3
Computational Challenges

• N 1012
• Direct summation forces would take 1010
  Teraflop years
• Need efficient, scalable algorithms
• Large dynamic ranges
• Need multiple timestepping
• Irregular domains
• Balance load across processors

4
ChaNGa

• Uses Barnes-Hut algorithm
• Based on Charm
• Processor virtualization
• Asynchronous message-driven model
• Computation and communication overlap
• Intelligent, adaptive runtime system
• Load balancing

5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
Major Optimizations

• Pipelined computation
• Prefetch tree chunk before starting traversal
• Tree-in-Cache
• Aggregate trees from all chares on processor
• Tunable computation granularity
• Response time for data requests vs Scheduling
  overhead

9
Experimental Setup
dwarf 5 and 50 million particles
lambs 3 million particles
drgas 700 million particles
hrwh_LCDMs 16 milllion particles
10
Experimental Setup (contd.)?

• Platforms

11
Parallel Performance
A comparison of Parallel Performance with
PKDGRAV. (Dwarf' dataset on Tungsten.)?
12
Scaling Tests
IBM BG/L
Cray XT3
Poor scaling
13
Towards Greater Scalability

• Load Imbalance causes poor scaling
• Static balancing not good enough
• Even number of particles ! Even work
  distribution
• Must balance both computation communication

14
(No Transcript)
15
(No Transcript)
16
Results with OrbRefineLB

• Different datasets
• OrbRefineLB

17
(No Transcript)
18
(No Transcript)
19
Balancing Load in MS Runs

• Different strategies for different phases
• Multiphase instrumentation
• Model-based load estimation (first few small
  steps)?

0
0
1
2
20
Preliminary Results
Singlestepped (613 s)?

• Dwarf dataset
• 32 BG/L processors
• Different timestepping schemes

Multistepped (429 s)?
Multistepped with load balancing (228 s)?
21
Preliminary Results

• 50 reduction in execution time

• Lambb dataset
• 512 and 1024 BG/L processors
• Singlestepped vs load-balanced multistepped

• Multistepping and overdecomposition

• Lambb dataset
• 1024 BG/L processors
• Varying num. TreePieces

More TreePieces ? greater load balance
22
Future Work

• SPH
• Alternative decomposition schemes
• Runtime optimizations to reduce communication
  cost
• More sophisticated load balancing algorithms
• Account for
• Complete simulation space topology
• Processor topology (reduce hop-bytes)?

23
Conclusions

• Introduced ChaNGa
• Optimizations to reduce simulation time
• Load imbalance issues tackled
• Multiple timestepping beneficial
• Balancing load in multistepped simulations
