The ABS Project

1
The ABS Project
2
The ABS project

• Objective Implement Automated Beam Steering and
  shaping Methods for accelerator operation
• OPEN project
• Annual project planning sets targets and
  milestones
• Tasks and targets discussed in topical Monthly
  meetings

3
PS ABS recipe

• Based on the nominal optics a linear correction
  Matrix A is created using the first order terms.
• The errors at the available Monitors are
  measured, each measurement is represented by an
  error vector b.
• The universal solver Micado is applied to return
  the correction vector x such as the norm of the
  residual vector
• r A x b
• is minimum after iteration over the number of
  correctors.

4
ABS in operation 1997
ABS for steering (transfer lines and
orbits) Data ready for Test program in
MCR database Linac-PSB yes yes PSB yes no PS
B-PS yes yes PS (Closed Orb.) yes yes PS
(Coherent Osc.) yes yes TT2 yes no
5
ABS 1997

• Software Analyses
• Database
• Application program
• Studies
• Matching
• Linac-PSB
• PSB-PS
• PSB four rings
• Bump42
• PSB Orbit

6
Why do we put such an effort on the database?

• Experience with the test programs has shown that
  the weakest point is the generation of Matrices !
• Generic ABS program is DATADRIVEN
• The data must be MAINTAINABLE

7
Database for ABS application program

• Database must handle
• PPM
• Multi function magnets
• Common elements for several PSB rings
• Database objectives
• Maintainable
• Avoid duplication of data
• Easy access to other databases
• PS control database
• Survey database
• Other CERN optics databases
• Evolution potential
• General machine documentation
• Interconnection with application programs
• Portable

8
What does ABS need from database

• Complete listing of all Magnetic elements and
  Monitors belonging to each existing type of
  machine operation
• Nominal optics
• Nominal position along the beam-line
• Magnetic length
• Edge-up and Edge down
• Calibration points

9
Data entry form
10
Data interrogation via ACCIS WEB browser

• Click and you see it!
• AND
• WEB pages are dynamically created from the
  database using the ORACLE WebServer

11
Generic application program

• Data-driven
• Portable
• Common look for the different machines and
  transfer lines, and for the different types of
  corrections for which it applies
• Interface to different instrumentation devices
• For calculation s, the program uses the
  Mathematica package BeamOptics.

12
ABS application program
13
BeamOptics 97
14
ABS 98
15
ABS in operation, block 1
16
ABS in operation, block 1

• Generic application program
• Milestone 10/4
• Block 1
• Database generated Matrix and application program
  for
• Steering LINAC-PSB
• Steering PSB-PS
• Closed Orbit PS
• Coherent oscillations PS
• Database description of optics for TT2
• Milestone 5/6

17
ABS in operation, block 2
18
ABS in operation, block 2

• Block 2
• Database generated Matrix and application program
  for
• Matching TT2
• Steering TT2
• Matching LINAC-PSB
• Matching PSB-PS (SEM-grid)
• Milestone 6/11

19
ABS for PS projects
20
ABS for PS projects

• ABS for AD
• Database generated matrix and application program
  for
• Steering TTL-AD
• Closed orbit
• Milestone 26/6
• ABS for East Hall
• Database generated matrix and application program
  for
• Steering
• Milestone 31/7

21
ABS studies

• ABS Matching using the Bovet-Jung method in the
  SPS (OTR screen)
• ABS steering TT2-TT10
• Development of Bovet-Jung method with SEM-grid in
  PS (in collaboration with BD group)
• Development of Quadrupolar pick-up in PS (in
  collaboration with BD group)
• Study of TT2-TT10 line (collaboration)
• New version of BeamOptics
• New matched PSB recombination scheme
• Study of dispersion matching PSB-PS

22
ABS studies
23
ABS Mini WorkshopCERN, December 98

• Objectives
• Find a common platform for ABS between the PS and
  SL division
• Create the embryo for an international ABS
  community

24
Database software objectives
25
Database software objectives

• ORACLE software development of
• Template elements
• re-occurring elements
• Transfer lines
• problems found during Test in November
• USER MANUAL
• Milestone 10/4
• Generic positioning of elements
• Topology using survey points

26
ABS Human resources 1998

• ABS in operation
• Michel Arruat (CO)
• Tanguy Balavoine (CO)
• Marine Gourber-Pace
• Andreas Jansson
• Ole Jensen
• Mats Lindroos
• Olav Tungesvik
• Michel Martini (CA)
• Josi Schinzel (CO)
• Franck Di Maio (CO)

• ABS in PS projects
• Tommy Eriksson
• Ornella Fernando (CA)
• Masashi Shirakata (HP)
• ABS studies
• Bruno Autin (DI)
• Christian Carli (CA)
• Massimo Giovannozzi (CA)
• Gianluigi Arduini, SL
• Jan Uythoven, SL
• Roland Jung, SL
• Jean Boillot

27
Requests for 1998

• New hardware needs
• In progress
• Qudarupolar Pick-up
• Turn-by-turn SEM-grid
• Digitalization of scintillator screens
• Request
• Pick-ups for ISOLDE line

• Other request
• Mini workshop in ABS at CERN
• Site license for Geometrica
• Portable PC
