Vikrant Khosla Sridhar Kameswara Nemani

1
Authoritative Sources in aHyperlinked
environmentJon M. Kleinberg

• Presented By-
• Vikrant KhoslaSridhar Kameswara Nemani

2
Outline

• Search on WWW Problem in general
• Overview of the authoritative approach proposed
  by this paper
• Constructing a focused Subgraph
• Computing Hubs and Authorities
• Similar page Queries
• Multiple Sets of Hubs and Authorities
• Diffusion and generalization
• Evaluation
• Conclusion

3
General Problem

• How to improve quality of search on WWW?
• Quality of search requires human evaluation due
  to the subjectivity inherent in notions such as
  relevance.
• The WWW is a hypertext corpus of enormous
  complexity and information.
• This paper aims to create link based model that
  consistently identifies relevant, authoritative
  WWW pages for broad search topics.

4
Understand Query Types

• There is more than one type of query and the
  handling of each may require different
  techniques.
• Type of queries
• Specific queries
• E.g. Does Netscape support the JDK 1.1
  code-signing API?
• Broad-topic queries
• E.g. Find information about the Java
  programming language.
• Similar page queries
• Example Find pages similar to honda.com

5
Difficulty in Handling query

• Specific queries
• Scarcity Problem- There are few pages containing
  those information and it is difficult to
  determine the identity of those pages.
• Broad topic queries
• Abundance problem- The number of pages that could
  reasonably be returned as relevant is far too
  large for a human user to digest.
• Select a small set of the most authoritative or
  definitive ones from a huge collection of pages
  that are most relevant

6
Authoritative Pages

• Given a particular page, how do we tell whether
  it is authoritative?
• Problem is related to limitations of text based
  analysis.
• Text based ranking function
• E.g. For the harvard, www.harvard.edu is proper
  authoritative page but there may be lots of other
  web pages containing harvard more often.
• Most popular Pages are not sufficiently self
  descriptive
• Usually the term search engine doesnt appear
  on search engine home web pages of Yahoo,
  AltaVista, Excite etc.
• Honda or Toyota home pages hardly contain the
  term automobile manufacturer.

7
Analysis of link structure

• Hyperlinks encode a latent human judgment which
  can be used to formulate a notion of authority.
• Creation of a link represents a concrete
  indication of the following type of judgment
• The creator of page p, by including a link to
  page q, has in some measure conferred authority
  on q.
• Opportunity for the user to find potential
  authorities purely through the pages that point
  to them.
• Potential Pitfalls of above concept
• Most links are created for navigational
  purposes.(eg main-menu, paid-adds)
• Difficult to balance between appropriate
  relevance and popularity(eg Yahoo)

8
Authorities and Hubs

• Authorities are pages that are recognized as
  providing significant, trustworthy, and useful
  information on a topic.
• Hubs are index pages that provide lots of useful
  links to relevant content pages (topic
  authorities).
• In-degree - Number of pointers to a page and is
  one simple measure of authority.
• Out-degree - Number of pointers from a page to
  other pages.

9
Can we operate over entire WWW ?

• Local approaches- deals with intranet and amount
  of data is much smaller as compared to WWW as a
  whole.
• Clustering approach- dissects a heterogeneous
  population into subpopulations that in some way
  more cohesive, but underlying problem of
  filtering vast number of pages is still the same.
• Authoritative approach- global nature
• Perform search on text based WWW search engine
• Distil broad topic from these pages via the
  discovery of authority.

10
Overview of search steps
11
Overview

• Search string
• Text Search Engine
• Authoritative Approach
• Constructing focused subgraph
• Computing Hub Authorities
• Better quality search result

12
Constructing Subgraph

• The collection V of hyperlinked pages can be
  viewed as a directed graph G(V,E)nodes
  correspond to pages, and a directed edge (p,q) e
  E indicates the presence of a link from p to q.
• Construct a focused subgraph (S ? ) of the WWW
  with the following properties-
• S ? is relatively small (so that computation is
  affordable)
• S ? is rich in relevant pages (so that its
  easier to find good authority)
• S ? contains most (or many) of the strongest
  authorities

13
How to find S?

• Set Q- set of all pages containing query string.
• Root set R ? - t highest ranked pages for the
  query ? got from a text-based search engine. It
  satisfy property 1 2.
• Problems with R ?
• R is a subset of collection Q and Q does not
  satisfy property 3.
• There are extremely few links between pages in R,
  rendering it essentially structureless.
• Strong authority for query is quite likely to be
  pointed to by at least one page in R ?.
• Construct Base set S ? by extend root set R ? by
  including -
• All pages linked to by pages in R
• All pages that link to a page in R
• at most d

14
Subgraph algorithm

15
Observation Heuristics

• Heuristic 1 Delete all intrinsic links keep
  all transverse links
• Intrinsic links
• if the link is between pages with the same
  domain name.
• Generally these are for navigation purposes.
• Less informative and often contain repetitive
  information.
• Transverse if it is between pages with different
  domain names.
• Heuristic 2 Delete pages having collusion or
  keep 4 to 8
• Large number of pages from a single domain all
  point to a single page p.
• Generally used for mass endorsement,
  advertisement etc.

16
Overview

• Search string
• Text Search Engine
• Authoritative Approach
• Constructing focused subgraph
• Computing Hub Authorities
• Better quality search result

17
Computing Hubs Authorities

• Simplest approach would be to order pages by
  in-degree
• Problem
• Nodes with highest in-degree in base set-
• might not necessarily be authorities lack any
  thematic unity.
• might simply be universally popular pages like
  yahoo, google, etc.

18
Computing Hubs Authorities

• Observation
• Good sources of content (authorities)
• Good sources of links (hubs)
• True authority pages are pointed by a number of
  good hubs.
• Mutually reinforcing relationship
• Hubs point to lots of authorities.
• Authorities are pointed to by lots of hubs
• We will use the iterative algorithm to break this
  circularity.
• Terms
• Good hub page that points to many good
  authorities.
• Good authority page pointed to by many good
  hubs.

19
Overview of Algorithm
20
Iterative Algorithm

• An iterative algorithm
• with each page p , we associate
• a non-negative authority weight xltpgt
• a non-negative hub weight yltpgt
• weights of each type are normalized so their
  squares sum to 1
• The pages with larger x and y values have
  better authorities and hubs respectively.

21
Iterative Algorithm

• If p points to many pages with large x-values,
  then it should receive a large y-value
• If p is pointed to by many pages with large
  y-values, then it should receive a large x-value
• Inlinks Operation I
• Outlinks Operation O

22
Algorithm
23
Matrices Basics

24
Observations

• As one applies Iterate with arbitrary large k ,
  the vectors
• Let G (V , E ), with V p1 , p2 ,, pn ,
  and let A denote the adjacency matrix of the
  graph G the (i , j )th entry of A is 1 if
  (pi , pj ) is an edge of G , and is 0 otherwise.
• x is the principal eigenvector of ATA , and
• y is the principal eigenvector of AAT
• The convergence of Iterate is quite rapid (k 20
  is sufficient)

25
Observations

• Any eigenvector algorithm can be used to compute
  the fixed points X and Y
• Emphasizes the underlying motivation of the
  approach by reinforcing I and O operations
• Do not require to iterate I and O to convergence
• Can start from initial vector X0 and Y0 and
  computer using a fixed bound of I and O
  operations

26
Example Mini Web

27
Example Mini Web (Cont..)

28
Basic Results

29
Observations

• Just pure analysis of link structure
• We ignored the text in searching for
  authoritative pages.
• i.e., text-based search is just an initial set
• Pages legitimately considered as authoritative in
  the context of www without access to large-
  scale index of the www
• i.e., global analysis of the full www link
  structure can be replaced by local method over
  small focused subgraph
• This approach can replace local approaches used
  in intranet

30
Similar page queries

• Example Find pages similar to honda.com
• Using link structure to infer a notion of
  similarity among pages
• We have found a page p that is of interest and
  its an authoritative page on a topic.
• Can this help in finding similar pages?
• What do users of the WWW consider to be related
  to p when they create pages and links ?

31
Similar page queries

• Previously our request to search engine was
• Find t pages containing the string ?.
• Now our request to search engine is
• Find t pages pointing to p
• Rp root set
• Sp base set
• Gp focused subgraph
• Strongest authorities in the local region of the
  link structure near p are the potential
  broad-topic summary of pages related to p.

32
Results- Similar page queries
33
Multiple Sets of Hubs Authorities

• Several densely linked collections of hubs and
  authorities within the same set.
• Example
• jaguar has several different meanings.
• randomized algorithms arises multiple
  technical communities.
• abortion - -involves groups that may not be
  linked to each other.
• Clustering in presence of Abundance problem is
  needed.

34
Multiple Sets of Hubs Authorities

• The non-principal Eigenvectors provide us a way
  to extract additional densely linked collections
  of hubs and authorities.
• Non-principal eigenvectors will have both
  positive and negative entries.
• Often, the highly positive entries will
  correspond to a cluster of pages and negative
  entries to a different cluster.
• Typically the two clusters will not be tightly
  intertwined. intertwined.

35
Jaguar Example

• Authority principal eigenvector is primarily
  about the Atari product.
• In the positive end of the 2nd non-principal
  eigenvector, the pages are primarily about the
  Jacksonville Jaguars.
• In the positive end of the 3rd non-principal
  eigenvector, the pages are primarily about the
  car.

36
Randomized Algorithms Example

• The first non-principal eigenvector, positive end
  returned home pages of theoretical computer
  scientists.
• First non-principal eigenvectors, negative end
  returns compendia of mathematical software.
• In the negative end of the fourth non-principal
  eigenvector, the pages are primarily about
  wavelets.

37
Diffusion and Generealization

• The query may not be sufficiently broad.
• In this case there will not be enough highly
  relevant pages in the base set to extract a
  sufficiently dense sub-graph of relevant hubs and
  authorities.
• When this occurs, the collection will often
  represent a broader topic, and the results will
  reflect a diffused version of the initial query.
• Example WWW conferences -gt WWW resource pages.
  resource pages.

38

• In studies conducted in 1998 over 26 queries and
  37 volunteers, Clever reported better authorities
  than Yahoo!, which in turn was better than Alta
  Vista.

39
Conclusion

• Need a way to distill a broad topic, for which
  there may be millions of relevant pages
• Provides a high quality results in context of
  what is available on the www globally
• Operate without maintaining an index of the www
  or its link structure
• It identifies the complex pattern of social
  organization on the www.

40
References

• http//crystal.uta.edu/gdas/Courses/websitepages/
  spring07DBIR.htm
• An Intro to Information Retrieval by Manning and
  Raghaban
• Information Retrieval Data Structures Algorithms
  - William B. Frakes
• Random Walks in Ranking Query Results in
  Semistructured Databases slides by Vagelis
  Hristidis

41

• Thank You
