Development of Indicators for Integrated System Validation

1
Development of Indicators for Integrated System
Validation

• Leena Norros Maaria Nuutinen Paula Savioja
• VTT Industrial Systems Work, Organisation and
  System Usability Research
• 20.1.2005

2
Outline of the Presentation

• NPP control room modernizations
• Integrated System Validation (ISV)
• Performance indicators in validation
• Development of the evaluation framework for
  intelligent environments
• Conclusions

3
(No Transcript)
4
NPP Control Room Modernizations

• Current control and automation systems are being
  modernized
• No changes to the degree of automation
• Technological rationale for the change
• Maintenance costs
• Lack of spare parts
• Technological possibilities exist
• Different strategies adopted by the utilities
• Some human centered design principles implicitly
  adopted in the projects
• Happening at the same time
• OL3
• Generation change within the personnel of
  existing NPPs

5
NPP Control Room Modernizations The Effective
Changes

• Loss of individual data points and controls in
  the information panels and desks
• The decrease in peripheral information ? Tacit
  knowledge, Process feel and awareness
• Spatial memory ? memorability, skill based
  behavior, response times
• Co-operation within the crew ? communication,
  group awareness
• Adoption of individual information displays
• Sequential use of information instead of
  parallel, key hole effect ? Windows and dialogs
  might hide information
• Active searching required ? understanding of the
  available resources
• Secondary tasks from manipulating the interface ?
  possibility of confusion, response times
• Higher abstraction level in the information ?
  orientation, constraints and possibilities
• Adoption of large screen displays
• Basis for shared co-operation ? group SA
• Higher abstraction level in the information

6
NPP Control Room Modernizations Model of the
Change
Control and automation system UI
User practices
Process performance
7
How do we know that a complex system can be
safely operated?
8
Integrated System Validation

• Performance based evaluation of the integrated
  design, in order to ensure that the human system
  interface supports the safe operation of the
  plant
• Use of full scope simulator
• The effect of contextual and situational factors
  to the safety of operation must be evaluated
• Towards the end of the design process
• The total system is available
• After the training period of the operators
• Use of actual crews, representative sample of the
  population
• Use of normal conditions, specific failures,
  accidents, beyond design basis events
• Compare the selected measures with the predefined
  acceptance criteria

9
Integrated System Validation Current Problems

• Which indicators to use
• Which measures reflect the safety
• Which measure are relevant in the change
  situation
• Which measures reflect performance in a way that
  can be generalized
• How to set the criteria
• What is the acceptable level of performance with
  the selected indicators
• The effort needed, the amount of testing required
• Generalization of the results

Norros Savioja 2004, Heimdal et. al. 2004
10
Validation The Problem of the e case

• How to predict what will happen in a very rarely
  occurring beyond design basis, beyond validation
  possibilities, event that nobody predicted ever
  to happen?
• Predictive capabilities of validation procedures?

11
Performance Indicators Development Challenges

• Process performance
• Do not really differentiate enough
• High degree of automation
• Complex defenses within the system
• Thorough training process
• Difficult to anchor to the HF-related changes
  taking place in modernization
• Not predictive of future performance in the
  conditions not tested
• Human performance
• Do not describe how and based on what underlying
  assumptions the crew acts in the situation
• Not predictive of future performance in the
  conditions not tested

12
The Development of the Evaluation Framework
Evaluation Framework Development
Simulation
Evaluation

The Design Process
13
Concept of System Usability

• System Usability The effect of the emerging
  technology on the whole activity system
• In NPP modernizations the effect on process
  performance, user practices, user acceptance
• System Usability denotes how the system works as
  a
• Material
• Cognitive
• Communicative
• tool in an organization promoting the
  fulfillment of the core task

14
Modelling Domain - motives objectives -
functions Situation - constraints
possibilities - resources Complexity -
interactions - dynamics - uncertainty
PRACTICE
Indicators Outcome - process measures - error -
work load - procedure following Way of acting -
orientation - way of perception and action - way
of collaboration - way of communication - way of
using procedures
Assessment Criteria Effectiveness
efficiency - process parameters - number of
errors - TLX - number of deviations Core-task
oriented appropriateness - realistic-objectivistic
- reactive-interpretative - transparency of
actions - shared horizon and meaning -
understanding the rationale as making sense
External good
Situational criteria
Internal good
Assessment of system usability
Data Empirical - orientation interview -
simulator run - stimulated process tracing
interviews - interface interviews Course of
action analysis - goals, perceptions actions -
communications - resource utilisation
EXPERIENCED APPROPRIATENSS
Indicators - trust -utilisation of functional
possibilities
Criteria - Evidence of the possibility for
creating new usage practices and culture
15
Conclusions

• Traditional scientific performance measures do
  not differentiate between UIs in a highly
  automated environment ? more profound criteria in
  assessment are needed
• A system with high system usability induces good
  working practices on the users
• With practices individual users cope with system
  uncertainty which is a critical demand in the NPP
  environment
• In validation practices within a new system will
  be compared to the practices in the baseline
  evaluation within the valid traditional system
• Further work Connect the practice-driven
  performance indicators to the changes in the
  modernization

16
Thank You!
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
Classification of User Practices

• Reactive
• Repetition of pre-learned
• Not understanding the reasoning behind i.e.
  procedures
• Diffuse
• Characteristics of both reactive and
  interpretative
• Interpretative
• Takes into account the situational variation in
  objectives
• Attempts to interpret what contextual factors
  have an effect
• Understands the trade off between the actions for
  acute and chronic cures the effect of ones own
  actions to the overall performance goals of
  operation

22
Practice Related Criteria in Validation
Baseline
Validation
Interpretative
Diffuse
Reactive
Fail Fail Pass
Acceptable Rea validation Reabaseline ?
Int validation Int baseline
