Calibration

1
Calibration

2
Camera Calibration

• Geometric
• Intrinsics Focal length, principal point,
  distortion
• Extrinsics Position, orientation
• Radiometric
• Mapping between pixel value and scene radiance
• Can be nonlinear at a pixel (gamma, etc.)
• Can vary between pixels (vignetting, cos4, etc.)
• Dynamic range (calibrate shutter speed, etc.)

3
Geometric Calibration Issues

• Camera Model
• Orthogonal axes?
• Square pixels?
• Distortion?
• Calibration Target
• Known 3D points, noncoplanar
• Known 3D points, coplanar
• Unknown 3D points (structure from motion)
• Other features (e.g., known straight lines)

4
Geometric Calibration Issues

• Optimization method
• Depends on camera model, available data
• Linear vs. nonlinear model
• Closed form vs. iterative
• Intrinsics only vs. extrinsics only vs. both
• Need initial guess?

5
Caveat - 2D Coordinate Systems

• y axis up vs. y axis down
• Origin at center vs. corner
• Will often write (u, v) for image coordinates

u
v
v
u
v
u
6
Camera Calibration Example 1

• Given
• 3D ? 2D correspondences
• General perspective camera model (no distortion)
• Dont care about z after transformation
• Homogeneous scale ambiguity ? 11 free parameters

7
Camera Calibration Example 1

• Write equations

8
Camera Calibration Example 1

• Linear equation
• Overconstrained (more equations than unknowns)
• Underconstrained (rank deficient matrix any
  multiple of a solution, including 0, is also a
  solution)

9
Camera Calibration Example 1

• Standard linear least squares methods forAx0
  will give the solution x0
• Instead, look for a solution with x 1
• That is, minimize Ax2 subject to x21

10
Camera Calibration Example 1

• Minimize Ax2 subject to x21
• Ax2 (Ax)T(Ax) (xTAT)(Ax) xT(ATA)x
• Expand x in terms of eigenvectors of ATA x
  m1e1 m2e2 xT(ATA)x l1m12l2m22 x2
  m12m22

11
Camera Calibration Example 1

• To minimize l1m12l2m22subject to
  m12m22 1set mmin 1 and all other mi0
• Thus, least squares solution is eigenvector
  corresponding to minimum (non-zero) eigenvalue of
  ATA

12
Camera Calibration Example 2

• Incorporating additional constraints intocamera
  model
• No shear (u, v axes orthogonal)
• Square pixels
• etc.
• Doing minimization in image space
• All of these impose nonlinear constraints
  oncamera parameters

13
Camera Calibration Example 2

• Option 1 nonlinear least squares
• Usually gradient descent techniques
• e.g. Levenberg-Marquardt
• Option 2 solve for general perspective model,
  find closest solution that satisfies constraints
• Use closed-form solution as initial guess
  foriterative minimization

14
Radial Distortion

• Radial distortion can not be representedby
  matrix
• (cu, cv) is image center,uimg uimg cu, vimg
  vimg cv,k is first-order radial distortion
  coefficient

15
Camera Calibration Example 3

• Incorporating radial distortion
• Option 1
• Find distortion first (e.g., straight lines
  incalibration target)
• Warp image to eliminate distortion
• Run (simpler) perspective calibration
• Option 2 nonlinear least squares

16
Calibration Targets

• Full 3D (nonplanar)
• Can calibrate with one image
• Difficult to construct
• 2D (planar)
• Can be made more accuracte
• Need multiple views
• Better constrained than full SFM problem

17
Calibration Targets

• Identification of features
• Manual
• Regular array, manually seeded
• Regular array, automatically seeded
• Color coding, patterns, etc.
• Subpixel estimation of locations
• Circle centers
• Checkerboard corners

18
Calibration Target w. Circles
19
3D Target w. Circles
20
Planar Checkerboard Target


Bouguet
21
Coded Circles
Marschner et al.
22
Concentric Coded Circles
Gortler et al.
23
Color Coded Circles
Culbertson
24
Calibrating Projector

• Calibrate camera
• Project pattern onto a known object(usually
  plane)
• Can use time-coded structured light
• Form (uproj, vproj, x, y, z) tuples
• Use regular camera calibration code
• Typically lots of keystoning relative to cameras

25
Multi-Camera Geometry

• Epipolar geometry relationship between observed
  positions of points in multiple cameras
• Assume
• 2 cameras
• Known intrinsics and extrinsics

26
Epipolar Geometry
P
p1
p2
C1
C2
27
Epipolar Geometry
P
l2
p1
p2
C1
C2
28
Epipolar Geometry
P
Epipolar line
l2
p1
p2
C1
C2
Epipoles
29
Epipolar Geometry

• Goal derive equation for l2
• Observation P, C1, C2 determine a plane

P
l2
p1
p2
C1
C2
30
Epipolar Geometry

• Work in coordinate frame of C1
• Normal of plane is T ? Rp2, where T is relative
  translation, R is relative rotation

P
l2
p1
p2
C1
C2
31
Epipolar Geometry

• p1 is perpendicular to this normal p1 ?
  (T ? Rp2) 0

P
l2
p1
p2
C1
C2
32
Epipolar Geometry

• Write cross product as matrix multiplication

P
l2
p1
p2
C1
C2
33
Epipolar Geometry

• p1 ? T R p2 0 ? p1T E p2 0
• E is the essential matrix

P
l2
p1
p2
C1
C2
34
Essential Matrix

• E depends only on camera geometry
• Given E, can derive equation for line l2

P
l2
p1
p2
C1
C2
35
Fundamental Matrix

• Can define fundamental matrix F analogously,
  operating on pixel coordinates instead of camera
  coordinates u1T F u2 0
• Advantage can sometimes estimate F without
  knowing camera calibration
