A green lacewing Chrysopa sp' in flight

1
A green lacewing (Chrysopa sp.) in flight
2
Figure 19.1 The organization of skeletal muscles
(Part 1)

• Muscle fiber is a muscle cell sheathed in
  endomysium
• A bundle of muscle fibers is a fascicle sheathed
  in perimysium
• A bundle of fascicles make up a muscle sheathed
  in epimysium.

3
Figure 19.1 The organization of skeletal muscles
(Part 2)
4
Figure 19.1 The organization of skeletal muscles
(Part 3)
5
Figure 19.1 The organization of skeletal muscles
(Part 4)
6
Figure 19.2 The arrangement of thick (myosin)
and thin (actin) myofilaments in a sarcomere

• Thick filaments (myosin) make up A band
• Thin filaments (actin) make up I band
• And titin extends from M line to Z disc

7
Figure 19.3 Muscle contraction produced by
sliding filaments

• Contraction
• I bands and H zones decrease in length
• A bands remain unchanged
• Strong contractions eliminate the H zone

8
Figure 19.4 Myosin molecules form the thick
filament
9
Figure 19.5 Molecular interactions that underlie
muscle contraction
10
Figure 19.6 The regulation of contraction
11
Figure 19.7 Excitationcontraction coupling
(Part 1)
12
Figure 19.7 Excitationcontraction coupling
(Part 2)
13
Figure 19.7 Excitationcontraction coupling
(Part 3)
14
Figure 19.8 Interaction between contractile and
elastic components (Part 1)
15
Figure 19.8 Interaction between contractile and
elastic components (Part 2)

• Muscle contractions are a combination of
  isometric and isotonic contractions.
• For experimental purposes the two are separated.

16
Figure 17.9 Recording isometric and isotonic
contractions (Part 1)
Figure 19.9 Recording isometric and isotonic
contractions (Part 1)

• A twitch is the response to a single AP
• Latent period is the time it takes for AP to
  reach VG Ca2 channels and for Ca2 to increase
  in the sarcoplasm
• Contraction is the sliding of filaments
• Relaxation is the sequestering of Ca2 in the
  sarcoplasmic reticulum

17
Figure 19.9 Recording isometric and isotonic
contractions (Part 2)

• The heavier the load the longer the latent period

18
Figure 19.10 The loadvelocity relationship of
skeletal muscle

• Isotonic contractions are used to look at the
  velocity of shortening.
• Greater loads decrease detachment rate between
  actin and myosin.
• The tension produced by a muscle must match the
  force of the load.

19
Figure 19.11 Summation and tetanus

• Single twitches
• Summationtwitches can sum because of the time it
  takes for a muscle to relax
• Tetanus is produced by high frequency stimulation
• Fused tetanus is a smooth contraction produced by
  many APs

20
Cellular physiology of tetanus and summation

• Tetanus leads to greater amounts of Ca2 released
  into sarcoplasm
• Greater number of crossbridges formed
• The elastic elements (connective fiber sheaths
  and Titin) need time to be pulled taut to
  increase force
• Crossbridges cycle repeatedly until elastic
  elements are taut.
• Tension depends on the the length of the muscle
  when stimulated.
• Muscle tension is greatest when muscle is at its
  ideal length.

21
Figure 19.12 The relationship between length and
tension produced by skeletal muscle (Part 1)
22
Figure 19.12 The relationship between length and
tension produced by skeletal muscle (Part 2)
23
Figure 19.13 Work of contraction
24
Box 19.1 The electric eel possesses both strong
and weak electric organs (Part 1)
25
Box 19.1 The electric eel possesses both strong
and weak electric organs (Part 2)
26
Box 19.1 The electric eel possesses both strong
and weak electric organs (Part 3)
27
Figure 19.14 The production and use of ATP
28
(No Transcript)
29
Figure 7.6 The fueling of intense but sustained
muscular work in humans
30
Figure 7.9 The mechanisms of meeting the ATP
costs of world-class competitive running
31
Types of Muscles

• Tonic muscle fibers are postural
• Generate no APs
• Slow cross-bridge cycling produces long sustained
  contractions with low energy costs
• Twitch muscle fibers
• Slow oxidative (SO)
• Fast oxidative glycolytic (FOG)
• Fast glycolytic (FG)
• The velocity of a contraction depends on load and
  the type of muscle fiber

32
Figure 19.15 Whole muscles typically consist of
mixtures of different types of fibers
33
(No Transcript)
34
(No Transcript)
35
The cat hindlimb and ankle extension

• The soleus muscle consists of SO fibers and
  functions in postural standing
• The medial and lateral gastrocnemius muscles are
  mixed (45 FG, 25 FO and 25 SO)
• The FO contributes fatigue resistance for walking
  and running
• The FG are reserved for short burst fast
  locomotion and for jumping

36
Exceptional muscles

• Hummingbird flight muscles contract at 80 Hz
• Tail shaker muscles of rattlesnake contract up to
  90 Hz at the proper temperature
• Factors contributing to speed
• Myosin isoforms capable of rapid crossbridge
  recycling
• Troponin isoforms that have low affinity for Ca2
• Increased density of Ca2 ATPase pumps in SR for
  rapid relaxation
• Cost of speed is limited ability to build up
  tension in muscles
• Shaker muscles require high amounts of ATP,
  glycogen and a large SR

37
Box 19.2 Insects exhibit two types of flight
muscles synchronous and asynchronous (Part 1)

• One AP leads to one contraction

38
Box 17.2 Insects exhibit two types of flight
muscles synchronous and asynchronous (Part 2)

• One AP leads to many oscillating contractions.
• One contraction one wing beat
• Verticle muscle induces contraction of
  longitudinal muscle and vice versa

39
Figure 19.16 Vertebrate skeletal muscles consist
of many different, independent motor units
40
Figure 19.17 Innervation patterns of vertebrate
tonic muscle fibers and arthropod muscle fibers
41
Figure 19.18 Smooth muscle (Part 1)
42
Figure 17.18 Smooth muscle (Part 2)
43
Organization of smooth muscle
44
Regulation of smooth muscle contractions
45
Smooth muscle physiology

• Smooth muscle maintains long term tone
• Provides steady pressure on GI contents
• Provides steady pressure in arterioles
• Smooth muscle fibers contract or relax in
  response to
• Stretching
• Hormones
• Change in pH, O2, CO2
• Temperature
• Ion concentrations

46
Smooth muscle contractions

• The bolus distends the gut, stretching its walls.

• Stretching stimulates nerves and the muscle
  becomes "more depolarized."
• When a slow wave passes over this area of
  sensitized smooth muscle, spike potentials form
  and contraction results.
• A coordinated contraction moves along the gut
  because the muscle cells are electrically coupled
  through gap junctions.

47
Figure 17.19 Cardiac muscle
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
