Title: Chapter 11 Operating Systems


1
Chapter 11Operating Systems
2
Outline
  • Functional overview of an operating system
  • Process management
  • Resource allocation
  • CPU allocation
  • Memory allocation
  • Interprocess communication

3
Operating System Overview
  • Operating System Management Functions
  • Operating System Layers

4
Operating System Overview
  • The operating system oversees all hardware
    resources and allocates them to user and
    applications as needed.
  • The operating system performs many low-level
    tasks on behalf of users and application programs.

5
Operating System Overview
  • Operating System Management Functions
  • The operating system manages
  • Hardware resources
  • Users and their programs

6
(No Transcript)
7
Operating System Overview
  • Operating System Layers
  • Command Layer
  • Service Layer
  • Kernel

8
Operating System Layers
9
Operating System Layers
  • Operating System Layers
  • Command Layer the users interface to the
    operating system.
  • Service Layer contains a set of functions
    called by application programs and the command
    layer.
  • Kernel manages resources and directly interacts
    with computer hardware.

10
Outline
  • Functional overview of an operating system
  • Process management
  • Resource allocation
  • CPU allocation
  • Memory allocation
  • Interprocess communication

11
Process Management
  • Process Control Data Structures
  • A process is a unit of executing software that is
    managed independently by the operating system.
  • A process can request and receive hardware
    resources and operating system services.

12
Process Management
  • Process Control Data Structures
  • Process Control Block (PCB) keeps track of each
    process by creating and updating a data
    structure.
  • The PCB is created when the process is created,
    updated when the process changes and deleted when
    the process terminates.

13
Process Management
  • Data included in a PCB
  • A unique process identification number
  • The current state of the process
  • Events for which the process is waiting
  • Resources allocated exclusively to the process
  • Machine resources consumed
  • Process ownership and/or access privileges
  • Scheduling priority

14
Process Management
  • Threads
  • A portion of a process that can be scheduled and
    executed independently.
  • Process light
  • Thread can execute concurrently on a single
    processor or simultaneously on multiple
    processors.

15
Outline
  • Functional overview of an operating system
  • Process management
  • Resource allocation
  • CPU allocation
  • Memory allocation
  • Interprocess communication

16
Resource Allocation
  • Single Process Resource Allocation
  • Multiple Process Resource Allocation
  • Resource Allocation Processes
  • Real and Virtual Resources

17
Resource Allocation
  • Single Process Resource Allocation
  • Involves only two executing programs
    application and operating system.
  • When an application program begins executing, the
    operating system grants it control of all unused
    resources.

18
Resource Allocation
  • Single Process Resource Allocation
  • Most service calls are actually indirect requests
    for system resources.
  • MS-DOS is a single-tasking operating system.

19
Resource Allocation
  • Multiple Process Resource Allocation
  • Multitasking operating systems are the norm for
    general-purpose computers.
  • Multitasking operating systems must be able to
    handle multiple programs and users.

20
Resource Allocation
  • Multiple Process Resource Allocation
  • A multitasking operating system manages hardware
    resources to achieve the following
  • Meet the resource needs of processes
  • Prevent processes from interfering with one
    another
  • Efficiently use hardware and other resources

21
Resource Allocation
  • Resource Allocation Processes
  • Keeps detailed records of available resources.
  • Knows which resource are used to satisfy which
    requests.
  • Schedules resources based on specific allocation
    policies to meet present and anticipated demands.
  • Updates records to reflect resources commitment
    and release by processes and users.

22
Resource Allocation
  • Real and Virtual Resources
  • Real resource a computer systems physical
    devices and associated system software.
  • Virtual resource the resources that are
    apparent to a process or user.

23
Real and Virtual Resources
  • Providing virtual resources that meet or exceed
    resources is accomplished by
  • Rapidly shifting resources unused by one process
    to other processes that need them.
  • Substituting one type of resource for another
    when possible and necessary.

24
CPU Allocation
  • Thread States
  • Interrupt Processing
  • Scheduling

25
CPU Allocation
  • A thread controls the CPU for no more than a few
    milliseconds before it relinquishes control and
    the operating system gives another thread a turn.
  • CPU sharing is called concurrent execution or
    interleaved execution.

26
CPU Allocation
27
CPU Allocation
  • Thread States
  • Ready
  • Running
  • Blocked

28
CPU Allocation
29
CPU Allocation
  • Ready State a thread is waiting for access to a
    CPU.
  • Running State the thread has control of the
    CPU.
  • The thread or its parent process terminates
    normally
  • An interrupt occurs
  • Block State the thread is suspended while an
    interrupt is being processed.

30
CPU Allocation
  • Interrupt Processing
  • A blocked thread is waiting for an event to
    occur.
  • If the event is the correction of an error and it
    can be corrected, the thread remains in the
    blocked state until the error condition is
    resolved otherwise, the thread is halted.

31
Scheduling
  • Preemptive Scheduling
  • Priority-based Scheduling
  • Real-time Scheduling

32
Scheduling
  • Preemptive Scheduling
  • A thread can be removed involuntarily from the
    running state.
  • A running process controls the CPU by controlling
    the content of the instruction pointer.
  • CPU control is lost whenever an interrupt is
    received.

33
Scheduling
34
Scheduling
35
Scheduling
  • Priority-Based Scheduling Methods
  • First come First served
  • Explicit priority
  • Shortest time remaining

36
Scheduling
  • Priority-Based First come first served
  • The scheduler always dispatches the ready thread
    that has been waiting the longest.

37
Scheduling
  • Priority-Based Explicit priority
  • Uses a set of priority levels and assigns a level
    to each process or thread.
  • The scheduling method can use priority levels in
    two ways
  • Always dispatch the highest priority ready thread
  • Assign larger time slices to high priority
    threads

38
Scheduling
  • Priority-Based Shortest time remaining
  • Chooses the next process to be dispatched based
    on the expected amount of CPU time needed to
    complete the process.

39
Scheduling
  • Real-Time Scheduling
  • Guarantees a minimum amount of CPU time to a
    thread if the thread makes an explicit request
    when it is created.
  • Used when a thread must have enough resources to
    complete its function within a specified time.

40
Technology Focus
  • Windows 2000 Scheduling

41
Technology Focus
42
Memory Allocation
  • Single-Tasking Memory Allocation
  • Multitasking Memory Allocation
  • Memory Fragmentation
  • Noncontiguous Memory Allocation
  • Virtual Memory Management
  • Memory Protection
  • Memory Management Hardware

43
Memory Allocation
  • Single-Tasking Memory Allocation Contiguous
    Memory Allocation
  • The bulk of the operating system occupies lower
    memory addresses.
  • The application program is loaded above the
    operating system.
  • The remaining space is available for user
    programs and data.

44
Memory Allocation
45
Memory Allocation
  • Single-Tasking Memory Allocation Noncontiguous
    Memory Allocation
  • To conserve physical memory, some operating
    system components are loaded into memory only
    when needed.
  • When loaded, they usually are placed in upper
    memory.

46
Memory Allocation
47
Memory Allocation
  • Multitasking Memory Allocation
  • The goals of multitasking memory allocation are
  • Allow as many active processes as possible.
  • Respond quickly to changing memory demands of
    processes.
  • Prevent unauthorized changes to a processs
    memory region(s).
  • Implement memory allocation and addressing as
    efficiently as possible.

48
Memory Allocation
49
Memory Allocation
50
Memory Allocation
51
Memory Allocation
  • Memory Fragmentation
  • As processes are created, executed, and
    terminated, memory allocation changes
    accordingly.
  • Memory partition allocation and deallocation
    leads to an increasing number of small free
    partitions separated by allocated partitions.

52
Memory Allocation
53
Memory Allocation
54
Memory Allocation
  • Noncontiguous Memory Allocation
  • Uses small fixed-size partitions, usually no
    larger than 64K.
  • A process can be loaded into more than one
    partition.

55
Memory Allocation
56
Memory Allocation
  • Virtual Memory Management
  • Divides a program into partitions called pages.
  • Memory is divided into pages called a page frame.
  • During program execution, one or more program
    pages are stored in a page frame, the remaining
    are stored on a secondary storage device.

57
Memory Allocation
58
Memory Allocation
  • Memory Protection
  • Refers to the protection of memory allocated to
    one program from unauthorized access by another
    program.
  • The operating system checks each write to a
    memory location to ensure that the address being
    written is allocated to the program performing
    the write operation.

59
Memory Allocation
  • Memory Management Hardware
  • Modern CPUs and computer systems incorporate
    advanced memory allocation and address resolution
    functions in hardware.

60
Technology Focus
61
Technology Focus
62
Outline
  • Functional overview of an operating system
  • Process management
  • Resource allocation
  • CPU allocation
  • Memory allocation
  • Interprocess communication

63
Interprocess Communication
  • Interprocess Signals
  • Interprocess Data Communication

64
Interprocess Communication
  • Interprocess Signals
  • A signal is a message used to synchronize the
    actions of two processes or threads.
  • Signals can be sent between threads of the same
    process, between independent processes, or
    between the operating system and a process or
    thread.

65
Interprocess Communication
66
Interprocess Communication
67
Interprocess Communication
68
Interprocess Communication
  • Interprocess Data Communication
  • Operating systems provide a mechanism called a
    pipe so there can be communication via shared
    memory between independent processes.

69
Interprocess Communication
70
Interprocess Communication
71
Summary
  • An operating system is the most complex component
    of system software.
  • The operating system allocates hardware resources
    to individual user processes on demand.
  • The operating system stores information about
    each process in a PCB.

72
Summary
  • Application software is simper to develop if
    programs are unaware of resource allocation
    functions.
  • An active thread is always in one of three states
    ready, running, or blocked.

73
Summary
  • Memory is divided into fixed-size partitions and
    processes are allocated one or more memory
    partitions to store instructions and data.
  • Modern operating systems implement a form of
    memory allocation and management called virtual
    memory management.

74
Summary
  • Processes and threads often need to synchronize
    their actions or transfer data among themselves
    using signals and pipes.
Write a Comment
User Comments (0)
About PowerShow.com
