Welcome to the Strasbourg JDF Tutorial

1
Welcome to the Strasbourg JDF Tutorial
2
CIP4 Tutorial and Developer Sessions

• Sunday November 6 2005
• Sofitel Strasbourg
• 10.00-12.00 Tutorial
• 13.00-18.00 Developer Sessions

3
Tutorial Session Speakers

• Henny van Esch - Optichrome
• Rainer Prosi - Heidelberg
• Markus Schluep Müller-Martini

4
Outline

• Architectural Overview of JDF
• Experience with JDF

5
JDF on One Slide

• JDF is a Graphic Arts Job Ticket Data
  Interchange Format Specification - JDF is not an
  Application or System
• JDF is encoded in XML
• Content is referenced, not embedded
• JDF is extensible
• JDF is based on semantic structures originally
  defined by
• Adobe PJTF
• CIP3 PPF
• JDF Job Definition JMF Messaging JDF
  Capabilities define the JDF Framework

6
JDF on Another Slide- Goals and Requirements -

• Why?
• Automation increases Efficiency
• Information allows for informed decisions
• We have a digital content workflow with a paper
  based management workflow that is not useful!
• What?
• Describe a Job in the graphic arts from the view
  point of
• Technical Applications
• Management Information Systems
• Customers
• Collect data that is relevant to a Job from
  origination to delivery
• How?
• See next Slides

7
CIP4 Reference Model
8
JDF Encoding

• XML Encoding
• External references via URI/URL
• XML Schema for Data Type Definitions
• Extensibility using XML name spaces

9
The Building Blocks of the JDF Framework

• JDF Node
• Description of a Process, Process Group or
  Product
• JDF Resource
• Description of a parameter set or physical entity
• JDF ResourceLink
• Link between JDF Nodes (processes) and Resources
• JDF Capabilities Descriptions
• Limitation of a JDF interface
• JMF Messages
• Real time data interchange format

10
The JDF Node

• Description of a generic Process
• The Verb in JDF
• Do something at a given time
• Structured container for Scheduling and Auditing
• One JDF node type for both Products and Processes

• Less Precise Product Intentat the Job Root Node
• Abstract ProcessGroup Nodes or Workflow Group
  nodes in between
• Detailed individual or combined Processes in the
  Leaf Nodes

11
Product Intent vs. Process Modeling

• Goal of Product Intent Description
• Customers view of the thing they want to
  manufacture
• Contract Negotiation
• Process Independent

12
Product Intent vs. Process Modeling

• Goal of Process Modeling
• Interface between MIS and Production
• Process interdependencies
• Manufacturing Instruction Details

13
Gray Boxes

• Incomplete Model of a Process
• The MIS View of the process
• Its only important if it affects the cost!
• Thus, parameters not affecting costs are not
  important
• Exact Process execution is potentially undefined
• Ordering of steps is not necessarily predefined
• Detailed Work Steps may be left out
• E.g. MIS knows RIPping, but not Trapping or
  ColorSpaceConversion

14
Audit Objects

• Logging of Job Execution
• Actual times
• Start time
• End time
• Phases
• Logging of Late Changes
• Resources (used 85g Paper instead of 80g)
• Consumables
• Status Summary
• Event Log

15
Job / Customer Information

• CustomerInfo
• Map Subcontracting via Localized Customer
  Information in any JDF Node
• Customer ID
• Addresses (Delivery, Invoice, )
• NodeInfo
• Scheduling
• Deadlines
• Processing Time Estimation

16
JDF Node simple Example

• ltJDF IDN1" Type"Product" JobID"HDM1"
  JobPartIDp1 StatusWaiting" Version1.3"gt
• ltResourcePoolgt
• ltNodeInfo Class"Parameter"
  StatusAvailable ID"Link0001" /gt
• ltSomeInputResource ID"Link0002"
  Class"Parameter" StatusAvailable"/gt
• ltComponent ID"Link0003" Class"Quantity"
  StatusUnavailable" DescriptiveName"SomeOutputRe
  source"/gt
• lt/ResourcePoolgt
• ltResourceLinkPoolgt
• ltNodeInfoLink rRef"Link0001" UsageInput"/gt
• ltSomeInputResourceLink rRef"Link0002"
  UsageInput"/gt
• ltComponentLink rRef"Link0003"
  UsageOutput"/gt
• lt/ResourceLinkPoolgt
• ltAuditPool/gt
• lt/JDFgt

17
The JDF Node Node Type

• Individual process types and their respective
  resources are defined e.g.
• Interpreting
• Trapping
• ConventionalPrinting
• DigitalPrinting
• Cutting
• Folding
• Verification
• Delivery

18
Combination of JDF Nodes

• Dont recreate a new Process Type for
  Permutations of known Processes!
• Create combinations of multiple defined processes
  into one process, e.g.
• online finishing printing folding cutting
• in-RIP trapping trapping RIPping
• Three types of Combination Nodes
• Combined Node All internal interfaces are hidden
• Smart multi-function device
• ProcessGroup Internal nodes are accessible
• Without Sub elements (Gray Box)
• MIS view
• With Sub elements
• Workflow group in a department
• Subcontract

19
Combined vs. ProcessGroup

• Combined Node

Combined Node
Res
Res
Res1
Res2

• ProcessGroup

ProcessGroup
Res
Res
Res1
Res2
20
JDF Resources

• Specification of Parameters of
• Product Intent description
• Logical Entities, e.g RIP Parameters, Imposition
  setup
• Physical Entities, e.g. Media, Devices, Plates
• Based on Adobe PJTF and CIP3 PPF
• Intent Resources for product intent nodes
• Prepress Adobe PJTF
• Press, Finishing CIP3 PPF
• Internal to JDF or External Links to well-defined
  Formats
• Thumbnails, Preview Files, ICC Profiles, Content
  Data

21
JDF RunList Resource Simple Example

• ltRunList ID"Link0003" Class"Parameter"
  StatusAvailable PartIDKeysRungt
• ltRunList Run1 Pages"010"gt
• ltLayoutElement ElementType"document"gt
• ltFileSpec URLFile///File1.pdf
  MimeType"application/PDF"/gt
• lt/LayoutElementgt
• lt/RunListgt
• ltRunList Run2 Pages12-1"gt
• ltLayoutElement ElementType"document"gt
• ltFileSpec URLFile///File2.pdf
  MimeType"application/PDF"/gt
• lt/LayoutElementgt
• lt/RunListgt
• lt/RunListgt

22
JDF Resources - Intent Resources

• Parameters are not attributes but rather
  structured Span Elements with the following
  attributes
• Range list of allowed values
• Names
• Numbers
• Ranges of Numbers / Strings
• OfferRange list of proposed values
• Preferred one preferred value
• Actual The selected value from Range or
  Preferred

23
JDF Resources - Details

• Special handling of multiple Parts, e.g.
• Sheets
• Separations
• Amounts
• Tiles
• Versions
• Redo one part of a large resource
• Only the yellow plate of the front surface of
  sheet 17
• Parallel processing of partitioned resources
• Selection of devices / operators

24
JDF Resources - Partitioning

• One Resource may specify multiple entities
• Multiple Partition type levels, e.g. Sheet,
  Side, Separation
• Inheritance model
• specify common attributes once
• Overwrite individual attributes / elements
• Select individual or multiple parts with a
  ResourceLink

25
Partitioning and Nodes
Partitioned Resources with matching partition
keys are connected.
26
Partitioned Ink Resource Example

• ltInk IDInkID" BrandProcessBrand"
  Class"Consumable" StatusAvailable"
  MediaType"Coated" PartIDKeys"Separation"gt
• ltInk Separation"Cyan"gt
• ltColor CMYK"1 0 0 0"/gt
• lt/Inkgt
• ltInk Separation"Magenta"gt
• ltColor CMYK"0 1 0 0"/gt
• lt/Inkgt
• ltInk Separation"Yellow"gt
• ltColor CMYK"0 0 1 0"/gt
• lt/Inkgt
• ltInk Separation"Black"gt
• ltColor CMYK"0 0 0 1"/gt
• lt/Inkgt
• ltInk BrandSpotBrand" Separation"Heidelberg
  Spot Blau"gt
• ltColor CMYK"0.7 0.7 0.3 0.7"
  ColorantUsage"spot"/gt
• lt/Inkgt
• lt/Inkgt

27
ResourceLink

• Bind a Resource to a Node
• Define Resource Usage (input or output)
• Link to a Subset / Part of a Resource
• E.g. Cyan Plate of the Front of Sheet 1
• Define the Amount
• Allow reuse of Resources by multiple processes
• One resource may be linkedby multiple
  ResourceLinks
• Defines a process network

28
ResourceRef

• Used to reference a Resource from within another
  JDF element.
• Resource
• CustomeInfo
• May contain Part elements to select individual
  partitions
• Equivalent to an inline occurence of the
  referenced resource
• Name mangling ResourceRef

29
JDF RunList Resource Simple Example with
ResourceRef

• ltRunList ID"Link0003" Class"Parameter"
  StatusAvailable PartIDKeysRungt
• ltRunList Run1 Pages"010"gt
• ltLayoutElementRef rRefL1gt
• lt/RunListgt
• ltRunList Run2 Pages12-1"gt
• ltLayoutElement ElementType"document"gt
• ltFileSpec URLFile///File2.pdf
  MimeType"application/PDF"/gt
• lt/LayoutElementgt
• lt/RunListgt
• lt/RunListgt
• ltLayoutElement IDL1 ElementType"document
  Class"Parameter" StatusAvailablegt
• ltFileSpec URLFile///File1.pdf
  MimeType"application/PDF"/gt
• lt/LayoutElementgt

30
ConventionalPrinting JDF Node Example
ConventionalPrinting
ExposedMedia (Plate)

• NodeInfo
• Planned StartTime
• Planned EndTime

Media
AuditPool Actual Resource Usage Actual Time
Summary
Ink
InkZoneProfile
Resource Links
Component (including amount)
Parameters Layout (Control Marks)
31
The JDF Node Execution Requirements

• A Node is executable when all required input
  resources are available
• Serial Processing -- Standard
• Parallel Processing -- Partial Resources
• Overlapping Processing -- Pipes
• Iterative Processing -- Draft Resources
• Node dependencies allow process configuration
• A proof node can create an Approval which is
  needed for the press node to operate

32
Node Executability
Resource ResourceLink JDF Node
Not Available
Not Executable
Available
Resource Links
Available
33
Node Executability
Resource ResourceLink JDF Node
Available
Executable
Available
Resource Links
Available
34
Node ExecutabilityAnd Networks
Waiting
Available
Not Available
Links
Not Executable
Available
Links
Available
Available
Not Available
35
Node ExecutabilityAnd Networks
Running
Available
Not Available
Links
Not Executable
Links
Available
Available
Available
Available
36
Node ExecutabilityAnd Networks
Completed
Available
Available
Links
Executable
Available
Links
Available
Available
Available
37
Job Description Models supported by JDF I

• Product Definition
• No Process
• Abstract, customer view
• Segmentation by Product Components
• Serial Processing

RIP
Print
Bind
38
Job Description Models supported by JDF II

• Parallel Processing
• Overlapping Processing

Print
Bind
RIP
Print
39
Job Description Models supported by JDF III

• Iterative Processing
• Informal Iterative Processing using Draft
  Resources
• Formal Iterative Processing using JMF Messages

Edit
Touchup
Layout
40
JDF Tree / Network Structure
41
JDF - Spawning and Merging

• Spawn individual nodes of the JDF Tree for
  independent processing
• Parallel Processing
• Subcontracting
• Support for Partitioning e.g. only sheet 1
• Merge back after processing
• Retain information source Context
• Audits
• Modified Resources

42
Spawning Merging
Master JDF
Executable Sub-JDF 1
Executable Sub-JDF 2
Step 1 - Prior to Spawning
43
Spawning Merging
Master JDF
Executable Sub-JDF 1
Locked Sub-JDF 2
Step 2 - Spawned, Prior to Execution
Spawned Executable Sub-JDF
44
Spawning Merging
Master JDF
Executable Sub-JDF 1
Locked Sub-JDF 2
Step 3 - Spawned, After independent Execution Pr
ior to merging
Spawned completed Sub-JDF
45
Spawning Merging
Master JDF
Executable Sub-JDF 1
Merged Sub-JDF 2
Step 4 - After Execution After Merging
46
JMF Messaging

• Real-time data interchange format
• Small XML structures
• JDF is referenced via URL, not bound into message
• Idea is to minimize network traffic and delay
  transmission of data until it is actually needed

47
JMF Messaging

• Used for
• Plug Play bootstrapping
• Snapshots of Job / Device status
• Dynamic job update
• Job submission and Queue/QueueEntry handling
• Capabilities discovery and interchange

48
JMF Message Families

• JMF messages fall into five categories
• Command
• Receiver is instructed to take an action, or to
  modify the state of something
• Query
• Receiver is instructed to return information
  about something. No action is taken, no states
  are changed
• Response
• Used to immediately return result of command or
  query
• Synchronous messaging command/query and
  response are exchanged on same open connection

49
JMF Message Families

• JMF message categories (contd)
• Acknowledge
• Used to return the result of a command after some
  time has passed
• Asynchronous messaging empty response returned
  immediately on same connection as command with
  indication that Acknowledgement will be sent
  later
• Signal
• Used to send notifications of events or change in
  status
• Typically result of a query with a subscription
  embedded in it
• Subscription sets up persistent channel
• Registration
• Request for commands
• Used to set up triangular workflows
• E.g. MIS tells prepress to send a Command to Press

50
Example SubmitQueueEntry message

• ltJMF DeviceID"SP013" SenderID"MIS1TimeStamp"2
  005-11-05T123248-0600"gt
• ltCommand ID"m3829" Type"SubmitQueueEntry"gt
• ltQueueSubmissionParams URL"http//jobserv
  er/getJob?job10047"
• ReturnJMF"http//jobserver/jmfservice"
• Priority"50"/gt
• lt/Commandgt
• lt/JMFgt

51
JMF Message Types

• Examples of JMF message that fall within the six
  categories
• Command
• SubmitQueueEntry, AbortQueueEntry,
  ReturnQueueEntry, HoldQueue, ResumeQueue
• Query
• KnownControllers, KnownDevices, Status
• Response
• Various related to various commands/queries
• Acknowledgement
• Various related to various commands/queries
• Signal
• Status, Resource, Occupation
• Registration
• Resource

52
CIP4 Open Source Development Tools

• XML Schema
• C API
• Java API
• JDF Editor
• Visualise JDF JMF
• Send Messages
• Elk Project
• Reference Device

53
History of JDF

• 1999 Adobe, Agfa, MAN and Heidelberg form the
  GAT initiative with the goal of defining a job
  ticket for the Graphic Arts that also integrates
  MIS.
• 2000 The CIP3 Consortium takes ownership of the
  standard.
• 2001 JDF 1.0 is released.
• 2002 JDF 1.1 is released.
• Ambiguities/Bugs found in implementation were
  removed
• Additional Processes were added
• Consistency between diverse areas was enhanced
• 2004 JDF 1.2 is released
• More additional processes
• Even more mature and consistent
• 2005 First set of ICS documents are published
• JDF 1.3 is released

54
Experience with JDF - Advantages

• Single grammar for specifying job data in the
  graphic arts industry
• Integration of Production, Customer and MIS
• Multiple views for Production, Customer and MIS
• Definition of production networks
• Combined Processes
• Defined communication protocol, not only data
  structures
• Extensible Model
• Interaction with other Standards in GA

55
Experience with JDF - Challenges / Obstacles

• Number of processes in the graphic arts
• Creative
• Prepress
• Press
• Finishing
• Fulfillment
• Complexity of the standard
• Size of the Specification
• Moving from the Abstract Idea to a Concrete
  Implementation
• Flexibility of the Specification
• Unclear Role of Production networks in
  Interfacing with Devices
• private extensions
• Definition of abstract coordinate systems
• Legacy System Longevity

56
Why ICS ?
JDF A ICS JDF B
Product A
Product B
InteroperabilityConformanceSpecifications
57
Interoperability Conformance Specifications

• Define a set of Interoperability Conformance
  Specifications ICS
• The term JDF Compliant does not immediately
  imply that two arbitrary applications will
  communicate.
• Sending RIP instructions to a Folding Machine is
  not useful
• Two applications that comply with a given ICS
  will communicate in a meaningful way.
• Product Certification will be based on ICS
  Compliance
• Avoid multiple, incompatible JDF Dialects

58
ICS Document Structure
59
JDF Tutorial
Thank you very much for your attention!
