Numerical simulation of the Alum lakes geothermal outflow

1
Numerical simulation of the Alum lakes
geothermal outflow

• J. Newson and M. J. OSullivan

2
BACKGROUND

• Part of a study on simulation of geothermal
  surface features
• If water is taken by geothermal wells, is there
  less for the springs?
• What about heat?
• Is this important?
• Used data from Alum Lakes, Wairakei

3
TAUPO VOLCANIC ZONE
4
WAIRAKEI-TAUHARA
5
ALUM LAKES
6
CONCEPTUAL MODEL
7

• Pirorirori (Alum Lake)
• Ceased flowing in late 1990s
• Photo taken Nov 2004

8
AVAILABLE DATA

• Mass flow (including streamflow)
• Temperature
• Chemistry
• Water level (recent)

9
3 SPRINGS WITH DATA
Pirorirori
10
RESERVOIR SIMULATION

• Simulator that represents heat and mass flow in
  porous and fractured media (rocks)
• Two phase (steam, water, water vapour, and air)

TOUGH2
11
RESERVOIR SIMULATION GRID

• Design a 2-D or 3-D block structure that will
• represent the system

12
VERTICAL SECTION
Alum Lakes
Te Mihi
0 mrsl
Western Borefield
Eastern Borefield
13
DETAIL, 2-D GRID
14
RESERVOIR SIMULATION PARAMETERS

• Give each block properties such as permeability,
  porosity, thermal conductivity

SURFACE FOLLOWS TOPOGRAPHY
Pirorirori
Butterfly Spring
Lower Devils Eyeglass
15
RESERVOIR SIMULATION B.C.s

• Assign boundary conditions

10 AV. ANN. RAINFALL
SIDE BOUNDARIES CLOSED
HOT WATER
HEAT
16
RUNNING A RESERVOIR SIMULATION

• Simulator calculates the temperature and pressure
  at the centre of each block
• T P differences lead to flows between blocks
• Control the flows by changing the permeability
  and porosity in each block

17
RESERVOIR SIMULATION TELLS US

• If the hypothesis is possible
• Possible permeability, porosity distribution
• Information about the subsurface flow paths
• Information on the future behaviour of the system

18
NATURAL STATE MODEL

• Reservoir temperature vs depth for Wairakei
  before production (1953)
• the mass flow data for Alum Lakes

19
NATURAL STATE MODEL
Alum Lakes mass flow data (kg/s)
field model
Pirorirori 11.3 11.91
Butterfly Spring 7.5 7.68
Lower Devils Eyeglass 1.6 2.07
Eastern Borefield
20
PRODUCTION PERIOD MODEL

• Use the natural state model as a starting point
  for production simulation
• Check the response of the Alum Lakes in the
  model, compare with known fiels data (mass flow
  over time)
• Production enthalpy, and reservoir pressure for
  the Wairakei borefields

21
PRODUCTION HISTORY
Eastern Borefield
Western Borefield
Enthalpy time history
Reservoir pressure time history
22
ALUM LAKES MASS OUTFLOW
23
NATURAL STATE LIQUID FLOWS
PIRORIRORI
BUTTERFLY SPRING
LOWER DEVILS EYEGLASS
24
NATURAL STATE GAS FLOWS
PIRORIRORI
BUTTERFLY SPRING
LOWER DEVILS EYEGLASS
25
1975 LIQUID FLOWS
PIRORIRORI
BUTTERFLY SPRING
LOWER DEVILS EYEGLASS
26
1975 GAS FLOWS
PIRORIRORI
BUTTERFLY SPRING
LOWER DEVILS EYEGLASS
27
2003 LIQUID FLOWS
PIRORIRORI
BUTTERFLY SPRING
LOWER DEVILS EYEGLASS
28
FINAL PERMEABILITY STRUCTURE
29
NEW CONCEPTUAL MODELNATURAL STATE
30
CONCEPTUAL MODEL2003
31
SUMMARY

• Behaviour of Alum Lakes Flows linked to reservoir
  changes
• Low permability zones control the shallow
  subsurface flow
• Groundwater now flows down into the reservoir
• Groundwater diverted from Alum Lakes springs, and
  from flowing further eastward

32
FUTURE WORK

• Model chloride component
• Model the water level change
