Concerns and Needs related to Alaska Coastal Infrastructure

1
Concerns and Needs related to Alaska Coastal
Infrastructure

• Orson P. Smith, PE, Ph.D.

2
Alaskan Engineers' Viewsof Global Warming
Challenges

• Proven responses to most warming problems exist
• Accurate prediction of changes will save money
• Existing data needs to be synthesized
• Statewide monitoring is warranted
• Data and technology transfer can be improved
• Need revised design codes, manuals, and software

3
Sea Level Rise Other Trends in Alaska Complicate
Predictions
Intergovernmental Panel on Climate Change, 2001
?
Figures from EPA website http//www.epa.gov/global
warming/
4
Permafrost Coasts

• Permafrost changes
• Thaw subsidence, onshore and offshore
• Increased flux of sediments into streams and the
  coastal ocean

5
Permafrost foundations at risk

• About 90,000 Alaskans live in permafrost areas
• 21 of Alaskas road miles are on continuous
  permafrost
• 57 road miles are on discontinuous permafrost
• All Beaufort Chukchi Sea and much of Bering Sea
  coastal infrastructure is on permafrost

6
Coastal communities at risk

• Sea level rise (0.1 0.9 m
  by 2100)
• Flooding
• Erosion
• Salt intrusion
• More frequent and intense storms (maybe)
• Reduced ice cover (yes!)
• More surges
• More wave energy
• Coastal erosion may make some communities
  untenable
• A baseline of Alaska coastal conditions does not
  exist

Shishmaref
Little Diomede, Alaska
Little Diomede
Kivalina
7
Sea Ice Changes

• Lesser sea ice extent, thickness, and duration
• More open water over longer periods
• Longer fetches and higher waves at the coast

8
Anticipated Changes in Streamflow

• More rainfall in winter
• Increased winter runoff
• Mid-winter breakups
• Mid-winter ice jams
• Accelerated thawing of permafrost banks
• Accelerated bank erosion
• Higher sediment loads to coast

Alaska Ice Jams
Cold Regions Research Engineering Laboratory
9
Bridge and culvert problems
MP 228 Richardson Highway One Mile Creek Bridge
photo provided by George Levasseur, Alaska
Department of Transportation Public Facilities
10
Marine transportation benefits

• River Transportation
• Flow increases could improve commercial river
  navigability
• Ocean Transportation
• Less ice
• New northern ports

11
Southcentral Alaska coastal issues
12
Cook Inlet Bluff Erosion
13
Cook Inlet Bluff Erosion
14
Homer Spit from about 2 miles
15
Eroding bluffs NW of Homer Spit
16
Role of tidal currents?
17
Opportunities for public professional education
in Alaska
18
UAA School of EngineeringPort Coastal
Engineering Courses

• CE A674 Waves, Tides, Ocean Processes
• CE A675 Design of Ports Harbors
• CE A676 Coastal Engineering
• CE A677 Coastal Measurements and Analysis
• GIS A333 Marine Applications of GIS
• GE0 A433 Hydrographic Surveying
• by televideo with UAF and UAS

19
UAA and UAFArctic Engineering MS Programs

• CE A603 Arctic Engineering
• CE A681 Frozen Ground Engineering
• CE A682 Ice and Snow Engineering
• CE A683 Arctic Hydrology Hydraulic Engineering
• CE A684 Arctic Utilities
• ME A685 Arctic Heat Mass Transfer
• ME A687 Arctic Materials
• UAA required course

20
Existing Alaska Coastal Research Programs

• NOAA Alaska Sea Grant College Program
• Research topics aligned with National and State
  Sea Grant priorities
• Includes extensive public outreach capability
  (Marine Advisory Program)
• MMS Alaska Coastal Marine Institute
• Research topics aligned with MMS-Alaska priorities

21
Alaska littoral baseline assessment- an
opportunity for interagency collaboration

• Locate present shoreline
• Tidal datum? Ellipsoid standard? Bluff shores?
  Sea level change? Tectonic change? Permafrost
  thaw subsidence?
• Define littoral cells
• By longshore sediment sources and sinks
• By wave exposure
• By tide and tidal current regime
• Quantify longshore sediment transport
• Quantify rates of coastal sediment supply (e.g.,
  rivers and bluffs) and loss (to offshore sinks)

22
Improve measurement and modeling of fjord wind
and wave relationships

• e.g., 10 March 2005 storm at Whittier
• Orographic funneling of winds difficult to
  quantify
• Fetch-limited predictions are not conservative

Photo provided by Sandra Morris, PND, Inc.
23
Improve design of erosion control responses in
high tide ranges and cold climates

• Emphasize tech transfer and public outreach
• Develop guidance for assessing wave and tidal
  current interaction

24
