Automatic derivation of Semantic Properties in
.NET

• Analyze the behaviour of an assembly using Phoenix

2
Problems/issues

• Weaving is currently only possible on the
  syntactic level
• Set also matches Setup
• Not certain of actual implementation
• Possible conflicts while using aspects
• SECRET uses custom attributes
• There is no knowledge about
• the method body itself

3
Goals

• Semantic weaving points
• Fine grained weaving
• Inside the method body
• Based on conditions, loops, exception handling,
  method calling, branching
• Detection of possible conflicts
• Read/write actions on same fields
• Resource conflicts (files, ports etc)
• Providing information for SECRET

4
How to

• Must support multiple .NET languages
• Parser for each language is inefficient
• Use of the Common Intermediate Language
• Extract semantics from an assembly using a tool
  (IL reader)
• Store the semantics in a model
• Allow tools to query this model using API

5
Read IL using Phoenix

• Microsoft research project named Phoenix
• An unified framework for building compilers and
  software development tools.
• Used internal by MS for compiling Windows,
  PowerPoint, games and for building test tools.
• Contains readers, analysis tools (control/data
  flow etc), inserters and writers.
• Targets different architectures and languages

6
Phoenix

• Multiple phases executed in sequential order
• Add own phases between others
• A common Intermediate Representation (IR)
• Accessible in each phase
• Represents a function at multiple levels of
  abstraction
• Flows, AST on top of IR
• IL instructions are converted to IR objects

7
Phoenix Architecture
High Level Analysis and Optimization
Machine Independent Optimization
Front End
Reader
Code Generation
Phoenix API
Machine Dependent Optimization
Code Emission
8
Instructions in Phoenix

• Pseudo instructions
• Not directly mapped to machine code
• E.g. labels, data
• Real instructions
• ValueInstr assignment, add, mul, neg
• CallInstr call, jmp
• CmpInstr gt, lt, eq, neq
• BranchInstr br, brfalse, bgt, bne
• SwitchInstr switch
• OutlineInstr inline assembly code

9
New model needed

• Why another model?
• Phoenix model very general and large
• Structure not directly mapped to .NET assembly
  structure
• We only use HIR to analyse
• Need own API to reason about semantics
• Semantic tools independent of Phoenix

10
Meta Model
11
Meta Model
12
Creating an API

• Find certain instruction in method
• Is instruction in loop, for, conditional?
• Has instruction exception handling?
• Is parameter X assigned a value?
• Is field Y assigned a value in this
  method/property?
• Each method where value of Z gt 10
• Which operations are used on the ReifiedMessage
  parameter?

13
Remarks

• Static analysis
• Some minor code changes between the real source
  and IL
• However JIT does most of optimalization
• Local variable names are missing in IL
• Phoenix and Whidbey needed
• Phoenix very powerful

14
JIT Optimalization

• Constant folding
• Constant and copy propagation
• Common subexpression elimination
• Code motion of loop invariants
• Dead store and dead code elimination
• Register allocation
• Method inlining
• Loop unrolling (small loops with small bodies)
