Title: Class 5 Applying Loads to Buildings


1
Class 5Applying Loads to Buildings Wind and
Flood
2
Wind loads
  • References are ASCE 7 Chapter 6 and the Guide
    to the Use of the Wind Load Provisions of ASCE 7
  • Design process is to determine
  • Basic wind speed from Figure 6-1
  • Directionality factor (Kd)
  • Importance factor (I)
  • Exposure category and velocity pressure
    coefficient (Kz)
  • Topographic factor (Kzt)
  • Gust effect factor (G)
  • Enclosure classification
  • Internal pressure coefficients (GCpi)
  • External pressure coefficients (Cp)

3
Wind pressures and loads
  • Then calculate wind pressure q
  • Use q to find wind load p or F
  • Basic wind pressure equation is
  • q 0.00256 Kz Kzt Kd V2 I (psf)

4
Determine loads for
  • MWFRS examples
  • CC - examples

5
MWFRS
  • ..\..\..\presentations\Design of Buildings in
    Coastal Regions Workshop\Reference material\FEMA
    499 Home Builder's Guide Technical Fact
    Sheets\hgcc_fact10 Load Paths.pdf

6
CC
7
ASCE Design Methods
  • Simplified procedure
  • Analytical procedure the design process
    mentioned above follows this approach
  • Were going to work a problem with same givens
    through both approaches and see how the results
    compare

8
Wind Speed Map Fig. 6-1
9
Delaware wind speeds
110
120
10
Wind speed measuring standards
  • 3-sec peak gust
  • 33 ft (10m) above the ground
  • Exposure C
  • Hurricane coastline event frequency is between 50
    100 years MRI

11
Directionality Factor Kd
  • For most buildings Kd 0.85
  • Accounts for reduced probability that max winds
    will come from any particular direction
  • And reduced probability that max pressure
    coefficient will occur for any given wind
    direction

12
Importance Factor
  • I 1.0 for Category II buildings which include
    residential and most commercial
  • I 1.15 for both Category III and IV buildings
    which are high occupancy or critical use

13
Exposure Category
  • B prevails upwind 2600 ft or 20 x bldg height
  • Described as urban and suburban areas, wooded or
    closely spaced obstructions
  • Exposures developed from surface roughness
  • ASCE Commentary discusses

14
Exposure B (from ASCE 7)
15
Exposure D
  • Prevails upwind 5000 ft or 20 x bldg height
  • Described as flat, unobstructed areas and water
    surfaces outside hurricane prone regions
  • Includes mud and salt flats, unbroken ice

16
Exposure D
17
Exposure C
  • Applies to all cases that are not Exposure B or D
  • Includes open terrain with scattered obstructions
    generally less than 30 ft tall
  • Airports are good examples

18
Exposure C
19
Caution!!
  • Wind speed maps are based on an Exposure C
  • All the tables and simplified wind design
    pressures are all based on Exposure B
  • Requires conversion to get pressures at Exposure
    C,
  • However, Exposure B is the most prevalent terrain
    condition

20
Velocity Pressure Coefficient Kz
  • Values provided in Table 6-3
  • Values can be interpolated between heights above
    ground
  • Note that Kz 1.0 for Exposure C at 33 ft which
    is the base for the wind speeds
  • Note there is no difference in coefficient
    between 0 and 15 ft. and in Exposure B no
    difference for 0 to 30 ft.

21
Topographic factor Kzt
  • There is a wind speed-up effect at isolated
    hills, ridges and escarpments in any exposure
    category
  • Must account for speed-up under 3 conditions (see
    Section 6.5.7.1)
  • If site conditions do not meet ALL the conditions
    in Section 6.5.7.1, then Kzt 1

22
Effects from topography
23
Gust Effect Factor G
  • For rigid structures G 0.85 or calculated by
    Formula 6-4
  • By definition, rigid structure is one whose
    fundamental frequency n1 is 1 hz
  • n1 1/Ta (the building period)
  • From earthquake design Ta Cthx where h is
    height of building, Ct and x are coefficients
    based on shear wall strategies

24
Determining height for a rigid building
  • For most structural systems, Ct 0.02 and x
    .75, so if min. n1 1.0 then Ta must 1.0
  • Solving for h in Ta Cthx or 1 0.02h.75
  • h (1/0.02)1.333
  • h 183.96 184 ft
  • Use G 0.85 for any building lt 150 ft unless
    structural system is extremely flexible

25
Enclosure classification
  • Open
  • Partially enclosed
  • Enclosed
  • Definitions for these classifications are given
    in Sec 6.2 definitions

26
Open
  • Building that has EACH wall at least 80 open
  • Examples of openings doors, operable windows,
    air intake exhausts, gaps around doors,
    deliberate gaps in cladding, louvers

27
Partially enclosed
  • Building that complies with both conditions
  • Total area of openings in wall that receives
    positive external pressure exceeds sum of areas
    of openings in balance of building envelope by
    more than 10
  • Total area of openings in wall exceeds 4 ft2 or
    1 of area of wall whichever is smaller and of
    openings in balance of building envelope does not
    exceed 20

28
Enclosed
  • Building that does not comply with either open or
    partially enclosed definitions
  • Importance of enclosed building
  • In order to qualify, openings must be
    impact-resistant
  • Required in wind-borne debris regions which are
    within hurricane prone areas where wind speed is
    110 mph or greater and within 1 mile of coast or
    where wind speed is 120 mph or greater

29
MWFRS Pressures
  • GCp external pressure coefficients found in
    Figures in Chapter 6 (depends on the method you
    select to determine loads)
  • GCpi internal pressure coefficient found in
    Figure 6-5 and is a function of enclosed condition

30
CC Pressures
  • GCp external pressure coefficients based on
    effective wind area and are function of building
    geometry
  • Use graphs to determine coefficients such as
    Figures 6-11A-D

31
Important design concepts
  • Wind loads are normal to the surface yet in order
    to perform load combinations for vertical and
    horizontal loads, the wind components must be
    determined
  • Wind loads acting toward the surface (windward)
    are positive and loads acting away from the
    surface (leeward) are negative
  • In design, we are looking for the very largest
    loads irrespective of windward/leeward acting

32
Design example
  • Work one example using 2 methods and compare
    results
  • Simplified procedure
  • Low-rise building provisions

33
(No Transcript)
34
Flood loads
  • References are ASCE 7 Chapter 5, ASCE 24 and
    USACE Shore Protection Manual
  • Two primary flooding sources riverine (mapped
    by FEMA as A Zones) and coastal (mapped as V
    Zones)
  • Regulatory elevation is the 1 or 100-year flood

35
Flood Design Method
  • Determine flood source riverine or coastal
  • Determine depth of flooding
  • Determine flood parameters important to design
    could include
  • Depth (hydrostatic and buoyancy)
  • Velocity
  • Waves
  • Erosion
  • Scour
  • Debris

36
Flood Depth
  • Source of information is FEMA Flood Map
    provides flood elevations
  • Need ground elevation USGS Quad map or survey
    information
  • MUST add some factor of safety called freeboard
  • Flood depths too difficult to precisely quantify

37
Hydrostatic forces
38
Hydrostatic force
39
Buoyancy forces
40
Buoyancy failure
41
Velocity
  • Do not have good information about velocity of
    water moving during a flood except FIS
  • Best guidance is

42
Hydrodynamic forces
  • Force of moving water

43
Wave height determination
44
Breaking wave forces
  • Against slender element like pile

45
Breaking wave forces on wall
46
Effect of scour and erosion
  • Both scour and erosion lower the ground elevation
    increasing water depth
  • Both reduce soil support for foundations
  • Pile embedment
  • Soil for shallow footings
  • Consider effects of both and for multiple storms

47
Debris
  • Correction ?g should be ?t impact duration

48
Homework 4
