Analysis Patterns

1
Analysis Patterns

• Data Modeling Patterns, David Hay
• Analysis Patterns, Martin Fowler

2
Analysis Patterns

• Organizational structure Hay, Fowler
• Accountability Fowler
• Quantities Hay, Fowler
• Contracts Hay, Fowler
• Accounting Hay, Fowler
• Products and Inventories Hay
• Material Requirements Planning Hay

3
Transactions
Transactions can effect many accounts.
Entry amount
Account
Transaction date
4
Party

• Many roles that are usually played by people are
  sometimes played by organizational units, too.

Party Address
Person
Organization
5
Organizational Hierarchies

• Organizations usually have a hierarchical
  structure.

Party Address
parent
Organization
Person
subsidiary
Division
Region
Sales Office
Operating Unit
6
Organizational Structure

• Problem An organization can be in several
  hierarchies, and the structure can change over
  time.

OrganizationStructureType
OrganizationStructure time interval
parent
Organization
subsidiary
Division
Region
Sales Office
Operating Unit
7
Quantity
Quantity amount Number units Unit , -, , /
8
Conversion Ratio
Conversion Ratio ratio Number
Unit
9
Measurement
weight
Quantity
Person
height
10
Measurement
Phenomenon Type
Person
Measurement
Quantity
11
Observation
Phenomenon Type
Person
Observation
Measurement
CategoryObs.
Quantity
Category
12
Action
Action time
Party
Location
13
Proposed and Implemented Actions
Action
Proposed Action
Implemented Action
14
Completed, Abandoned, Suspended Actions
Status
Action
Completed
Abandoned
Suspended
Time Period
15
Plan
dependent
Proposed Action
consequences
Plan
16
Resource Allocation
Action
Resource Type
Proposed Action
Implemented Action
Resource Allocation quantity
books
uses
17
Summary

• Analysis is modeling the problem.
• Analysis patterns are as important as design
  patterns.
