Portable Execution Time Analysis Method

1
Portable Execution Time Analysis Method
?
Keiji Yamamoto (University of Tokyo) Yutaka
Ishikawa (University of Tokyo) Toshihiro Matsui
(Advanced Industrial Science and Technology)
2
Background

• Real-time systems must finish tasks within fixed
  time bounds
• Controllers in cars, robots,
• Worst Case Execution Time (WCET) must be known

3
Goal of this work

• To design a static WCET prediction tool
• Requirements
• Guarantee of WCET
• Portability
• Various architectures are supported
• Pentium, XScale

4
WCET Analysis Approach

• Flow Analysis
• Determines the dynamic behavior of program
• Program code is represented by the graph
  structure (Control Flow Graph CFG)
• Timing Analysis
• Determines the execution time for each program
  part on the hardware
• Calculation
• Determines WCET using flow and timing information

5
Problem of Flow analysis

• Analyzes assembly code
• no portability
• data flow analysis is difficult
• A variable name and type information are lost.
• Analyzes C language
• Compiler optimization cannot be taken into
  consideration

6
Problem of Timing analysis

• Model-based approach
• constructs Pipeline, I-Cache, D-Cache, Branch
  prediction models
• Accuracy of these models cannot be guaranteed
• Internal behavior of a processor is not
  disclosure.
• Measurement-based approach
• It is possible for all the factors to be included
  in a measurement result
• The scope of this approach is limited

7
Our Approach

• Flow Analysis
• Analyzes intermediate expression of compiler
• Independent of Low-level and High-level language
• Compiler optimization can be taken into
  consideration
• Data flow analysis is performed on intermediate
  expression
• calculates loop bound
• Timing Analysis
• Simulation-based approach
• for memory access latency
• Measurement-based approach
• for instruction execution time

8
WCET Analysis System - RETAS
9
Flow Analysis
10
Flow Analysis

• Modified GCC 4.0.2
• Flow analyzer is implemented as a part of
  optimization phase
• Analyzes intermediate expression of GCC
• TREE,RTL (Register Transfer Language)
• Independent of Language and Architecture
• Considered compiler optimization
• Calculate loop bound automatically

11
Dynamic Flow

• Dynamic flow information is described as
  Annotation
• Using pragma
• Annotation is extracted inside a compiler
• pragma is translated into a function call with a
  preprocessor

for ( c 0 c lt n c ) pragma WCET
(loop", 10) / WCET_LOOP (10) / sum c
12
Timing Analysis

• Memory access time and the other execution time
  are calculated
• Simulation-based
• RTL-level memory access latency analysis
• Measurement-based
• calculate the execution time of instructions
  without memory access

13
Memory Access Latency Analysis

• RTL-level simulator
• Analyzes memory access pattern
• Independent of architecture
• Cache simulator
• Calculates memory access latency using memory
  access pattern
• Dependent of architecture
• Set-Associative, LRU Round-Robin
• Cache size, Line size, Way is modified by the
  parameter

14
Measurement-based analysis

• Assembly code is divided into basic blocks
• Timing analysis code is inserted into before and
  after these basic blocks
• These basic blocks are executed on a real machine

15
Evaluation of SimpleScalar

• Evaluation environment
• default parameter is used

16
Evaluation of SimpleScalar

• Estimated time is larger than the Observed time
• The error of fibonacci
• The pipeline overlap between basic blocks

17
Accuracy of RTL-Level simulator

• The memory access of SimpleScalar and RTL-level
  simulator is compared
• RTL-level simulation is equal to a binary level
  simulation
• The number of load instruction is strictly equal
• Cache access is also almost equal

18
Evaluation of Real-machine

• Evaluation environment

19
XScale Processor
XScale

• ObservedltEstimated
• predicted safely
• A prediction error is about several percent
• It is accurate because of simple architecture

20
Pentium-M Processor
Pentium-M

• ObservedltEstimated
• predicted safely
• A prediction error is large as compared with
  XScale

21
Limitation

• Not implemented factor
• Instruction cache
• Branch prediction
• There is an instruction to be able to measure the
  execution time with cycle.
• Simple architecture not implemented this
  instruction

22
Conclusion (1/2)

• New WCET analysis method
• Flow analysis
• Using intermediate expression of GCC
• Architecture independent
• Timing analysis
• Memory access latency
• Using RTL-level simulator and Cache
  simulator,cache hit and main memory access count
  are estimated
• Measurement execution time of each basic block

23
Conclusion (2/2)

• Evaluates some architectures
• SimpleScalar, XScale, Pentium-M
• Our system estimates safe WCET
• Complex architecture, prediction error is large
• Future work
• We consider instruction cache

24
End
